Press START/STOP button to start operation. RUN and TIME signal lights. Shaker runs and counts down time from set value.

NOTE: You cannot modify the set time during shaking; however, you can stop the unit with the START/STOP button and then reset the time.
Changing the RPM during shaking
Push the encoder knob to put the shaker into RPM set mode (RPM signal light will be on).

Rotate the encoder knob right (+) or left (-) to set the desired value. In the meantime RPM signal light will flash.

When you stop rotating the encoder knob the signal light for RPM will stop flashing after 2 sec.

When the run time has elapsed or when you press the START/STOP button, End will show on the display, and the Run light will flash.

When the shaker completely stops the set speed and time will return to the last programmed values.


5.3 Additional Operations

If you want to view the set value for RPM during shaking, rotate the encoder knob for ONE CLICK right (+) or left (-). RPM signal light

will then flash for 2 sec., and the display will show the set RPM and the light will stop flashing.
NOTE: Shaker must be in RPM mode – RPM signal light must be on.
If you want to view the set value for TIME during shaking, rotate the encoder knob for ONE CLICK right (+) or left (-). Time signal light

will then flash for 2 sec., and the display will show the set TIME and the light will stop flashing.
6 | LABNET ORBIT DIGITAL SHAKERS
POWER
RUN TIME
99.4
POWER
RUN TIME
100
POWER
RUN TIME
End
POWER
RUN TIME
120
RPM
Encoder
Push
RPM
Encoder
Push
RPM
Encoder
Push
RPM
Encoder
Push
START
STOP
START
STOP
START
STOP
START
STOP
