Page 1 MARINE RADAR MODEL1722/1732/1742/1752/1762 MODEL1722C/1732C/1742C/1752C/1762C MODEL1723C/1733C/1753C/1763C...
Page 2 9-52 Ashihara-cho, 9-52 Ashihara-cho, Nishinomiya, Japan Nishinomiya, Japan Telephone : Telephone : 0798-65-2111 0798-65-2111 0798-65-4200 0798-65-4200 Printed in Japan Printed in Japan All rights reserved. All rights reserved. PUB.No. OME-34940 PUB.No. OME-34940 ( ( HIMA HIMA ) ) MODEL1722/C SER. MODEL1722/C SER.
Page 3 Immediately turn off the power at the switchboard if the equipment is emitting smoke or fire. Continued use of the equipment can cause fire or electrical shock. Contact a FURUNO agent for service. Keep heater away from equipment. A heater can melt the equipment's power cord, which can cause fire or electrical shock.
Page 4: Table Of Contents
TABLE OF CONTENTS FOREWORD ... viii SYSTEM CONFIGURATIONS ... x WHAT IS WAAS?... xii 1. OPERATIONAL OVERVIEW ... 1-1 1.1 Operating Controls ... 1-2 1.1.1 Display unit controls ... 1-2 1.1.2 Remote controller ... 1-5 1.2 Inserting a Chart Card ... 1-6 1.3 Turning the Unit On/Off...
Page 5 2.9 Presentation Mode ... 2-9 2.9.1 Selecting a presentation mode... 2-9 2.9.2 Description of presentation modes ... 2-10 2.10 Measuring the Range... 2-12 2.10.1 Measuring range by range rings... 2-12 2.10.2 Measuring range by cursor... 2-13 2.10.3 Measuring range by VRM ... 2-14 2.10.4 Erasing a VRM, VRM indication ...
Page 6 3.4 Chart Scale... 3-9 3.5 Chart Cards ... 3-10 3.5.1 Chart card overview... 3-10 3.5.2 Indices and chart enlargement...3-11 3.5.3 FURUNO and NavCharts™... 3-12 3.5.4 C-MAP cards ... 3-14 3.6 Working with Track ... 3-18 3.6.1 Displaying track ... 3-18 3.6.2 Stopping, restating plotting of own ship track ...
Page 7 3.8.3 Erasing waypoints... 3-34 3.8.4 Changing waypoint mark size (FURUNO, NavCharts™)... 3-35 3.8.5 Searching waypoints... 3-36 3.9 Routes ... 3-37 3.9.1 Creating routes ... 3-37 3.9.2 Connecting routes... 3-41 3.9.3 Inserting waypoints ... 3-42 3.9.4 Removing waypoints from a route... 3-44 3.9.5 Erasing routes...
Page 8 5.3.1 Navigation options... 5-9 5.3.2 Function key setup ... 5-10 5.4 Chart Setup ... 5-12 5.4.1 Chart offset... 5-12 5.4.2 FURUNO, Nav-Charts™ chart attributes ... 5-13 5.4.3 C-MAP chart attributes ... 5-16 5.5 Data Boxes Setup... 5-20 5.6 Hot Page Setup ... 5-21 5.7 Navigator Setup...
Page 9 6. DATA TRANSFER ... 6-1 6.1 Memory Card Operations... 6-1 6.1.1 Formatting memory cards ... 6-1 6.1.2 Saving data to a memory card ... 6-2 6.1.3 Playing back data from a memory card ... 6-4 6.2 Uploading, Downloading Data... 6-5 6.2.1 Setting communication software on the PC...
Page 10: Foreword
FURUNO Electric Company thanks you for purchasing the MODEL1722/1722C/1723C Series Marine Radar. We are confident you will discover why the FURUNO name has become synonymous with quality and reliability. For over 50 years FURUNO Electric Company has enjoyed an enviable reputation for quality and reliability throughout the world.
Page 11 MODEL1723C series: High-precision color LCD ! User friendly operation with combination of discrete keys, soft keys and cursor pad. ! Accepts FURUNO and Nav-charts™ (NAVIONICS) or C-MAP NT/NT+ charts (C-MAP). All names mentioned are registered trademarks of their respective companies.
Page 12: System Configurations
SYSTEM CONFIGURATIONS All NavNet products incorporate a “network circuit board” to integrate each NavNet product on board through an optional LAN cable (Ethernet 10BASE-T). Each NavNet product is assigned an IP address to enable transfer of images between other NavNet products. For example, video plotter pictures can be transferred to a radar and vice versa.
Page 13 Two-unit NavNet system Antenna Unit Radar data Two-unit NavNet system Three-or more unit NavNet system (Max. 4 NavNet capable display units) Antenna Unit Radar data Sounder data Network Sounder ETR-6/10N ETR-30N (option) Three-or more unit NavNet system SYSTEM CONFIGURATIONS GP-310B/320B Plotter data GP-310B/320B Plotter data...
