Warnings and Information Pop-ups

A pop-up warning or information box will be displayed for
approximately five (5) seconds. To remove the information box, tap
anywhere on the screen.
Figure 1-8: Example of Information Text Box

Setup Option Information

Press the option's icon or option's name of any menu item to display
a definition and range values of that item. To remove the information
box, press anywhere on the screen.
Figure 1-9: Example of Information Text Box
Pro 570GS • MATRIX
®
MATRIX

Drop Down Menu Selections

Press DOWN arrow
arrows
list. Select the appropriate option. To close the list without selecting an
option, tap anywhere on the screen outside the drop down menu.
Figure 1-10: Example of Drop Down Menu

Scrolling Screens

Some screens have more information or options that are visible
beyond the current screen. Use the UP/DOWN arrows
slide bar to access additional options or information not currently
visible on the screen.
Figure 1-11: Example of Scrolling Screen
®
Pro 840GS
to access the options. Use the UP/DOWN
or slide bar if necessary to scroll through the extended
Backward
Forward
98-05273-ENUS R9
or
5
