Alpha-InnoTec Solterra SWP 230H Instruction Manual page 16

TECHNICAL DATA
SWP 410H
H-devices up to maximum 65°C fl ow temperature
V.813139
Heat pump type
Conformity
Installation
Protection
Power data
Heating power/COP
Power consumption
Sound
sound pressure level averaged at 1m distance to the machine (free field)
Application limits
Temperature limits heating circuit water
Temperature limits brine
Device
Dimensions, width x depth x height (without connections)
Weight including transport packing
Refrigerating agent type / charge
Heating circuit water
Minimum / nominal / maximum water flow rate
Pressure drop heat pump at nominal water flow rate
Temperature spread B0/W35
Heat source
Minimum / nominal / maximum brine flow rate
Pressure drop heat pump at nominal brine flow rate
Minimum brine / antifreeze concentration up to
Recommended brine circulation pump Grundfos type:
Total pressing of recommended pump at nominal brine flow rate
Connections
Heating circuit water
Brine
Dirt filter with 2 x 2" internal thread for brine circle, to be installed before heat pump
Power cable
Control line
Electrics
Nominal voltage / protection heat pump1)
Maximum machine current within application limits
Maximum theoretical compressor current (Imax) Klixon shift point)
Power consumption / cos at B0/W35 acc. to EN 255
Power consumption / current of brine pump at nominal flow rate
Setting range motor circuit switch
Starting current direct (locked rotor) with smooth starter (installed)
1) Observe local regulations
16
B0/W35 acc. to EN255
B0/W50 acc. to EN255
B-5/W35 acc. to EN255
B-5/W50 acc. to EN255
B../W35 and B../W50
- Subject to Technical Modifi cations -
Sole / Wasser
CE
Innen
IP24
40,3 / 4,1 (21,4 / 4,4)
kW/-
37,5 / 2,8 (19,9 / 3,0)
kW/-
36,2 / 3,7 (19,2 / 3,8)
kW/-
33,6 / 2,5 (17,8 / 2,6)
kW/-
ca. 9,8 und ca. 13,5 (ca. 4,8 und ca. 6,6)
kW / kW
60
dB(A)
20 bis 65
°C
-5 bis 25
°C
920 x 800 x 1690
mm
550
kg
R134a / 9,5
- / kg
3500 / 4200 / 8400
l/h
0,025
bar
K 8,6
7800 / 10000 / 21000
l/h
0,08
bar
25 / -13
% / °C
CHI 8-10 (3x400V,50Hz)
0,68
bar
2 x 2" Außengewinde
2 x 2" Außengewinde
Bauseits zu erstellen
2
Bauseits zu erstellen
mm / m
-
V / A 400 / 50C
A 2 x 19,5
A 27
kW / A / - 9,8 / 25,7 / 0,55
kW / A 0,72 / 1,4
A 1,1-1,6
167 / 70
A / A
830109aGB/151024