Page 14: What Is Waas
During this developmental period, which may last for several years, there is no guarantee of the accuracy, integrity, continuity, or availability of the SBAS signal. Furuno will accept no responsibility for the use of the signal for other than the above stated purpose. It is the user’s responsibility to exercise common prudence and navigational judgment while using the SBAS signal.
Page 15: Operational Overview
OPERATIONAL OVERVIEW This chapter provides basic information needed to get you started using your radar. The follow topics are presented: Control overview Chart card insertion Power on/off Contrast, brilliance and hue (Color series only) adjustments Display selection Data boxes Function keys Simulation display The brilliance of the LCD is adjustable to match a wide variety of lighting...
Page 16: Operating Controls
1. OPERATIONAL OVERVIEW Operating Controls 1.1.1 Display unit controls Overview of display unit controls The radar systems are mainly operated with controls of the display unit (and remote controller). Ten keys are labeled and they provide the function shown on their labels.
Page 17 Soft keys The five soft keys’ functions change according to the operation. Their labels for their current functions are shown on the screen to the left of the keys. To hide or show the soft key labels, press the [HIDE/SHOW] key. Each press of the key shows preset soft keys, user function keys or turns off navigation information (at the top of the screen).
Page 18 1. OPERATIONAL OVERVIEW [ENTER] knob The [ENTER] knob functions to Register data Enter alphanumeric data such as waypoint name Select menu items and options Adjust setting Clockwise rotation of the knob selects an alphabet, symbol or numeric, in one of the sequences shown below.
Page 19: Remote Controller
1.1.2 Remote controller Function RANGE Same as RANGE key on display unit. DISP Same as DISP key on display unit. SAVE MOB Same as SAVE MOB key on display unit. Ten keys Enter alphanumerics. EBL/VRM Same as EBL/VRM key on display unit.
Page 20: Inserting A Chart Card
1. OPERATIONAL OVERVIEW Inserting a Chart Card Your unit reads FURUNO and Nav-Charts ™ (NAVIONICS), or C-MAP chart cards, depending on its specifications. Insert the appropriate chart card for your area as follows: 1. Open the chart card slot lid.
Page 21: Turning The Unit On/Off
“7.5 Diagnostics.” Chart List Host Name RADAR PLOTTER STATION NAME: RADAR FURUNO ELECTRIC CO., LTD. CHARTS AVAILABLE FLYBRDG = ANB01004 RADAR = ANB01003 Product information The magnetron in the antenna unit takes about one minutes and thirty seconds to warm up before the radar can be operated.
Page 22: Cursor Pad, Cursor
1. OPERATIONAL OVERVIEW Cursor Pad, Cursor The cursor pad mainly functions to shift the cursor, for measurement of range and bearing to a location (radar) and latitude and longitude position (plotter). Operate the cursor pad to shift the cursor. The cursor moves in the direction of the arrow or diagonal pressed, on the cursor pad.
Page 23: Display Brilliance, Panel Brilliance, Contrast, Hue
Display Brilliance, Panel Brilliance, Contrast, You can adjust display brilliance, panel brilliance, contrast and hue (MODEL1722C/1723C series only) as shown below. 1.5.1 Display brilliance, panel brilliance 1. Press the [POWER/BRILL] key momentarily. A set of soft keys for adjustment of brilliance, contrast and hue (MODEL1722C/1723C series only) appear.
Page 24: Contrast
1. OPERATIONAL OVERVIEW 1.5.2 Contrast 1. Press the [POWER/BRILL] key momentarily. 2. Press the CONTST (monochrome) or CONTST/HUE (color) soft key. 3. For MODEL1722C/1723C series, two soft keys appear at the pressing of the CONTST/HUE soft key: CONTST and HUE. Press the CONTST soft key to adjust the contrast.
Page 25: Selecting A Display
Selecting a Display 1.6.1 Display modes If you have a navigator and network sounder connected, four full-screen displays are available: radar, plotter, and video sounder and navigation data. (MODEL1722C/1723C series have five screens, those mentioned above plus the overlay screen.) In addition to the full-screen display, you can divide the screen into half-screen combination displays to show two sets of images (data).
Page 26 1. OPERATIONAL OVERVIEW 1.6.2 Selecting a display 1. Press the [DISP] key to show the full-screen selection window. The icons of modes not available are marked with “X” mark. PAGE1-PAGE5 are user-arrangeable displays called “hot pages,” which you can configure as you like.
Page 27: Switching Control In Combination And Overlay Screens
1.6.3 Switching control in combination and overlay screens A soft key is provided in relevant combination and overlay screens (color series only) to switch control between displays. In the example below, the RADAR CNTRL and PLOTTR CNTRL soft keys enable switching control between the radar and plotter screens in the plotter/radar combination display.
Page 28: Selecting Radar Source
1. OPERATIONAL OVERVIEW 1.6.4 Selecting radar source When other network radar is connected to the equipment, you may select an image source as shown below. This is not necessary when no other network radar is connected. Select one host name for the source though there are two or three radar units on the net.
Page 29: Data Boxes
Data Boxes Data boxes, providing navigation data, may be shown on any full-screen display. Up to six data boxes (two in case of large characters) may be shown, and the default data boxes are position (in latitude and longitude), course over ground, speed over ground, trip log and cursor position.
