Alpha-InnoTec SWP Series Operating Manual
Brine/water heat pumps professional, construction unit 1
Hide thumbs
Also See for SWP Series:
- Operating instructions manual (68 pages) ,
- Operating manual (52 pages) ,
- Operating manual (32 pages)
Related Manuals for Alpha-InnoTec SWP Series
Summary of Contents for Alpha-InnoTec SWP Series
- Page 1 Brine/Water Heat Pumps Professional Operating Manual SWP series Construction unit 1 83053700lUK...
-
Page 2: Please Read First
Symbols Please read first This operating manual provides important information The following symbols are used in the operating on the handling of the unit. It is an integral part of the manual. They have the following meaning: product and must be stored so that it is accessible in the immediate vicinity of the unit. -
Page 3: Table Of Contents
Table of contents Please read first 22 Maintenance ..........2 ..........21 22.1 Basic principles ........21 Symbols ............2 22.2 Maintenance as required ......21 Contact ............. 4 22.3 Clean and flush the evaporator and condenser ..........21 Intended use ........... -
Page 4: Contact
DIN/VDE regulations and all relevant safety regulations. ● Germany: www.alpha-innotec.de The operating manuals supplied with the product are ● www.alpha-innotec.com intended for all users of the product. The product is intended for use by end customers /... -
Page 5: Personal Protective Equipment
6.1 Personal protective equipment Injuries and environmental damage due to refrigerant During transport and work on the unit, there is a risk of cuts due to the sharp edges of the unit. The unit contains flammable (primary) refrigerant that is hazardous to health and the environment. If (prima- ►... -
Page 6: Warranty / Guarantee
Improper action Unsuitable quality of the water-antifreeze mixture in the heat source Requirements for minimising scale and corrosion dam- age in hot water heating systems: IMPORTANT ● Proper planning, design and commissioning Use of pure water in a flat-plate collector or a ●... -
Page 7: Operating Principle Of Heat Pumps
Operating principle of heat 10 Heat metering pumps In addition to proof of the unit’s efficiency, the EEWaermeG also requires heat metering (hereafter Heat pumps operate on the same principle as a referred to as HQR). Heat metering is mandatory for refrigerator: same technology, only with reversed air/water heat pumps. -
Page 8: Cooling
12 Cooling The room thermostat of the cooling function (purchasable accessories, optional) There are two ways to use the heat pump for air con- ditioning in rooms, through: „passive cooling“ and „ac- The room thermostat is used to release and to switch tive cooling“. -
Page 9: Care Of The Unit
Check the delivery for outwardly visible signs of NOTE damage. Variant 2 is only possible if the expansion Check that nothing is missing from the scope of board (purchasable accessories) is installed supply. in the heating and heat pump controller. Any defects or incorrect deliveries must be ... -
Page 10: Installation
15 Installation The surface/floor is suitable for installation of the unit: Observe the following when performing all work: ● level and horizontal ● load-bearing capacity for the unit’s weight NOTE Always comply with the applicable local accident prevention regulations, statutory 15.2 Transport to installation location regulations, ordinances,... -
Page 11: Installation
Lower the basic heat pump module on the 4 wood- WARNING en transport blocks in its final installation location. Several people are required to transport Now use the vibration-decoupling, adjustable ma- the unit. Do not underestimate the weight chine feet to align the unit horizontally. Ensure the of the unit. -
Page 12: Domestic Hot Water Tank
16.3 Domestic hot water tank IMPORTANT When installing the connections, always If the heat pump is to be used for domestic water secure the connections on the unit against heating, you must integrate special domestic hot water twisting, in order to prevent damage to the tanks in the heat pump system. -
Page 13: Installing The Housing
16.4 Installing the housing Use the insulating tape supplied to insulate the connection clip. Use the enclosed fastening mate- rials to additionally fix the insulation. NOTE Remove the protective film from all facing panels. NOTE The screws for installing the heat pump housing are included in the scope of delivery. - Page 14 Align the facing with the baseplate as shown in The front panel can now be hung into the clips the following sketch provided at the bottom. and locked by means of the two quarter-turn screws. Secure and fix the facing on the profile rail using the fastening materials included in the scope of delivery (2 x 10mm anchors and 2 x M8 hanger bolts).
-
Page 15: Electrical Connections
17 Electrical connections Lift out front panel and set aside in a safe place. Open the unit’s electrical switch cabinet. The following applies to all work to be done: DANGER Risk of fatal injury due to electric shock! All electrical connections must be carried out by qualified electricians only. - Page 16 The external electric cables to be provided must be fed through the grommets cut out in the bottom of the rear panel and then fed into the electrical switch cabinet by means of the cable duct, which is integrated into the baseplate of the heat pump.
