Pro 570GS • MATRIX
®
MATRIX

REALVIEW SPECIFIC OPTIONS

RealView guidance allows live video input to be displayed instead
of a computer-generated image. RealView setup options accesses
additional guidance tools including guidance over video and a
steering angle indicator.
►Single Camera – a single camera is directly attached to the
console
►Video Selection Module – if a Video selection module (VSM)
is installed on the system, two (2) video options are available:
• One Camera View – one of up to eight camera inputs can
be selected to change the view of the video input.
• Split Camera View – one of two sets of four camera inputs
(A/B/C/D or E/F/G/H) can be selected to divide the screen
into four separate video feeds.
To adjust the camera view [reverse, upside down], go to Setup->
Configuration-> Video.
To access the RealView options:
1. Press REALVIEW GUIDANCE bottom tab
2. Press REALVIEW OPTIONS tab
options.
3. Select from:
►Single Camera View
(8) camera inputs can be selected to change the view of the
video input
►Split Camera View [VSM only] – one (1) of two (2) sets of
four (4) camera inputs (A/B/C/D or E/F/G/H) can be selected
to divide the screen into four separate video feeds

►RealView Guidance Options

guidance tools including guidance over video and a steering
angle indicator
►RealView Camera Image Capture
the current view on the screen to a USB drive
Figure 7-37: RealView Guidance
10.0
0.0
mph
88
www.teejet.com
.
to display RealView
[VSM only] – one (1) of up to eight
– accesses additional
– saves a still photo of
27.00
ac
®
Pro 840GS
RealView Guidance Options
RealView setup options accesses additional guidance tools
including guidance over video and a steering angle indicator.
1. Press REALVIEW OPTIONS tab
options.
2. Press REALVIEW GUIDANCE OPTIONS icon
3. Select from:
►Guidance Over Video
guidelines over the video feed for navigation assistance
►Steering Angle Indicator
the steering wheel needs to be adjusted
►Horizon Line Adjustment
horizon line up or down
Figure 7-38: RealView Setup Options
0.0
mph
0.0
mph
0.0
mph
to display RealView
.
– places three-dimensional
– displays the direction in which
– adjusts the on-screen
0.00
0.0
ac
0.00
0.0
ac
0.00
0.0
ac
