Pro 570GS • MATRIX
®
MATRIX
Polygons Map
Polygon map shows all mapped polygons.
On Screen Mapping
• Guidelines
◄Blue – polygon boundary line
Figure 8-8: Polygon Map with Rate Control Available
27.00
Mark A
ac
Prescription Map
Prescription map is a pre-loaded map that provides information
to the rate controller for use in applying product. Prescription
maps contain geo-referenced product rate information. The
Matrix Pro GS can import job data containing Prescription maps for use
with variable-rate application (VRA) using compatible rate controllers.
On Screen Mapping
• Zone lines:
◄Black when approaching the application zone.
◄White when within the application zone.
◄ Other zones having the same rate will also be shown in
white.
• Coverage Area – illustrates different prescription rate zones:
◄ User selected – zone colors are selected when establishing
the Prescription map.
With Fieldware Link (v5.01 or later), users can import VRA jobs
created in Fieldware Link, as well as export job data from the console,
edit the included maps to create Target rate or Prescription maps, and
transfer back to the console for job use.
NOTE: Advanced job mode is required for variable rate applications.
See Options (Job mode) in the System setup chapter.
94
www.teejet.com
®
Pro 840GS
Figure 8-9: Prescription map
10.0
mph
Application and Target Rate Maps
Application Map
and where, using color to indicate level in proportion to preset or
automatically set maximum and minimum levels
Target Rate Map
controller attempted to achieve at each location
NOTE: Application map and Target Rate map cannot be selected
Application Map
Application Map shows how much product has been applied
and where, using color to indicate level in proportion to preset
or automatically set maximum and minimum levels.
NOTE: Application Map and Target Rate Map cannot be selected
On Screen Mapping
• Coverage Area – illustrates applied area:
◄ User Selected – applied areas show colored bars relative to
Figure 8-10: Application Map
27.00
Mark A
ha
shows how much product has been applied
shows the application rate that the rate
simultaneously.
simultaneously.
selected color range and map selection.
27.00
Mark A
ac
10.0
km/h
10.0
mph
