Analog Devices EV-ADF5355SD1Z User Manual page 18

UG-802
Reference Designator
R18, R19, R23
R2
R22
R25, RLE, RCLK, RDATA
R27
R32, R33
R6
RAVDD
RE1, RE2
RE3
REFINA, REFINB
RFOUTB, RFOUTA+,
RFOUTA−
S1
U1
UE1
VR2
VR3, VR5
VSUPPLY
VSUPPLY_ALT
Y1
ZD1
1 TBD means no value assigned; component not inserted.
Description
Film SMD resistor, 0603
Precision thick film chip, resistor R0603
Film SMD resistor, 0603
Precision thick film chip resistor, R0805
High-frequency thin film chip resistor
Chip SMD resistor, 0201
Standard thick film chip resistor
Precision thick film chip resistor, R0805
Precision thick film chip resistor, R0805
1
Do not install (TBD0603)
PCB, coaxial SMA, end launch connector
PCB, SMA right angle jack connector
Momentary single pole single throw
switch
IC, Analog Devices microwave wideband
synthesizer with integrated VCO
IC, 32 kB serial EEPROM
IC, 800 mA, ultralow noise/high power
supply rejection ratio (PSRR), RF linear
regulator, 5.0 V output
IC, 800 mA, ultralow noise/high PSRR, RF
linear regulator, 3.3 V output
Connector PCB, coaxial SMA, end launch
(do not install)
PCB, single socket (red) connector
IC, crystal low voltage positive emitter
coupled logic (LVPECL)
Zener diode, 6.8 V, SOT-23
Value
1.8 kΩ
10 kΩ
68 Ω
1.5 kΩ
100 Ω
0 Ω
5.1 kΩ
1 kΩ
100 kΩ
Rev. B | Page 18 of 19
EV-ADF5355SD1Z User Guide
Manufacturer Part Number
Multicomp MC 0.063W 0603 1% 1K8
Panasonic ERJ-3EKF1002V
Multicomp MC 0.063W 0603 1% 68R
Panasonic ERJ-6ENF1501V
Vishay FC0402E1000BST1
Panasonic ERJ-1GE0R00C
Vishay CRCW04025K10FKED
Panasonic ERJ-6ENF1001V
Panasonic ERJ-6ENF1003V
Do not install
Johnson 142-0701-801
Rosenberger 32K243-40ML5
Alcoswitch TT11AGPC-1
Analog Devices ADF5355BCPZ
Microchip 24LC32A-I/MS
Technology, Inc.
Analog Devices ADM7150ACPZ-5.0
Analog Devices ADM7150ACPZ-3.3
Do not install
Del-Tron 571-0500
Precision, Inc.
Vectron VCC6-LAB-122M880000
International
Philips BZX84-C6V8
