■ Supplied accessories
For the mounting bracket
Mounting bracket
Knob bolts
Screws (M5×20 mm) Spring washers (M5)
Microphone
Screws (5×20 mm) Nuts (M5)
Sponges
Microphone hanger
and screws (3×16 mm)
DC power cable
(OPC-1174A)*
GPS antenna
Conversion cable (OPC-2384)*
*
1
U sedforthetransceiverʼsoperationcheck. (12 V DC only)
*
2
For only the USA version.
*
3
May not be supplied, depending on the transceiver version.
Flat washers (M5)
Accessory connectors
6-pin
8-pin
1
Warning sticker*
2
3
CONNECTIONS AND MAINTENANCE
D Accessory connectors set up
The accessory connectors are used on the accessory
cables.
*
ACC Cable
Solder
Be sure to set this ring to keep the waterproof capability.
*
12
These illustrations are for the
8-pin connector.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