Page 30: Function Keys
1. OPERATIONAL OVERVIEW Function Keys The function keys provide for one-touch call up of a desired function. The default function key settings are as shown in the table below. Function Default Setting, Key Label Radar Heading line on/off, Rings on/off, RNG Echo trail, TRL Offcenter, SFT Radar source, RSR...
Page 31: Simulation Display
Simulation Display The simulation display, for use by service technicians for demonstration purposes, provides simulated operation to help acquaint you with the many features your unit has to offer. It allows you to view and control a simulated plotter, radar and sounder picture, without position-fixing equipment, network radar or a network sounder.
Page 32 1. OPERATIONAL OVERVIEW Antenna unit-generated echoes 1. Select RADAR SIMULATION DATA, then press the EDIT soft key. 2. Select YES and push the [ENTER] knob to erase simulation data and get new data. The message “Now getting demo data. Do not turn off display unit.”...
Page 33 Sounder 1. Select SOUNDER, then press the EDIT soft key. 2. Select SIMULATION 1 (internally generated echoes) or SIMULATION 2 (network sounder-generated echoes), then press the [ENTER] knob. Note: The depth, shift, bottom-zoom, bottom-lock and bottom discrimination displays cannot be shown at SIMULATION 1 mode. 3.
Page 34 1. OPERATIONAL OVERVIEW This page is intentionally left blank. 1-20...
Page 35: Radar Operation
RADAR OPERATION This chapter covers radar operation, including the ARP (Automatic Radar Plotting) function. ARP requires connection of MODEL1833/1833C series network radar equipped with the ARP circuit board. Radar Display Pulselength Range/ .125nm range ring .250 interval Presentation mode Alarm icon Battery icon Zoom area Guard zone 1...
Page 36: Transmitting, Stand-By
2. RADAR OPERATION Transmitting, Stand-by 1. Turn the power on. The products information appears and is then followed by the radar screen. You can display the radar screen at once by pressing the any key. 2. Press the [POWER/BRILL] key momentarily. 3.
Page 37 To adjust the receiver gain, transmit on long range, and then do the following: 1. Press the [GAIN] key. The last-used “adjustment window” is displayed. In the example below, the gain sensitivity adjustment is shown. Item selected for adjustment is highlighted. .250/ 319.9 .125nm...
Page 38: Reducing Sea Clutter
2. RADAR OPERATION Reducing Sea Clutter 2.5.1 How the A/C SEA works Echoes from waves can be troublesome, covering the central part of the display with random signals known as “sea clutter”. The higher the waves and the higher the antenna is above the water, the further the clutter will extend. Sea clutter may affect radar performance because real targets are sometimes hidden by the echoes of small waves.
Page 39: Reducing Precipitation Clutter
5. When the radar source is the Model 1833/C series radar, A/C SEA and A/C RAIN can be automatically adjusted. Press the A/C AT soft key to select ON or OFF as appropriate. When turned on, it overrides A/C SEA and A/C RAIN settings.
Page 40: Adjusting The Ftc
2. RADAR OPERATION 2.6.2 Adjusting the FTC To suppress rain clutter from heavy storms or scattered rain clutter, adjust the FTC. The FTC splits up these unwanted echoes into a speckled pattern, making recognition of solid targets easier. Note: In addition to reducing clutter, the FTC can be used in fine weather to clarify the picture when navigating in confined waters.
Page 41: Range Scale
Range Scale The range setting determines the size of the area (in nautical miles) that will appear on your display. in addition, the range setting will also automatically adjust the range ring interval so that accurate range measurements may be made while operating on any range setting.
Page 42: Pulselength
2. RADAR OPERATION Pulselength The pulselength in use is displayed at the upper left corner of the display. Appropriate pulselengths are preset to individual range scales. Therefore, you are not usually required to select them. If you are not satisfied with the current pulselength setting, however, it is possible to change it for the 1.5 and 3 nm (sm) ranges (3 and 6 kilometer ranges) as below.
Page 43: Presentation Mode
Presentation Mode This unit provides four radar presentation modes: head-up, course-up, north-up and true motion. Heading data is required for modes other than head-up. (When you use the network radar, input the radar source.) 2.9.1 Selecting a presentation mode 1. Press [HIDE/SHOW] key to show the radar soft keys. 2.
Page 44: Description Of Presentation Modes
2. RADAR OPERATION 2.9.2 Description of presentation modes Head-up A display without azimuth stabilization in which the line connecting the center with the top of the display indicates own ship’s heading. The targets are painted at their measured distances and in their directions relative to own ship’s heading. The short line on the bearing scale is the north marker.
Page 45 2. RADAR OPERATION North-up In the north-up mode, targets are painted at their measured distances and in their true (compass) directions from own ship. North is maintained at the top of the screen. The heading line changes its direction according to the ship’s heading.
