Copy Machine Profile

The copy machine profile option is used to duplicate the selected
machine profile for recall of that profile at a later use. Machine
profiles can be used to transfer settings to another console of the
same make and model with the same attached hardware.
1. Press DATA MANAGEMENT side tab
Machine settings
2. Press .
Manage
3. Press .
4. Select the machine profile to be copied into a new profile.
5. Press .
Copy
6. Name the new profile.
7. Press the ACCEPT icon
CANCEL icon to leave the keyboard without saving.
8. Press RETURN arrow
to return to the main Data management screen
tab
Figure 4-40: Machine Settings – Copy Profile
New Machine Settings Name
1 2 3 4
q w e r
Caps a s d
Alt z x
MATRIX
.
to save the new profile or the
or DATA MANAGEMENT side
5 6 7 8 9 0 <---
t y u i o p
f g h j k l
c v b n m Shift
Pro 570GS • MATRIX
®

CONSOLE

Console Setup is used to configure the display and cultural settings,
unlock advanced features and play back demo GNSS data.
Information about other devices attached to the system can be found
in the About section.
1. Press SYSTEM SETUP bottom tab
2. Press CONSOLE side tab
3. Select from:
►About – used to display the system software version as well
as the software versions of modules connected to the CAN
bus
►Display – used to configure color scheme and LCD
brightness, establish screenshot availability, and calibrate the
touchscreen
►Cultural – used to configure units, language, and time zone
settings
►Audio Volume – used to adjust the volume level of the audio
speaker
►Demo GNSS – used to start playback of simulated GNSS
data
►Feature Unlock – used to unlock advanced features
Figure 4-41: Console Options
®
Pro 840GS
.
.
