1.0 Introduction

The Labnet Orbit™ Digital Shakers are intended for shaking microliter plates, tubes, bottles, flasks, dishes and other laboratory
vessels. The shakers are driven by asynchronous motors, which enable silent operation and constant shaking speed independent of
the load or power supply fluctuations.
Each shaker device consists of two main components:
Motor with eccentric mechanism

Control electronics

The motor drives the shaker's eccentric mechanics and generates shaking effect. The electronics control the motor RPM, TIME, and
keyboard functions.

2.0 Safety Precautions

Always plug the unit into a properly grounded and fused outlet.

Do not use the device near water sources. Take care so that water will not fall on the device, especially during cleaning procedures.

Do not use the device in a caustic or explosive atmosphere.

There are no user serviceable parts in the unit. Opening the unit may void the warranty. In case of a malfunction or liquid being

spilled into the unit, unplug the device from its power outlet and contact Corning Customer Service.
NOTE: In the case that the device does not function properly even if you have exactly followed the instructions described in
the User's Manual, contact Corning Customer Service. If the equipment is used in a manner not specified by this manual, the
equipment may become unsafe to operate, could harm the user or the device, and may void the warranty.
Do not shake inflammable or explosive samples or use the unit in an inflammable or explosive environment.

3 .0 Specifications

The casings of the Labnet Orbit P4, 300, and 1000 are made of plastic. Bottom cover and upper plate are made of steel plate varnished
with high resistant polyurethane lacquer.
The housing of the Orbit 1900 is made from a high-grade cold rolled steel plate and painted with a highly resistant polyurethane
lacquer.
Labnet Orbit P4

Electric Power Supply
120V
230V
Motor Power
Fuse
120V
230V
RPM Regulation
Shaker Orbit
Timer
Maximum Load
Dimensions (W x L x H)
Weight
Ambient Operation Range
120V ± 10%, 50/60Hz
230V ± 10%, 50/60Hz
15W
2 x 1AT, 120V
2 x 0.25AT, 230V
Digital, load independent, from 100 to 1,200 rpm (1,400 rpm, 120V version) in 10 rpm steps
3 mm
30 sec. to 99 min. 50 sec. in 10-second steps (under 10 min. in 1-second steps), timer HOLD function
0.66 lbs. (0.3 kg)
7.4 x 11.8 x 5.9 in. (18.8 x 30 x 15 cm)
9.5 lbs. (4.3 kg)
5°C to 40°C, up to 85% RH, non-condensing
Instruction Manual | 1
