Labnet S0200 Instruction Manual

Do not exceed the "Accessory Max" speed setting when using any acces- Do not exceed the "Accessory Max" speed setting when using any acces- Do not exceed the "Accessory Max" speed setting when using any acces- Do not exceed the "Accessory Max" speed setting when using any acces- Do not exceed the "Accessory Max" speed setting when using any acces-
sory heads. Doing so can cause damage to the vortex mixer. . . . . sory heads. Doing so can cause damage to the vortex mixer sory heads. Doing so can cause damage to the vortex mixer sory heads. Doing so can cause damage to the vortex mixer sory heads. Doing so can cause damage to the vortex mixer
Optional shaking heads are as follows:
S0200-21 Microtube head, foam, for 80 tubes
S0200-22 Microplate head, foam, for 1 microplate or 64 x 0.2mL tubes
S0200-23 10-13mm and 15mL tube head, for 16 tubes
S0200-24 50mL tube head, for 6 tubes
S0200-25 Head for 12 x 1.5ml tubes, held horizontally
S0200-26 Head for 4 x 15 ml tubes, held horizontally
S0200-27 Head for 2 x 50 ml tubes, held horizontally
Contact your Labnet dealer for information about ordering additional heads
Care and Maintenance Care and Maintenance Care and Maintenance
Care and Maintenance Care and Maintenance
Warning: Disconnect the vortexer from power source before attempting Warning: Disconnect the vortexer from power source before attempting Warning: Disconnect the vortexer from power source before attempting Warning: Disconnect the vortexer from power source before attempting Warning: Disconnect the vortexer from power source before attempting
any cleaning or maintenance procedures. any cleaning or maintenance procedures. any cleaning or maintenance procedures. any cleaning or maintenance procedures. any cleaning or maintenance procedures.
After each use, wipe down the mixer with a soft cloth. Do not immerse the unit
or pour liquids over it as electrical shock may occur. Clean up any spills imme-
diately taking the proper precautions. If required, the shaking head may be
removed. First, disconnect the vortexer from the power source and then remove
the combo-cup head by holding the housing securely while pulling up on the
head. The head may then be cleaned with a mild detergent. Be sure the head is
thoroughly dry before replacing it on the unit.
The motor and shaking mechanism in the Vortex Mixer require no routine main-
tenance or lubrication.
Where to Call Where to Call Where to Call Where to Call Where to Call
If you have a question about the Vortex Mixer, contact Labnet's Customer Ser-
vice Department at 732 417-0700, Monday through Friday, 8:30am to 5:00pm
EST
For service inquiries, contact Labnet's Service Department at 732 417-0700,
9:00am to 5:00pm, Monday through Friday, EST. Before returning any unit for
service, a Return Authorization (RA) number must first be obtained. Equipment
sent in without out prior authorization will be returned at the customer's expense.
When returning a unit to Labnet for service, it should be sent in the original
packaging. If this is not possible, be sure that the unit is sufficiently packed.
Any damage resulting from improper packaging is the responsibility of the cus-
tomer. A written explanation should accompany the unit along with the RA num-
ber.
P.O. Box 841 • Woodbridge, NJ 07095 • phone: 732 417-0700
e-mail: labnet@labnetlink.com • http://www.labnetlink.com
Instruction Manual Instruction Manual
Instruction Manual Instruction Manual Instruction Manual
V V V V V ortex Mixer ortex Mixer ortex Mixer ortex Mixer
ortex Mixer
Cat.# S0200
S0200-230V-EU
S0200-230V-UK
S0200-230V-CH
Labnet International, Inc.
PO Box 841
Woodbridge, NJ 07095
Phone 732 417-0700
Fax 732 417-1750
email labnet@labnetlink.com
www.labnetlink.com
Copyright April 2007 Labnet International Inc.
Revision 1