Page 46: Measuring The Range
2. RADAR OPERATION 2.10 Measuring the Range You can measure the range to a radar target three ways: by the range rings, by the cursor, and by the VRM (Variable Range Marker). 2.10.1 Measuring range by range rings Count the number of rings between the center of the display and the target. Check the range ring interval and judge the distance of the echo from the inner edge of the nearest ring.
Page 47: Measuring Range By Cursor
2.10.2 Measuring range by cursor Operate the cursor pad to place the cursor intersection on the inside edge of the radar target. The range to the target, as well as the bearing, appears to the right of “+” at the bottom of the display. How to measure range and bearing to a target with the cursor Target .125nm...
Page 48: Measuring Range By Vrm
2. RADAR OPERATION 2.10.3 Measuring range by VRM 1. Press the [EBL/VRM] key to display the EBL/VRM soft keys. 2. Press the VRM1 ON (dotted ring VRM) or VRM2 ON (dashed ring VRM) soft key to select the desired VRM. The selected VRM’s indication, at the bottom of the screen, is highlighted.
Page 49: Erasing A Vrm, Vrm Indication
2.10.4 Erasing a VRM, VRM indication Press appropriate VRM soft key and press the [CLEAR] key. The VRM is erased, and its indication becomes blank. 2.10.5 Erasing EBL/VRM data boxes Press the EBL or VRM soft key associated with the EBL/VRM data box you wish to erase.
Page 50: Erasing An Ebl, Ebl Indication
2. RADAR OPERATION (Dotted line) (Dashed line) EBL2 bearing EBL1 bearing R: Relative Note: Bearing can be shown Relative to ship’s heading (relative) or in reference to North (True). This setting may be changed by changing the EBL REFERENCE setting, which is in the RADAR DISPLAY SETUP menu. See the paragraph “5.2.1 Radar display setup.”...
Page 51: Erasing The Heading Line, North Marker
2.12 Erasing the Heading Line, North Marker The heading line indicates the ship's heading in all presentation modes. The heading line is a line from the own ship position to the outer edge of the radar display area and appears at zero degrees on the bearing scale in head-up mode;...
Page 52: Reducing Radar Interference
2. RADAR OPERATION 2.14 Reducing Radar Interference Radar interference may occur when near another shipborne radar that is operating in the same frequency band as your radar. Its on-screen appearance looks like many bright dots either scattered at random or in the form of dotted lines extending from the center to the edge of the display.
Page 53: Zoom
2.15 Zoom The zoom feature allows you to double the size of the area selected with the zoom circle, which appears at the bottom right- or left-hand corner on the display. The zoom feature is available on any range but is inoperative in true motion and when the display is shifted.
Page 54: Shifting The Picture
2. RADAR OPERATION 1. If not displayed, press the [HIDE/SHOW] key to show the radar soft keys. 2. Press the ZOOM/D.BOX soft key to show ZOOM D.BOX soft keys. 3. Press the ZOOM soft key to select ZOOM ON. 4. Press the ARP TGT ZM soft key. 5.
Page 55: Automatic Shift
2.16.2 Automatic shift In the head-up mode, the amount of shift is automatically calculated with speed. The maximum shift amount is limited to 60% of the range in use. For example, if you set the shift speed setting for 15 knots and the ship is running at 10 knots, the amount of shift will be 40%.
Page 56: Using The Offset Ebl
2. RADAR OPERATION 2.17 Using the Offset EBL The offset EBL can be used to predict a potential collision course, and can also be used to measure the range and bearing between two targets. 2.17.1 Predicting a collision course The procedure below may be used to check if a radar target is on a collision course with your vessel.
Page 57: Measuring Range & Bearing Between Two Targets
2.17.2 Measuring range & bearing between two targets The procedure which follows shows how to measure the range and bearing between two targets, using the targets “A” and “B” in the figure below as an example. 1. Operate the cursor pad to place the cursor on the target “A”. 2.
Page 58: Echo Trails
2. RADAR OPERATION 2.18 Echo Trails Echo trails are simulated afterglow of target echoes that represent their past movements relative to own ship. This function is useful for alerting you past possible collision situations. 2.18.1 Trail time 1. If not displayed, press the [HIDE/SHOW] key to show the radar soft keys. 2.
Page 59: Starting Echo Trails
5. Use the cursor pad to select time desired. 6. Press the ENTER soft key to finish. 2.18.2 Starting echo trails 1. If not displayed, press the [HIDE/SHOW] key to display the radar soft keys. 2. Press the TARGET and TRAIL soft keys. 3.
Page 60: Trail Color (Model1722C/1723C Series)
2. RADAR OPERATION 2.18.5 Trail color (MODEL1722C/1723C series) The MODEL1722C/1723C series may be shown echo trails in blue, yellow, green or white. 1. If not displayed, press the [HIDE/SHOW] key to display the radar soft keys. 2. Press the TARGET, TRAIL and TRAIL COLOR soft keys. 3.
Page 61: Echo Stretch
2.19 Echo Stretch Normally, the reflected echoes from long range targets appear on the display as weaker and smaller blips even though they are compensated by the radar’s internal circuitry. The echo stretch function magnifies these small blips in all ranges.
