Getting Started with the ADIS1622x Evaluation Tools
Mark Looney
iSensor Applications Engineer
December 2010
Downloaded from
Elcodis.com
electronic components distributor

Advertisement

loading
Need help?

Need help?

Do you have a question about the iSensor ADIS1622x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Analog Devices iSensor ADIS1622x

Summary of Contents for Analog Devices iSensor ADIS1622x

  • Page 1 The World Leader in High Performance Signal Processing Solutions ® iSensor Getting Started with the ADIS1622x Evaluation Tools Mark Looney iSensor Applications Engineer December 2010 Downloaded from Elcodis.com electronic components distributor...

  • Page 2: Table Of Contents

    ® iSensor The Simple Solution for Sensor Integration Table of Contents, ADIS1622x Evaluation Tools TITLE/TOPIC PAGE Hardware: ADIS1622x/PCBZ, ADISUSBZ ADIS16220/PCBZ Documentation ADIS16220/PCBZ Physical Installation on an ADISUSBZ ADIS16223/PCBZ, ADIS16227/PCBZ: Schematic & Mounting Hole Pattern ADIS16223/PCBZ, ADIS16227/PCBZ: Physical Installation on an ADISUSBZ ADIS16223/PCBZ, ADIS16227/PCBZ: Ribbon Mating Cable Design Remote Mounting Option ADIS16220 Evaluation Software Installation...

  • Page 3: Hardware: Adis1622X/Pcbz, Adisusbz

    ® iSensor The Simple Solution for Sensor Integration Evaluation Tool Options ADIS16220/PCBZ The iSensor evaluation tools are designed for two purposes: Enable fast connection to SPI-compatible processor systems. Provide simple PC-based tools to demonstrate basic device functions. ADIS16220/PCBZ, Interface board Provides ADIS16220CCCZ on a small PCB with 2mm connectors.

  • Page 4: Adis16220/Pcbz Documentation

    ® iSensor The Simple Solution for Sensor Integration ADIS16220/PCBZ A, 4x 1.050 J1/J2 PIN NUMBERS 2 × 0.925 ADIS16220CCCZ AIN1 AIN2 SCLK 2 × 0.673 DIO2 i Sensor DOUT DIO1 B, 2x 4 × Ø0.087 VREF M2×0.4 2 × 0.000 0.150 A.

  • Page 5: Adis16220/Pcbz Physical Installation On An Adisusbz

    ® iSensor The Simple Solution for Sensor Integration ADIS16220/PCBZ Installation on ADISUSBZ Installation Steps 1. Remove ribbon cable & (2) 2mm screws. 2. Place ADIS16220/PCBZ on the ADISUSBZ, using the silk screen and four corner mounting holes as a guide. 3.

  • Page 6: Adis16223/Pcbz, Adis16227/Pcbz: Schematic & Mounting Hole Pattern

    ® iSensor The Simple Solution for Sensor Integration ADIS16223/PCBZ, ADIS16227/PCBZ A. ADIS16223CMLZ bolted to the interface board using: Fastener Express p/n FHS1106-4I2 , flat head 10/32x3/8”. B. Interface board general-purpose mounting holes. Use M2 (2mm) machine screws to help manage potential C, 6x B, 4x PCB-level resonance threats.

  • Page 7: Adis16223/Pcbz, Adis16227/Pcbz: Physical Installation On An Adisusbz

    ® iSensor The Simple Solution for Sensor Integration ADIS16223/PCBZ, ADIS16227/PCBZ; ADISUSBZ Installation 1. Bend ribbon cable back. 2. Remove M2 screws if they are present. 3. Place M2x6mm screws in six ADISUSB mounting holes. 4. Place ADIS1622x/PCBZ onto the ADISUSBZ and tighten screws.

  • Page 8: Adis16223/Pcbz, Adis16227/Pcbz: Ribbon Mating Cable Design

    ® iSensor The Simple Solution for Sensor Integration ADIS1622x/PCBZ Ribbon Cable Interface ADISUSBZ uses the following J1/J2 Ribbon Cable Interface Parts cable assembly from Samtec: ASP-140062-01 Ribbon Crimp Connector 3M P/N 152212-0100-GB Ribbon Cable 3M P/N 3625/12 (100m) Downloaded from Elcodis.com electronic components distributor...

  • Page 9: Remote Mounting Option

    ® iSensor The Simple Solution for Sensor Integration Alternate Use for Best Mechanical Coupling 1. Remove ADIS1622xCMLZ from ADIS1622x/PCBZ by carefully unplugging the flex (it can break) and the 10-32 screw on the bottom side. 2. Cut the interface board down so that the ADIS1622xCMLZ can be mounted to the test frame using a 10-32 stud or machine screw.