-
Page 17: Installation Of The Control Element
18 Installation of the control Fasten the wall bracket using the 3 screws (plus dowels) included in the scope of delivery. element The separate package contains: 1 wall bracket “Wallbracket for control unit”, page 42 2 control unit Plug the control unit onto the wall bracket. 3 cover The cables are laid either through the wall (e.g. -
Page 18: Flushing And Filling The Unit
19 Flushing and filling the unit NOTE A connection to a computer or a network can be made via socket 2, in order to enable the CAUTION heating and heat pump controller to be con- The system must be absolutely free from air trolled remotely from there. -
Page 19: Flush And Fill The Heating Circuit
19.2 Flush and fill the heating circuit WARNING Methanol and ethanol can give off flam‑ mable and explosive gases. Therefore, the Unsuitable quality of the water for filling up safety provisions for the anti‑freeze must and replenishing the heating circuit be noted and followed! The hazard markings of all anti‑freezes The efficiency of the system and the service life of the... -
Page 20: Insulating The Hydraulic Connections
21 Commissioning Monitoring Analytical recording and monitoring of the relevant water values and the added active conditioning NOTE substances is of decisive importance. Therefore, they The commissioning has to be in the heating should be monitored regularly using appropriate water mode. -
Page 21: Maintenance
22 Maintenance 23 Faults ► Read out the cause of the fault via the diagnostics NOTE program of the heating and heat pump controller. We recommend that you sign a maintenance ► Contact the local partner of the manufacturer or the agreement with accredited... -
Page 22: Technical Data / Scope Of Delivery
Technical data / scope of delivery Brine operation Device designation Heat pump type Brine/Water ı Air/Water ı Water/Water • relevant ı — not relevant Installation location Indoors ı Outdoors • relevant ı — not relevant Conformity Power data Heating power/COP at 2 Compressors kW ı... - Page 23 SWP371 SWP451 SWP581 SWP691 SWP291H SWP561H • ı — ı — • ı — ı — • ı — ı — • ı — ı — • ı — ı — • ı — ı — • ı — • ı — •...
-
Page 24: Water Operation
Technical data / scope of delivery Water operation Device designation Heat pump type Brine/Water ı Air/Water ı Water/Water • relevant ı — not relevant Installation location Indoors ı Outdoors • relevant ı — not relevant Conformity Power data Heating power/COP at Standard nominal conditions based 2 Compressors kW ı... - Page 25 SWP371 SWP451 SWP581 SWP691 SWP291H SWP561H — ı — ı • — ı — ı • — ı — ı • — ı — ı • — ı — ı • — ı — ı • • ı — • ı — •...
-
Page 26: Performance Curves
SWP 371 Performance curves – Brine operation Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 10,0 “”[m3/h] “„[m3/h] ∆p” ∆p„ Keys Keys UK823025L UK823025L “” “” Volume flow, heating water Volume flow, heating water 823077a “„... -
Page 27: Swp 451
Performance curves – Brine operation SWP 451 Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 10,0 15,0 “”[m3/h] “„[m3/h] ∆p” ∆p„ 823078a Legende: DE823025L Keys Keys UK823025L UK823025L “”... -
Page 28: Swp 581
SWP 581 Performance curves – Brine operation Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 15,0 10,0 15,0 20,0 “”[m3/h] “„[m3/h] ∆p” ∆p„ Keys Keys UK823025L UK823025L “” “”... -
Page 29: Swp 691
Performance curves – Brine operation SWP 691 Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 15,0 10,0 15,0 20,0 “”[m3/h] “„[m3/h] ∆p” ∆p„ Keys Keys UK823025L UK823025L “” “”... -
Page 30: Swp 291H
SWP 291H Performance curves – Brine operation Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 70°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823081a Keys Keys UK823025L UK823025L Legende: DE823025L “” Volumenstrom Heizwasser “”... -
Page 31: Swp 561H
Performance curves – Brine operation SWP 561H Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 70°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 15,0 20,0 10,0 12,5 “”[m3/h] “„[m3/h] ∆p… ∆p… Keys Keys UK823025L UK823025L 823082 “” “”... -
Page 32: Water Operation
SWP 371 Performance curves – Water operation Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 10,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823077a Keys Keys UK823025L UK823025L Legende: DE823025L “” Volumenstrom Heizwasser “”... -
Page 33: Swp 451
Performance curves – Water operation SWP 451 Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 10,0 15,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823078a Keys Keys UK823025L UK823025L Legende: DE823025L “”... -
Page 34: Swp 581
SWP 581 Performance curves – Water operation Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 15,0 10,0 15,0 20,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823079a Keys Keys UK823025L UK823025L Legende: DE823025L “”... -
Page 35: Swp 691
Performance curves – Water operation SWP 691 Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 65°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 15,0 10,0 15,0 20,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823080a Keys Keys UK823025L UK823025L Legende: DE823025L “”... -
Page 36: Swp 291H
SWP 291H Performance curves – Water operation Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 70°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 15,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823081 Keys Keys UK823025L UK823025L Legende: DE823025L “” Volumenstrom Heizwasser “”... -
Page 37: Swp 561H
Performance curves – Water operation SWP 561H Qh (kW) Temp„ (°C) Pe (kW) 35°C 45°C 55°C 70°C Temp„ (°C) Temp„ (°C) ∆p (bar) ∆p (bar) 10,0 12,5 10,0 15,0 20,0 25,0 “”[m3/h] “„[m3/h] Δp” Δp„ 823082 Keys Keys UK823025L UK823025L Legende: DE823025L “”... -
Page 38: Dimensional Drawings
SWP 371 – SWP 691 Dimensional drawings – moving dimensions Keys: UK819407 Keys: UK819407 All dimensions in mm. All dimensions in mm. Front view Front view Side view from left Side view from left Rear view Rear view Front view with facing Front view with facing View from underneath with facing View from underneath with facing... - Page 39 Dimensional drawings with housing SWP 371 – SWP 691 Keys: UK819406b Keys: UK819406b Item Item Designation Designation All dimensions in mm. All dimensions in mm. Control element (for wall mounting, in extra box) Control element (for wall mounting, in extra box) A A Front view Front view Penetration for connection and LIN bus cable...