Page 62: Echo Averaging
2. RADAR OPERATION 2.20 Echo Averaging The echo average feature, available with selection of a Model 1833/C series network radar as radar source, effectively suppresses sea clutter. Echoes received from stable targets such as ships appear on the screen at almost the same position during every rotation of the antenna.
Page 63: Outputting Tll Data
2.21 Outputting TLL Data Target position data can be output to units of the network and shown on their plotter screen, with the waypoint mark. This function requires position and heading data. 1. If not displayed, press the [HIDE/SHOW] key to display the radar soft keys. 2.
Page 64: Guard Alarm
2. RADAR OPERATION 2.22 Guard Alarm The guard alarm allows the operator to set the desired range and bearing for a guard zone. When ships, islands, landmasses, etc. violate the guard zone, an audio alarm sounds and the offending target blinks to call the operator’s attention.
Page 65: When The Alarm Is Violated
The equipment then searches for targets inside the guard zone to determine the guard alarm type. If a target is found inside the guard zone the guard zone type becomes an “Outward guard alarm”, and any target exiting, the guard zone will trigger an alarm.
Page 66: Watchman
2. RADAR OPERATION 2.23 Watchman 2.23.1 How watchman works The watchman function periodically transmits radar pulses for one minute to check for targets in a guard zone. If a target is found in the zone, watchman is cancelled, the audio alarm sounds and the radar continues transmitting. If no target is found the radar goes into standby, for the number of minutes selected on the RADAR DISPLAY SETUP menu.
Page 67: Waypoint Marker
2.24 Waypoint Marker A waypoint marker, showing waypoint position output from a navigation device, may be inscribed on the radar display. You may show or hide this marker as desired. 1. If not displayed, press the [HIDE/SHOW] key to display the radar soft keys. 2.
Page 68: Arp (Option), Ttm Operation
10 targets. Once a target is acquired automatically or manually it is automatically tracked within 0.1 to 32 nm. When the FURUNO heading sensor PG-1000 is connected, RMC sentence (NMEA) is required for true heading data.
Page 69: Activating/Deactivating Arp, Ttm
2.25.1 Activating/deactivating ARP, TTM 1. Press the [MENU] key followed by the ARP SETUP soft key to show the ARP SETUP menu. 2. Select ARP TARGET INFO, and then press the EDIT soft key to show the ARP target info window. 3.
Page 70: Acquiring And Tracking Targets (Arp Only)
2. RADAR OPERATION 2.25.2 Acquiring and tracking targets (ARP only) Ten targets may be acquired and tracked manually and automatically. When you attempt to acquire an eleventh target, the message “ARP FULL – ALREADY TRACKING 10 TARGETS!” appears for five seconds. To acquire another target, terminate tracking of an unnecessary target as shown in the paragraph 2.25.4.
Page 71: Displaying Target Number (Internal, External Arp)
7. Press the [MENU] key to close the menu. An acquisition area of 2.0 to 2.5 miles in range and ±45º on either side of the heading line in bearing appears. Note: Targets being tracked in automatic acquisition are continuously tracked when switching to manual acquisition.
Page 72: Terminating Tracking Of Arp Targets
2. RADAR OPERATION 2.25.4 Terminating tracking of ARP targets When 10 targets have been acquired, no more targets may be acquired unless targets are cancelled. If you need to acquire additional targets, you must first cancel one or more individual targets, or all of the targets, using one of the procedures below.
Page 73: Setting Vector Attributes (Arp)
2.25.5 Setting vector attributes (ARP) What is a vector? A vector is a line extending from a tracked target which shows speed and course of the target. The vector tip shows an estimated position of the target after the selected vector time elapses. It can be useful to extend the vector length in order to evaluate the risk of collision with any target.
Page 74: Displaying Past Position Display (Arp)
2. RADAR OPERATION 2.25.6 Displaying past position display (ARP) This ARP can display time-spaced dots (maximum 10 dots) marking the past positions of any targets being tracked. You can evaluate a target’s actions by the spacing between dots. Below are examples of dot spacing and target movement. To turn the past position display on or off: 1.
Page 75: Arp, Ttm Target Data
2.25.7 ARP, TTM target data This ARP calculates motion trends (range, bearing, course, speed, CPA and TCPA) of all target been tracked. You can show this data for a tracked target as below. TARGET ID NUMBER, in the ARP SETUP menu, must be turned on to show ARP target data.
Page 76: Cpa/Tcpa Alarm (Arp)
2. RADAR OPERATION 2.25.8 CPA/TCPA alarm (ARP) When the predicted CPA of any target becomes smaller than a preset CPA alarm range or its predicted TCPA less than a preset TCPA alarm limit, an audio alarm sounds, which you may silence with the [CLEAR] key. In addition, the target plot symbol of the offending target changes to a triangle and flashes together with its vector.
Page 77: Lost Target Alarm (Arp)
8. Select a TCPA limit. 9. Press the ENTER soft key. 10. Press the [MENU] key to close the menu. 2.25.9 Lost target alarm (ARP) When the system detects a lost target, the target symbol becomes a diamond and tracking is discontinued after one minute. Canceling a lost target 1.
