EV-ADF5355SD1Z User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Reference Designator
C1, C2, C7, C8, C10, C11,
C16, C20, C22
C9, C12, C21, C47
C4, C5, C13, C14, C18, C24
C17
C19
C25, C28, C29, C31, C34, C37,
C38, C43, C46, C48, C54
C27, C30, C32, C36,
C39 to C42
C3, C6, C51
C26, C33, C35, C45, C50,
C53, C55, C58
C44
C56, C57
C59
C60
C61
C71
C73
C74 to C76
CVP, CVRF, CAVDD, CDVDD,
CVRF1, CVVCO, CVRVCO
CN1
DS1, LED1
GND
L1, L2
SCL, SDA, TP1 to TP6, PDRF,
TP_VP, MUXOUT, TP_VRF,
TP_DVDD, TP_VRF1,
TP_VVCO, TP_+3.3V,
TP_AVDD1, TP_AVDD2
P3
R1, R4, R5, R12, R21, RV1 to
RV3, RV6 to RV9, R3V3,
RV11, RV12, RV14 to RV16,
RV18 to RV20, RV25 to
RV27, RV29 to RV31,
RMUXOUT
R11, R16, RMUX, RCPOUT,
R_VREGVCO
R14
R17
Description
Ceramic multilayer capacitor, X5R
Ceramic capacitor, X7R
Ceramic capacitor, X8R
Ceramic capacitor, X5R
Ceramic capacitor, X5R
RF/microwave capacitor, C0G
Ceramic capacitor, C0G, 0402
Ceramic chip capacitor, RF
Ceramic capacitor, X7R
Ceramic capacitor, NP0
Ceramic capacitor, C0G, 0402
Ceramic capacitor, Y5V
Ceramic capacitor
Ceramic capacitor, X7R
Solid tantalum electrolytic capacitor
Chip capacitor, C0G, 0603
Tantalum chip capacitor
Tantalum capacitor surface-mount device
(SMD)
Connector printed circuit board (PCB),
vertical type receptacle SMD
LED, 570 nm, SMD (green)
Connector PCB, single socket (black)
Inductor chip
Connector PCB, test point (yellow)
Connector PCB, Header 3
Film SMD resistor, 0603
Resistor thick film chip
Film SMD resistor, 0603
Film SMD resistor, 0603
Value
10 μF
1 μF
1 μF
4.7 μF
10 μF
10 pF
1000 pF
10 pF
0.1 μF
100 pF
120 pF
0.47 μF
22 nF
10,000 pF
22 μF
10 pF
100 μF
22 μF
7.4 nH
0 Ω
0 Ω
220 Ω
470 Ω
Rev. B | Page 17 of 19
Manufacturer Part Number
TDK C2012X5R1E106K085AC
Allied 0603YC105KAT2A
Electronics
TDK C2012X8R1C105K125AB
TDK C1608X5R1C475K080AC
TDK C1608X5R1A106M080AC
Allied 04025U100GAT2A
Electronics
Murata GRM1555C1H102JA01
Allied 0201ZK100GBSTR
Electronics
KEMET C0402C104K4RACTU
Yageo 2238 867 15101
Murata GRM1555C1H121JA01
Murata GRM188F51C474ZA01D
Allied 0603YC223KAT2A
Electronics
Yageo CC0603KRX7R9BB103
Allied TCJC226M025R0100
Electronics
Murata GRM1885C1H100JA01D
Allied TAJB107K006R
Electronics
Allied TAJB226K016R
Electronics
HIROSE FX8-120S-SV(21)
Avago HSMG-C170
Technologies
Del-Tron 571-0100
Precision, Inc.
Coilcraft 0302CS-7N4XJLU
Components TP-104-01-04
Corporation
Molex 22-28-4033
Multicomp MC0603WG00000T5E-TC
Multicomp 0402WGF0000TCE
Multicomp MC 0.063W 0603 1%
220R
Multicomp MC 0.063W 0603 1%
470R
UG-802
