3 .0 Specifications

Chamber temperature range
Accuracy/uniformity
Temperature accuracy
Temperature controller
Over temperature safety
Shaker speed
Shaker orbit
Shaker maximum load
Shaker timer
Timer increments
Interior electrical outlet
Chamber volume
Exterior dimensions (W x D x H)
Chamber dimensions (W x D x H)
Overvoltage category
Electrical ratings and unit size
I-5311-DS
I-5311-DS-230V
Environmental conditions
*Maximum load is 4 x 2L flasks with 400 mL liquid in each flask.
The Labnet 311DS Shaking Incubator is designed to be safe at least when operated under the following conditions:
Indoor use

Altitude up to 2,000 meters

Pollution Degree 2


4.0 Unpacking

Upon receipt of your Labnet 311DS Shaking Incubator, examine the carton and unit for damages. If shipping damage has occurred, a
claim must be filed with the carrier. The carrier is responsible for correcting shipping damages. Save all packaging until the unit has
been shown to operate properly to your satisfaction. Carefully remove the unit from the carton and shipping pallet.
The Labnet 311DS Shaking Incubator includes the following components:
311-DS Digital Shaking Incubator

1 full shelf

2 shelf brackets

4 adjustable feet

Power cord (both EU and UK cords in 230V models)

Instruction manual


5.0 Installation

Install the four adjustable feet and place the Shaking Incubator on a stable, flat, very solid surface near a grounded electrical outlet.
The location selected should be out of direct sunlight and away from heat producing sources or hot or cold air drafts. At least 2 in.
(5 cm) ventilation clearance is required around all sides of the incubator. Level the incubator using the four adjustable feet. Clockwise
rotation of a foot raises the incubator. Plug in the unit to a properly rated and grounded electrical outlet and the unit will be ready for
use. Install the optional platform you have selected by plugging in the four bottom protrusions. Larger flask platforms may require
being screw clamped to the shaking mechanism.
The shelf may be installed when using shaker flasks 1L or smaller. However, the shelf severely limits the illumination from the
chamber light and the shelf may possibly rattle under aggressive shaking conditions.
2 | LABNET 311DS SHAKING INCUBATOR
Ambient, +5°C to 80°C (shaker off)
Ambient, +10°C to 80°C (shaker on)
±0.3°C to ±0.5°C at 37°C
±0.2°C
Microprocessor, user calibratable
Independently settable
20 to 300 rpm
0.75 in. (19 mm)
16.3 lbs. (7.4 kg)*
Continuous (Hld) or 30 seconds to 99 min. 50 seconds
30 seconds to 9 min. 59 seconds in 1-second steps
10.0 min. to 99 min. 50 seconds in 10-second increments
1 amp (115V units only)
2.5 cu. ft. (70.8L)
22.6 x 21.4 x 25 in. (57.4 x 54.4 x 63.5 cm)
17.4 x 15.6 x 16 in. (44.2 x 39.6 x 40.6 cm)
Category II
120V ±10%, 50/60 Hz, 5x20 T8A 250V (1 fuse)
230V ±10%, 50/60 Hz, 5x20 T6.3A 250V (2 fuses)
15°C to 30°C, ≤80% RH (at 25°C)