Page 78: Interpreting The Radar Display
2. RADAR OPERATION 2.26 Interpreting the Radar Display 2.26.1 General Minimum and maximum ranges Minimum range The minimum range is defined by the shortest distance at which, using a scale of 1.5 or 0.75 nm, a target having an echoing area of 10 m from the point representing the antenna position.
Page 79 2. RADAR OPERATION Radar resolution There are two important factors in radar resolution (discrimination): bearing resolution and range resolution. Bearing resolution Bearing resolution is the ability of the radar to display the echoes received from two targets, which are at the same range and close together, as separate targets.
Page 80: False Echoes
2. RADAR OPERATION 2.26.2 False echoes Occasionally echo signals appear on the screen at positions where there is no target, or disappear even if there are targets. False target situations may be recognized, however, if you understand why they are displayed. Typical false echoes are shown below.
Page 81 Virtual image A relatively large target close to your ship may be shown at two positions on the screen. One of them is the true echo directly reflected by the target and the other is a false echo which is caused by the mirror effect of a large object on or close to your ship as shown in the figure below.
Page 82: Sart (Search And Rescue Transponder)
2. RADAR OPERATION 2.26.3 SART (Search and Rescue Transponder) A Search and Rescue Transponder (SART) may be triggered by any X-Band (3 cm) radar within a range of approximately 8 nm. Each radar pulse received causes it to transmit a response which is swept repetitively across the complete radar frequency band.
Page 83 2. RADAR OPERATION General procedure for detecting SART response 1. Use the range scale of 6 or 12 nm as the spacing between the SART responses is about 0.6 nm (1125 m) to distinguish the SART. 2. Turn off the automatic clutter suppression (if applicable). 3.
Page 84: Racon (Radar Beacon)
Some sets have automatic/manual anti-clutter rain control facilities in which case the operator should switch to manual. Note: This SART information is excerpted from IMO SN/Circ 197 Operation of Marine Radar for SART Detection. 2.26.4 Racon (Radar Beacon) A racon is a radar transponder which emits a characteristic signal when triggered by a ship’s radar (usually only the 3 centimeter band).
Page 85: Plotter Operation
PLOTTER OPERATION 3.1 Plotter Displays You may show the plotter display over the entire screen, in the overlay screen (MODEL1722C/1723C series), or in a combination screen. Press the [DISP] key to show the screen selection window, and then rotate the [ENTER] knob to select PLOT, NAV or OVRLY (overlay) as appropriate.
Page 86 3. PLOTTER OPERATION Nav data window The data shown in the nav data window depends on the status of the NAV soft key and the cursor. Latitude and longitude of cursor intersection Waypoint data (waypoint selected with cursor) Own ship position soft key Destination...
Page 87: Compass Display
3.1.2 Compass display The compass display, displayed at the bottom half of the screen in the combination display, provides steering information. The compass rose shows two triangles: the black triangle (hollow on monochrome model) shows the bearing to destination waypoint and the red (solid on monochrome) triangle, which moves with ship’s course, shows own ship’s course.
Page 88 3. PLOTTER OPERATION Reading the XTE (cross-track error) monitor The XTE monitor, located below the compass rose, shows the amount you are off course and the direction to steer to return to course. The own ship marker shows the direction and amount your ship is off course. It is shown in black when the amount of cross-track error is within the XTE monitor range and yellow when it is over.
Page 89: Highway Display
3.1.3 Highway display The highway display, displayed at the lower half of the screen in the combination display, provides a graphic presentation of ship’s track along intended course. It is useful for monitoring ship’s progress toward a waypoint. The own ship marker shows relation between ship and intended course.
Page 90: Nav Data Display
3. PLOTTER OPERATION 3.1.4 Nav data display The nav data display provides comprehensive navigation data. The user may select what data to display and where to display it, on the NAV DATA DISPLAY SETUP menu. For details see paragraph “5.8 Nav Data Display Setup.” Appropriate sensors are required.
Page 91: Presentation Mode
Presentation Mode Three types of presentation modes are provided for the plotter display: north-up, course-up and auto course-up. To change the presentation mode, first press the [HIDE/SHOW] key if the plotter soft keys are not displayed. Press the MODE soft key to select desired mode.
Page 92: Course-Up
3. PLOTTER OPERATION 3.2.2 Course-up The destination is at the top of the screen when a destination is set. When no destination is set, the course or heading is at the top of the screen at the moment the course-up mode is selected. A filled triangle marks own ship’s position.
Page 93: Shifting The Display
Shifting the Display The plotter display can be shifted on the plotter display as below. 1. Press the cursor pad to display the cursor. 2. Locate the cursor at a screen edge and press and hold down the cursor pad. The screen shifts in the direction opposite of cursor location.
Page 94: Chart Cards
Chart Cards 3.5.1 Chart card overview Your system reads FURUNO and NavCharts ™ (NAVIONICS) charts, or C-MAP charts, depending on its specification. When you insert a suitable chart card in the slot and your boat is near any chart graphic data, a chart appears. If a wrong card is inserted or a wrong chart scale is selected, land masses will appear hollow.
