Alpha-InnoTec Solterra SWP 230H Instruction Manual page 21

M-devices up to maximum 55°C fl ow temperature
Heat pump type
Conformity
Installation
Protection
Power data
Heating power/COP
Power consumption
Sound
sound pressure level averaged at 1m distance to the machine (free field)
Application limits
Temperature limits heating circuit water
Temperature limits brine
Device
Dimensions, width x depth x height (without connections)
Weight including transport packing
Refrigerating agent type / charge
Heating circuit water
Minimum / nominal / maximum water flow rate
Pressure drop heat pump at nominal water flow rate
Temperature spread B0/W35
Heat source
Minimum / nominal / maximum brine flow rate
Pressure drop heat pump at nominal brine flow rate
Minimum brine / antifreeze concentration up to
Recommended brine circulation pump Grundfos type:
Total pressing of recommended pump at nominal brine flow rate
Connections
Heating circuit water
Brine
Dirt filter with 2 x 2" internal thread for brine circle, to be installed before heat pump
Power cable
Control line
Electrics
Nominal voltage / protection heat pump1)
Maximum machine current within application limits
Maximum theoretical compressor current (Imax) Klixon shift point)
Power consumption / cos at B0/W35 acc. to EN 255
Power consumption / current of brine pump at nominal flow rate
Setting range motor circuit switch
Starting current direct (locked rotor) with smooth starter (installed)
1) Observe local regulations
830109aGB/151024
B0/W35 acc. to EN255
B0/W50 acc. to EN255
B-5/W35 acc. to EN255
B-5/W50 acc. to EN255
B../W35 and B../W50
- Subject to Technical Modifi cations -
TECHNICAL DATA
Brine / Water
CE
Indoor
IP24
kW/- 81,9 / 4,2 (43,4 / 4,4)
82,0 / 3,0 (43,5 / 3,1)
kW/-
73,5 / 3,8 (39 / 3,8)
kW/-
kW/- 72,6 / 2,7 (38,4 / 2,7)
kW / kW
about. 19,5 and about 27,3 (about 9,9 and about. 14,0)
dB(A) 57
20 to 55
°C
-5 to 25
°C
mm 920 x 800 x 1690
kg 610
- / kg R407C / 12
6500 / 7300 / 15000
l/h
0,05
bar
K 9,7
l/h 17000 / 20800 / 40000
bar 0,25
% / °C 25 / -13
UPS 50-180F (3x400V,50Hz)
0,92
bar
2 x 2" external thread
2 x 2" external thread
to be provided by customer
2
to be provided by customer
mm / m
-
V / A 400 / 63C
A 2 x 29,7
A 2 x 32
kW / A / - 19,5 / 36,8 / 0,76
kW / A 0,92 / 2
1,8 - 2,5
A
198 / 90
A / A
SWP 820
V.813135
