TROUBLESHOOTING

If a user experiences errors with any of the validation tests or
the resulting graphs do not look similar to the ones displayed in
the previous sections, refer to the troubleshooting help below to
ensure that each board is configured properly with its default
settings:
EVAL-AD5940ARDZ
Ensure the jumpers on the EVAL-AD5940ARDZ are in their
default positions as described in Table 8.
Table 8. EVAL-AD5940ARDZ Default Jumper Positions
Jumper Default Position
JP1 One jumper in Position A, one jumper in Position C
JP2 Position C
JP3 Position C
JP4, JP5 Disabled (no jumper inserted)
JP14 Inserted
JP10 Inserted
JP6 Inserted
Refer to the board schematic, EVAL-AD5940ARDZ-REVC.pdf
for more details.
EVAL-AD5940 Evaluation Kit User Guide
AD5940-BioElectric
Ensure the jumpers on the
are in their default positions as described in Table 9.
Table 9. AD5940-BioElectric
Jumper Default Position
P1 Inserted
P2 Connected to PIN1 and PIN2
P7 Connected to PIN2 and PIN3
P9 Inserted
P10 Connected to PIN1 and PIN2
P12 Connected to PIN2 and PIN3
P13 Connected to PIN3 and PIN5
AD5940Sens2
Ensure the jumpers on the
their default positions as described in Table 10.
Table 10. AD5940Sens2
Jumper Default Position
JP1, JP2 Connected to PIN1 and PIN2
JP3 Connected to PIN5 and PIN6
JP6 Connected to PIN1 and PIN2 (except for
amperometry tests, in which case it is connected to
PIN3 and PIN4)
