CAUTION: This equipment is not intended for use in residential environments and may not provide adequate protection
to radio reception in such environments.
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
5.0 Package Contents
Labnet Mini LabRoller™ Rotator
Rotisserie for 36 x 1.5/2.0 mL microcentrifuge tubes (Cat. No. H5500-02)
Power supply
Instruction manual
6.0 Installation
6.1 Unpacking
Before starting the installation, carefully examine the rotator.
Open the box and carefully remove the padding. Check to see that the rotator has not been damaged during transportation. Keep
the packing material until you are sure the rotator works properly.
Make sure that all of the accessories are included.
Carefully lift the unit from the box.
Be sure the following information is included on the label located on the bottom of the unit: Serial number, product number,
electrical rating.
Check that the power cord has the correct configuration that matches the outlet according to your local standards.
NOTE: If any damage occurred during transportation, contact your carrier immediately.
6.2 Installation
Place the rotator on a stable, flat surface. Connect the plug into the grounded wall socket. Avoid sockets where powerful electric
motors, refrigerators, and similar devices are also connected.
Use the On/Off switch to control the rotator.
Be careful when you plug the cord into the grounded wall socket.
Do not touch the plug with wet hands.
Do not pull the plug by the cord.
7.0 Loading the Rotisserie
The rotisserie supplied with the unit is designed to hold standard 1.5 or 2.0 mL microcentrifuge tubes.
There are two other rotisseries available separately for different size tubes. Each rotisserie consists of a rotisserie plate with bar keys
for placement into the apparatus and a two piece rotisserie rod with bar key on either end.
Install the rotisserie rod by screwing the two elements together through the hole in the center of the rotisserie plate. Insert the tubes
into the tube holders. Mount the rotisserie in the apparatus in either the vertical position using the rotisserie rod, or the horizontal
position using the bar keys on the plate. The side opposite to the driving mechanism is flexible to allow inserting the rotisserie
without tools. Insert the bar key on the rotisserie rod or plate into the drive mechanism. The other end of the rotisserie is suspended in
the bushing located in the opposite side of the unit. Be sure to distribute tubes evenly across the rotisserie carrier to achieve smooth
rotating motion.
2
|
LABNET MINI LABROLLER ROTATOR
