SPECIFICATIONS AND OPTIONS
D Dimensions
250 (9.8)
274 (10.8)
104
Unit: mm (inch)
28 (1.1) 93.5 (3.7)

■ Options

D Command head and cables
• RC-M600
command head
The command head with the same front panel as the
transceiver. Mounting bracket, microphone, and a 10 meter
(32.8 feet) connection cable included.
• OPC-2383 *
control cable
10 meter (32.8 feet) cable to connect the transceiver and
RC-M600 .
command head
*The same cable as the cable supplied with RC-M600.
• OPC-2377
extension cable
10 meter (32.8 feet) extension cable.
D Microphone and cables
• HM-195GB/HM-195GW
commandmic IV
External microphone-type controller. Provides optional
intercom operation. 6 meters (20 feet) microphone cable
and mounting base included.
HM-195GB: Black
HM-195GW: White
*Not usable for the IC-M605EURO.
• HM-229B/HM-229W
commandmic V
External microphone-type controller without [DISTRESS] key.
HM-229B: Black
HM-229W: White
™ *
™