  • Page 10: Adis16220 Evaluation Software Installation

    ® iSensor The Simple Solution for Sensor Integration ADIS1622x Evaluation Software Installation The ADIS16220, ADIS16223, and ADIS16227 have their own demo/evaluation software packages, which can be downloaded from each product’s web page at www.analog.com. Use the following steps to download, install, and get the evaluation software running.
  • Page 11 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Evaluation Software Installation Installation Steps (continued) Unpack contents from zipped file and click on “setup.exe”. Click OK on the next screen. Click on computer icon to start the installation process. Downloaded from Elcodis.com electronic components distributor...
  • Page 12 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Evaluation Software Installation Installation Steps (continued) Click Continue. If a window like this appears, we suggest keeping the existing files. In this case, click "Yes" to keep existing files. Click OK Downloaded from Elcodis.com electronic components distributor...
  • Page 13 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Evaluation Software Installation Installation Steps (continued) Open the newly created directory and double-click onto “giveio.exe”. 10. Click “Install”. Downloaded from Elcodis.com electronic components distributor...
  • Page 14 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Evaluation Software Installation Installation Steps (continued) 11. Click “Install”. 12. Click “Yes”. 13. Giveio Driver complete. Click “Ok”. Downloaded from Elcodis.com electronic components distributor...

  • Page 15: Adisusbz Usb Driver Installation

    ® iSensor The Simple Solution for Sensor Integration MCP USB Driver Installation Installation Steps Plug the ADISUSBZ to the PC using an A-to-B USB cable. The USB Driver screen will pop-up. Click “Next” to start this process. Then click on “Continue Anyway”.

  • Page 16: Adis16220, Adis16223 Evaluation Software

    ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Manual Trigger Mode 1. Click on “Interface” and select USB, then OK when the pop-up window shows the USB device is connected. 2. Software should start up and place the ADIS1622x device in Manual mode.

  • Page 17: Automatic Trigger Mode

    ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Automatic Trigger Mode 1. Automatic mode in the ADIS1622x products uses an internal timer to trigger new data capture events. 2. Since the ADISUSBZ doesn’t connect to the “Busy” signal, DIO1 per factory default, use the LEDs on the ADIS16223/PCBZ to...

  • Page 18: Event Trigger Mode

    ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Event Trigger Mode 1. Use the pull-down menu to set the device up for “Event Capture Mode”. Downloaded from Elcodis.com electronic components distributor...
  • Page 19 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Event Trigger Mode 2. Use the “ALARMS” option in the configuration pull-down menu to set up the trigger levels. Downloaded from Elcodis.com electronic components distributor...
  • Page 20 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Event Trigger Mode, Alarms 1. In this example, enable each alarm, then enter the acceleration threshold for triggering the capture. 2. In this case, enter “10”, then click “Write A1”. 3.
  • Page 21 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Event Mode Capture Example 1. Click on “Arm” and notice that the DIO1 LED light turns on. 2. Tap the assembly on non-valuable surface. Increase the intensity of the tap until the capture triggers.

  • Page 22: Filter Case Study

    ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Filtering, No Filtering Enabled 1. The ADIS1622x are wide- band filters. 2. Lower frequency applications tend to value lower noise. 3. The filtering helps optimize the noise and frequency content of the data capture.
  • Page 23 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Band-Pass Filtering 1. Enable the band-pass filter. 2. Click on Trigger. 3. Notices the lower amount of noise and the fact that it is centered around 0g now. Downloaded from Elcodis.com electronic components distributor...
  • Page 24 ® iSensor The Simple Solution for Sensor Integration ADIS1622x Software Tips, Band-Pass & Low-Pass Filtering 1. Click on the AVG_CNT pull-down menu and select 64. 2. Click on Trigger. 3. Observe the lower noise and longer capture time. Downloaded from Elcodis.com electronic components distributor...

  • Page 25: Adis16227 Evaluation Software, Basic Setup

    ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Basic Setup 1. Double click on the ADIS16227*.exe file to start the software. 2. Make sure that the settings under “Main Control” and “Sample Rate Options” match those in this graphic. The Signal Range, FFT Avgs, SR3 settings are the most common...

  • Page 26: Adis16227 Evaluation Software, Basic Demo

    ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Basic Demo 1. Shake the ADIS16227 in a repetitive manner and click on “Start.” Continue the shaking until the software completes collecting data. 2. After data collection is complete, use the mouse pointer to measure the response.

  • Page 27: Adis16227 Evaluation Software, Spectral Alarm Demo

    ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Spectral Alarm Demo 1. Use the “Configuration” drop-down menu to click on the “Alarm Spectrum” option. Downloaded from Elcodis.com electronic components distributor...
  • Page 28 ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Spectral Alarm Demo 2. Under “Sample Rate Option,” use the drop- down menu to select “3”. 3. Change each entry by highlighting the numbers and then typing it in. Downloaded from Elcodis.com electronic components distributor...
  • Page 29 ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Spectral Alarm Demo 4. Enter all of the numbers show for this demo in the graphic. 5. Click on “Write All” to save them to the flash memory in the ADIS16227.
  • Page 30 ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Spectral Alarm Demo 8. After returning to the main window, use the “Configuration” drop- down menu to select the “ALM_CTRL” option. 9. Use the ALM_CTRL menu to enable all three (x,y,z) spectral alarms.
  • Page 31 ® iSensor The Simple Solution for Sensor Integration ADIS16227 Software Tips: Spectral Alarm Demo 11. Repeat the shaking motion and click on “Start”. 12. Observe the Peak Alarms and Spectral Alarms outputs. Downloaded from Elcodis.com electronic components distributor...
  • Page 32 Contacts:  Applications Engineer: Mark Looney  mark.looney@analog.com 1-336-605-4139 Marketing: Bob Scannell  bob.scannell@analog.com 1-336-605-4031 More Information on iSensor Evaluation Tools: www.analog.com/isensor-evaluation  Downloaded from Elcodis.com electronic components distributor...
