CHAPTER 4 – SYSTEM SETUP
System Setup is used to configure the console, the machine and its implements. Four side tabs access options for Machine/Implement
Configuration, Data Management, Console Settings, and Tools.

OVERVIEW

Four side tabs access setup options for:
Configuration
• Implement (Straight, Spreader, or Staggered Implement
configurations; Tip Selection information including Droplet Size
Monitor, Reverse configuration)
• Mapping and Guidance (Mapping Location, Lightbar, External
Lightbar)
• GNSS Receiver Configuration
• Video Configuration
• Sensors (Input/Output Module (IOM) Pressure Sensor)
• Product configuration
• Third-party rate control configuration
• AutoSteer
◄FieldPilot (Valve Setup, Steering Settings, Valve Test, Valve
Diagnostics, Steering Wheel Sensor, Steering Angle Sensor)
◄FieldPilot Pro / UniPilot Pro (Manage Vehicle, Calibrations,
Adjustments, Select QI Values, Transport Mode, Service
Mode)
• Tilt Correction
Figure 4-1: Setup Options
Pro 570GS • MATRIX
®
MATRIX
• Job Data (Transfer, Manage)
• Reports
• Options (Job Mode)
• Machine Settings (Transfer, Manage)
• About (System Information)
• Display
• Cultural
• Audio Volume
• Demo GNSS
• Feature Unlock
• Upload Software
• Extras (Calculator, Units Converter)
Side Tabs
Configuration side tab
Data Management side tab
Console Settings side tab
Tools side tab
System Setup bottom tab
Data Management
Console Settings
Tools
®