-
Page 40: Swp 291H - Swp 561H
SWP 291H – SWP 561H Dimensional drawings – moving dimensions Keys: UK819416 Keys: UK819416 All dimensions in mm. All dimensions in mm. Front view Front view Side view from left Side view from left Rear view Rear view Front view with facing Front view with facing View from underneath with facing View from underneath with facing... - Page 41 Dimensional drawings with housing SWP 291H – SWP 561H Keys: UK819414b Keys: UK819414b Item Item Designation Designation All dimensions in mm. All dimensions in mm. Control element (for wall mounting, in extra box) Control element (for wall mounting, in extra box) A A Front view Front view Penetration for connection and LIN bus cable...
-
Page 42: Wallbracket For Control Unit
Schutzvermerk ISO 16016 beach Bohrschablone A Wallbracket for control unit Dimensional drawing lattformat: A4 hoch Keys: UK819444a Keys: UK819444a Maßstab Det. Maßstab Allgemein- Oberflächen All dimensions in mm. All dimensions in mm. toleranz Werkstoff Gewicht DIN ISO 2768 -c Datum Name Benennung Maßbild PWZS... - Page 43 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
-
Page 44: Installation Plans
SWP 371 – SWP 691 / SWP 291H – SWP 561H Installation plan 1 max. 13m 1350 >500 >500 Keys: UK819408a Keys: UK819408a All dimensions in mm. All dimensions in mm. Front view Front view Plan view Plan view Legende : DE819408a Hatched area: space for service purposes Hatched area: space for service purposes... -
Page 45: Installation Plan 2
Installation plan 2 SWP 371 – SWP 691 / SWP 291H – SWP 561H max.13m >2730 >30 >500 >500 Keys: UK819409 Keys: UK819409 All dimensions in mm. All dimensions in mm. Front view Front view Legende : DE819409 Plan view Plan view Hatched area: space for service purposes Hatched area: space for service purposes... -
Page 46: Hydraulic Integration
SWP 371 – SWP 691 / SWP 291H – SWP 561H Separate buffer tank Subject to change without notice | 83053700lUK | ait-deutschland GmbH... -
Page 47: Legend Hydraulic Integration
Subject to change without notice | 83053700lUK | ait-deutschland GmbH... -
Page 48: Terminal Diagram
SWP 371 – SWP 691 / SWP 291H – SWP 561H Terminal diagram 3~PE/400V/50Hz 1~N/PE/230V/50Hz ZW2/SST Subject to change without notice | 83053700lUK | ait-deutschland GmbH... -
Page 49: Circuit Diagrams
Circuit diagram 1/3 SWP 371 / SWP 451 Subject to change without notice | 83053700lUK | ait-deutschland GmbH... - Page 50 SWP 371 / SWP 451 Circuit diagram 2/3 OUT1 OUT4 OUT5 Green Yellow white Brown AIN1 AIN2 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
- Page 51 Circuit diagram 3/3 SWP 371 / SWP 451 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
-
Page 52: Swp 581 / Swp 691 / Swp 561H
SWP 581 / SWP 691 / SWP 561H Circuit diagram 1/3 Subject to change without notice | 83053700lUK | ait-deutschland GmbH... - Page 53 Circuit diagram 2/3 SWP 581 / SWP 691 / SWP 561H OUT1 OUT5 Green Yellow white Brown AIN1 AIN2 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
- Page 54 SWP 581 / SWP 691 / SWP 561H Circuit diagram 3/3 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
-
Page 55: Swp 291H
Circuit diagram 1/3 SWP 291H Subject to change without notice | 83053700lUK | ait-deutschland GmbH... - Page 56 SWP 291H Circuit diagram 2/3 OUT1 OUT5 Green Yellow white Brown AIN1 AIN2 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
- Page 57 Circuit diagram 3/3 SWP 291H Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
- Page 58 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
- Page 59 Subject to change without notice | 83053700lUK | ait-deutschland GmbH...
- Page 60 GmbH Industriestraße 3 D-95359 Kasendorf E info@alpha-innotec.de W www.alpha-innotec.de alpha innotec – an ait-deutschland GmbH brand...
