1.0 Introduction

The Labnet Mini LabRoller™ Rotator is and end over end tube rotator, designed for mixing samples in both a horizontal and vertical plane.

2.0 Symbols and Conventions

The electrical warning indicates the presence of a potential hazard which could result in electrical shock.
CAUTION: This symbol refers you to important operating and maintenance (servicing) instructions within this Instruction
Manual. Failure to heed this information may present a risk of damage or injury to persons or equipment.
This symbol identifies a Protective Earth (PE) terminal, which is provided for connection of the supply system's protective
earth (green or green/yellow) conductor.

3.0 Safety Information

NOTE: Misuse or unauthorized modifications may void the warranty. If this equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be impaired.
WARNINGS:
Do not use the rotator near water sources. Be sure that water does not get on the device, especially during cleaning procedures.

Do not expose the rotator to aggressive solvents.

Hazardous samples should be mixed only in appropriate containment vessels.

Do not mix flammable or explosive samples.

4 .0 Technical Specifications
Motion
Accessories Included
Speed
H5500
H5500-230V
Dimensions (W x D x H)
Weight
Electrical
H5500
H5500-230V
Temperature Range
Protection Class
The Labnet Mini LabRoller Rotator is designed to be safe at least when operated under the following conditions:
Indoor use only

Altitude up to 2,000 meters

Pollution degree 2

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in
a commercial environment. The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the user manual, may cause harmful interference to radio communications. Operation of equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference.
Rotating
Rotisserie for 36 x 1.5/2.0 mL microcentrifuge tubes (Cat. No. H5500-02)
24 rpm
20 rpm
8.4 x 4 x 5 in. (21.3 x 10.2 x 12.6 cm)
1.8 lbs. (0.8 kg)
120V~, 60 Hz, 0.03A, 3.6W
230V~, 50/60 Hz, 0.017A, 4W
5°C to 40°C (up to 80% RH at 31°C, decreasing linearly to 50% RH at 40°C)
IP21
Instruction Manual | 1
