User Guide
MODULE OPERATION
Table 16. Command, SYSTem:ZERO:CAL (Continued)
lid, and this command returns Calibration in progress...
Channel 1 input voltage is too high.
Example
SYSTem:ZERO:CAL 1, 0.
Table 17. Command, SYSTem:POS:FULL:CAL
Syntax
SYSTem:POS:FULL:CAL {1|2}, {value}.
Function
Users can use this positive full-scale calibration function to
set the range for Channel 1 or Channel 2.
Explanations
The value is input from the source to Channel x and the
valid input must be between 80% and 120% of positive full
scale. This command returns 'Calibration in progress...
Channel X Calibration Done' and the measured value
once it is transmitted successfully. Otherwise, the calibra-
tion is invalid, and this command returns Calibration in
progress... Channel X full scale calibration data can
not exceed 80% ~ 120% of Full Scale.
Example
SYSTem:POS:FULL:CAL 1, 0.2.
Table 18. Command, SYSTem:NEG:FULL:CAL
Syntax
SYSTem:NEG:FULL:CAL {1|2}, {value}.
Function
Users can use this negative full-scale calibration function
to set the range for Channel 1 or Channel 2.
Explanations
The value is input from the source to Channel x, and the
valid input must be between 80% and 120% of negative full
scale. This command returns Calibration in progress...
Channel X Calibration Done and the measured value
once it is transmitted successfully. Otherwise, the calibra-
tion is invalid, and this command returns Calibration in
progress.. Channel X full scale calibration data can not
exceed 80% ~ 120% of Full Scale.
Example
SYSTem:NEG:FULL:CAL 1, −0.2.
Table 19. Command, SYSTem:CAL:DATE
Syntax
SYSTem:CAL:DATE {20yy}, {mm}, {dd}.
Function
Users can use this function to write the calibration date into
the ADMX3652.
Explanations
This command must run after calibration, or it returns
please execute calibration firstly. In the command, 20yy
is the year, mm represents the month, and dd represents
the day. The ADMX3652 returns Calibration Date year-
month-day: 20yy-mm-dd.
Example
SYSTem:CAL:DATE 2023, 01, 01.
Table 20. Command, SYSTem:CAL:DATE?
Syntax
SYSTem:CAL:DATE?
Function
Queries the last calibration date.
Explanations
User can use this function to query the date of the last
successful calibration.
analog.com
EVAL-ADMX3652
Table 20. Command, SYSTem:CAL:DATE? (Continued)
Example
SYSTem:CAL:DATE? returns the last calibration date.
Table 21. Command, SYSTem:CAL:STORE
Syntax
SYSTem:CAL:STORE {ON|OFF}.
Function
Users can use this function to save or erase calibration
data and information.
Explanations
This command must go after SYSTem:CAL:DATE, or it
returns please input calibration date first, command:
SYSTem:CAL:DATE [year],[month],[day].
Example
SYSTem:CAL:STORE ON.
Table 22. Command, SYSTem:INFormation?
Syntax
SYSTem:INFormation? {HARdware|FIRmware|BATch|
MANufacture}
Function
Queries the device information of the instrument.
Explanations
The query returns hardware version, firmware version,
serial number, and manufacturing date.
Example
SYSTem:INFormation? FIRmware returns the firmware
version.
Table 23. Command, SYSTem:CAL:TIMES?
Syntax
SYSTem:CAL:TIMES?
Function
Queries the total calibration times on the device.
Explanations
The device records times of successful calibration. User
can use this function to query the calibration times of the
device.
Example
SYSTem:CAL:TIMES? returns the total calibration times.
ERROR CODES AND TROUBLESHOOTING
Error Operating the ADMX3652 Evaluation GUI
Software
When using the EVAL-ADMX3652-INT interface board to power
and communicate with the
ADMX3652
the COM port may fail to be recognized because of the following
reasons:
The hardware is not connected properly; check and confirm
►
hardware connections.
The driver is not installed properly (see the
►
section to install or reinstall the driver).
Error Codes Feedback in UART
Communication
When communicating with the ADMX3652, error codes or messag-
es can be returned from the device. Refer to
messages, descriptions, and troubleshooting. If the user receives
an error message that is not listed below, contact
Sales
for further assistance.
and a PC, in some cases,
Software Installation
Table 24
for error code
Analog Devices
Rev. B | 16 of 22