Page 95: Indices And Chart Enlargement
When this happens, select proper chart scale. Note: Indices can be turned on or off with “Chart border line.” See page 5-13 for FURUNO and NAVIONICS charts and 5-16 for C-MAP charts. Sample chart (Japan) showing indices 3. PLOTTER OPERATION...
Page 96: Furuno And Navcharts
3. PLOTTER OPERATION 3.5.3 FURUNO and NavCharts Chart symbols The table below shows FURUNO and NavCharts ™ mini chart symbols and their meanings. Symbol Data for aids to navigation Selected FURUNO and NavCharts ™ charts can show buoy and lighthouse data.
Page 97 Port service icons (NavCharts ™ only) NavCharts ™ show services available at ports, with icons. Use the cursor pad to place the cursor on the sailboat icon (denotes a port or harbor), and then push the [ENTER] knob. The services available appear at the top of the display. Detailed information of service selected List of services...
Page 98: C-Map Cards
3. PLOTTER OPERATION 3.5.4 C-MAP cards Cursor and data display Besides its fundamental functions of providing position data, the cursor can also show caution area, depth area, source of data, etc. on C-map charts. In addition, you can display information about an icon by placing the cursor on it. 1.
Page 99 Icon data You may place the cursor on any icon to find information about the selected icon. 1. For example, place the cursor on a lighthouse icon. Place the cursor on a lighthouse icon. 080 22. 3456'E 16.0nm 2. Push the [ENTER] knob to show data. For example, the following window appears for a lighthouse.
Page 100 3. PLOTTER OPERATION 5. Press the RETURN soft key twice to close the Objects window. Tide information The C-MAP chart card provides for calculation of the tide heights for any date. Additionally it displays the times of sunrise and sunset. 1.
Page 101 Horizontal Cursor Vertical Cursor 5. Press the DATE soft key to open the DATE window. 6. Use ◄ or ► to position the cursor where desired and then rotate the [ENTER] knob to set. Repeat to enter complete date. 7. Push the [ENTER] knob to show the tidal graph for entered date. 8.
Page 102: Working With Track
3. PLOTTER OPERATION Working with Track Your ship’s track is plotted on the screen using navigation data fed from a navigation receiver. This section shows you what you can do with track, from turning it on or off to changing its plotting interval. Own ship’s track is displayed in the default setting and on the color model it is red.
Page 103: Stopping, Restating Plotting Of Own Ship Track
Target track Target track, NMEA format TTM data sentence (target data fed from an ARP board-equipped MODEL1833/1833C series network radar), may be turned on or off as desired. The default setting is ON. 1. Press the [MENU] key followed by the CHART SETUP and TRACKS & MARKS CONTROL soft keys to open the TRACK CONTROL menu.
Page 104: Changing Track Color (Model1722C/1723C Series)
3. PLOTTER OPERATION 3.6.3 Changing track color (MODEL1722C/1723C series) Track can be displayed in red (default setting), yellow, green, light-blue, purple, blue and white. It can be useful to change track color on a regular basis to discriminate between previous day’s track, etc. Own ship’s track 1.
Page 105: Track Plotting Method And Interval For Own Ship Track
3.6.4 Track plotting method and interval for own ship track In drawing the own ship track, first the ship’s position fed from a navigation receiver is stored into the unit’s memory at an interval of time or distance. A shorter interval provides for better reconstruction of the track, but the storage time of the track is reduced.
Page 106: Changing Own Ship Track/Mark Distribution Setting
3. PLOTTER OPERATION 4. Use the [ENTER] knob and the cursor pad to enter numeric data. The [CLEAR] key functions to clear an entire line of data. 5. Push the [ENTER] knob or ENTER soft key. 6. Press the [MENU] key to close the menu. 3.6.5 Changing own ship track/mark distribution setting The equipment stores a total of 8000 points of track and marks.
Page 107: Erasing Track
3.6.6 Erasing track This paragraph shows you how to erase own ship’s track and target tracks. You can erase ship’s track three ways: collectively, by color (color model only) and by area. Erasing own ship track by area You can erase own ship’s track by area as below. This function is not available on the overlay display (MODEL1722C/1723C series).
Page 108 3. PLOTTER OPERATION Erasing own ship track by color (color model) You may erase own ship’s track by color as follows: 1. Press the [MENU] key followed by the CHART SETUP, TRACKS & MARKS CONTROL and ERASE T & M soft keys to show the ERASE menu. 2.
Page 109: Marks, Lines
Marks, Lines Marks are useful for denoting important points such as a good fishing spot. Marks can be inscribed in seven shapes and seven colors (MODEL1722C /1723C series): Red, yellow, green, light-blue, purple, blue and white. 3.7.1 Entering a mark 1.
Page 110: Selecting Line Type
3. PLOTTER OPERATION 4. Select MARKS SHAPE and press the EDIT soft key. 5. Use the cursor pad to select mark shape desired and then press the ENTER soft key. 6. Select MARKS SIZE and press the EDIT soft key. 7.
