NOTE: The supply cord shall be with PE conductor and cross section at least 3 x 1.00 mm
The unit can be connected to external installation with overcurrent protective device max. value 16A or 20A (USA/CANADA). This
device is intended for use in a basic electromagnetic environment (Basic, class B), and it is in compliance with IEC 61326-1:2020. The
device may experience a restart during overvoltage events (surges) or voltage interruptions in mains power supply.
The Labnet Orbit™ Digital Shakers is designed to be safe when operated under the following conditions:
Indoor use

Altitude up to 2,000 meters

Pollution Degree 2


4.0 Installation

4.1 Unpacking

Before starting installation, carefully examine the shaker for damage or missing parts.
Open the box, and lift the device together with the inner packing out of the box.

Remove the inner packing and check that the shaker has not been visibly damaged during transportation. Keep the packing material

until you are sure that the shaker works properly.
Check information on the rear data label and verify the following are correct:

Model
•
Serial number
•
Electrical rating
•
Should any kind of damage have occurred during transportation, contact the carrier immediately. The carrier is responsible for
shipping damage.

4.2 Selecting the Location

Put the device on a horizontal, leveled, and stable surface.

Leave enough space around the device for normal air circulation (4 in./10 cm minimum).

Leave enough space around the device for easy access and maintenance.

Do not use the device in surroundings where there are major temperature and humidity fluctuations. Also avoid locations in direct

sunlight or places near devices that produce heat.
Avoid locations with excessive vibrations.


4.3 Attaching the Power Cord

Fit the main power cord, which is included in the package, into the power receptacle on the shaker. Connect the other end of the cord
to a properly grounded wall outlet. To avoid interference from noise, surges, and spikes, a dedicated line is preferred. If no such line is
available, avoid lines to which powerful electric motors, refrigerators, and similar devices are connected.
Be careful when you plug the cord to a grounded wall socket. Do not touch plug with wet hands. Do not pull the plug by the cord.
4.4 Installing Shaker Platforms
Labnet Orbit P4

Unit comes with the platform already installed.
2 or 3 x AWG 18 (USA/CANADA).
