CHAPTER 2 – JOBS / HOME SCREEN
Once the power up sequence has completed and the console is
receiving GNSS, the Home screen will appear with the option to start
a new job or continue an existing job.
Setup for the specific machine and its components
must be completed before starting a job.
job is active, some setup options can no longer be changed. See
"Matrix Pro GS Console Menu Settings" in the appendix of this
manual.
To change between simple and advanced mode, go to Data->
Options-> Job Mode in the System Setup.

Simple Mode

In simple mode, only one job will be available at a time. Only
bounded area, coverage areas, and application time are displayed
on the home screen. Only the current job is available for saving in
Reports. Use with Fieldware Link is not available.
Figure 2-1: Simple Mode Home Screen
Pro 570GS • MATRIX
®
MATRIX

Advanced Mode

In advanced mode, more than one job will be available at any time.
Client, farm, field and job names; bounded and coverage areas;
application time; and distance from selected job are displayed on the
home screen. All saved job profiles can be exported as a PDF, SHP
Once a
or KML file to a USB drive using Data-> Reports.
Client information, farm information, field information, and
prescription maps can only be inputted using Fieldware Link. A job
name can only be edited using Fieldware Link.
A user can duplicate jobs for reuse of guidelines, boundaries, applied
data, prescription map and/or polygons using Fieldware Link or
Data-> Job Data-> Manage in the console.
Figure 2-2: Advanced Mode Home Screen
®
Pro 840GS
