TIPS AND TRICKS

1. Enable help mode to get information about specific
parameters, measurement techniques, and measurement
theories. Hover the mouse over a certain parameter or
measurement on the screen to view the relevant
information.
Figure 43. Help Mode
2. Export the generated graph data to a Microsoft® Excel file
by clicking the Excel icon above the graph area. The file
explorer opens for the user to name and save the file.
Figure 44. Export to Excel
3. Click the expand button to toggle the graph full screen or
restore it to its original size.
Figure 45. Toggle Full Screen
4. Use the scroll wheel on the mouse to zoom in and out on
certain sections of the graph.
5. Hover over a point on the graph to view the point's x-value.
Click on the point to view the point's y-value.
6. After data collection has finished, double-click the graph
area to fit the graph to the screen.
Rev. 0 | Page 23 of 27
Figure 46. Graph Data Points
Figure 47. Graph Fit
