Figure 7-34: Coverage Map with Rate Control Mapping
27.00
Mark A
ac
27.00
Mark A
ac

ZOOM IN/OUT

Vehicle View
Zoom In/Out & Perspective is used to adjust the vehicle's view or
perspective to the horizon from vehicle view to bird's-eye view.
• Zoom In will adjust view to vehicle view displaying a
compass on the horizon
will adjust view to bird's-eye view
• Zoom Out
Figure 7-35: Zoom In to Zoom Out
27.00 0.0
ac
Pro 570GS • MATRIX
®
MATRIX
10.0
mph
10.0
Field View
mph
Zoom in/out is used to adjust the map's visible area.
• Zoom In
• Zoom Out
While in Field view guidance, the Pan mode allows the screen to be
positioned manually as desired. The off-center position on the screen
will be retained until the World icon is pressed.
To enter Pan mode and pan across the screen:
1. Press SCREEN OPTIONS tab
2. Press:
►AND DRAG SCREEN in the corresponding direction to move
►ARROWS
►WORLD VIEW icon
NOTE: Press & Hold ARROWS
7.2
mph
To close Pan Mode options:
1. Press CLOSE OPTIONS tab
Figure 7-36: Pan Mode
27.00 0.0
ac
will decrease the amount of map area visible.
will increase the amount of map area visible.

PAN MODE

the view on screen.
in the corresponding direction to
move the view on screen (down, left, right, up).
to center vehicle on screen and
extend the screen view to the widest area available.
settings.
.
-13 0.0
98-05273-ENUS R9
®
Pro 840GS
7.2
mph
.
to quickly adjust
7.2
mph