Page 111: Erasing Marks, Lines
3. Use the cursor pad to select line style desired and press the ENTER soft key. Line style “dot” disables line drawing. The edge of lines is determined by mark shape. For example, selecting the circle shape will join lines with a circle as below.
Page 112 3. PLOTTER OPERATION Erasing all marks, lines You can erase all marks and lines. Be absolutely sure you want to erase all marks and lines - erased marks and lines cannot be restored. 1. Press the [MENU] key followed by the CHART SETUP, TRACKS & MARKS CONTROL and ERASE T &...
Page 113: Waypoints
Waypoints In navigation terminology, a waypoint is a particular location on a voyage whether it be a starting, intermediate or destination point. A waypoint is the simplest piece of information your equipment requires to get you to a destination, in the shortest distance possible. This unit has 999 waypoints into which you can enter position information.
Page 114 3. PLOTTER OPERATION 8. Operate the cursor pad to select shape desired. 9. Press the ENTER soft key. 10. For the MODEL1722C/1723C series, press the SELECT MARK and MARK COLOR soft keys in that order to open the waypoint mark color selection window.
Page 115 12. Press the SAVE soft key to register the waypoint. 13. Enter another waypoint with the cursor, or press the [MENU] key to close the menu. Entering a waypoint by range and bearing This method is useful when you want to enter a waypoint using range and bearing to a target found on a radar.
Page 116: Editing Waypoint Data
3. PLOTTER OPERATION Entering a waypoint from the waypoint list You can manually enter waypoint position from the waypoint list as follows: 1. Press the [MENU] key to open the menu. 2. Press the WAYPOINTS/ROUTES and WAYPOINTS soft keys. 3. Press the LOCAL LIST (lists waypoints in order from nearest to furthest) or ALPHANUMERIC LIST (lists waypoints in alphanumeric order) soft key.
Page 117 Editing a waypoint from the plotter display You may change/edit waypoints from the plotter display as follows: 1. Press the [MENU] key followed by the WAYPOINTS/ROUTES and WAYPOINTS soft key to open the waypoint menu. 2. Press the WAYPOINT BY CURSOR soft key. 3.
Page 118: Erasing Waypoints
3. PLOTTER OPERATION 3.8.3 Erasing waypoints Erasing a waypoint with the cursor 1. Press the cursor pad to turn on the cursor. 2. Operate the cursor pad to place the cursor on the waypoint you want to erase. A flashing diamond mark appears over the waypoint when the waypoint is correctly selected.
Page 119: Changing Waypoint Mark Size (Furuno, Navcharts™)
3.8.4 Changing waypoint mark size (FURUNO, NavCharts™) You may change the size of all waypoint marks to small or large (default), or you may turn them off. 1. Press the [MENU] key to open the menu. 2. Press the CHART SETUP and CHART DETAILS soft keys.
Page 120: Searching Waypoints
3. PLOTTER OPERATION 3.8.5 Searching waypoints You can search for a waypoint through the alphanumeric list as follows: 1. Press the [MENU] key. 2. Press the WAYPOINTS/ROUTES, WAYPOINTS and ALPHANUMERIC LIST soft keys to show the alphanumeric list. 3. Use the cursor pad and [ENTER] knob to enter up to three alphanumeric characters in the search window.
Page 121: Routes
Routes Often a trip from one place to another involves several course changes, requiring a series of route points (waypoints) which you navigate to, one after another. The sequence of waypoints leading to the ultimate destination is called a route. Your unit can automatically advance to the next waypoint on a route, so you do not have to change the destination waypoint repeatedly.
Page 122 3. PLOTTER OPERATION 5. If desired you can change the route name shown and/or add a comment. A route name may consist of six characters; comment, 13 characters. 6. Press the LOCAL LIST or ALPHA LIST soft key to open the waypoint list. 7.
Page 123 WAYPOINTS ROUTE 56.7 nm WAYPOINTS 21.1 nm WAYPOINTS 21.1 nm RETURN Save route menu ROUTE NAME COMMENT USE FURUNO BACK TRACK FUNCTION TO AUTOMATICALLY CREATE ROUTE BY TIME OR DISTANCE. Save route window SAVE ROUTE BCKTRK TIME BCKTRK DIST MANUAL...
Page 124 3. PLOTTER OPERATION 6. Choose how to record points for your route, by time, by distance or manual entry pressing by one of BCKTRK TIME, BCKTRK RANGE or MANUAL soft key as appropriate. For manual go to step 8. For BCKTRK TIME, BCKTRK DIST one of the following displays appears.
Page 125: Connecting Routes
3.9.2 Connecting routes Two routes which you have created can be connected as follows to form a new route. 1. Press the [MENU] key to open the menu. 2. Press the WAYPOINTS/ROUTES soft key. 3. Press the ROUTES soft key. 4.
Page 126: Inserting Waypoints
3. PLOTTER OPERATION 3.9.3 Inserting waypoints Waypoints can be inserted into a route as follows: Inserting waypoint from the route list 1. Press the [MENU] key to open the menu. 2. Press the WAYPOINTS/ROUTES soft key. 3. Press the ROUTES soft key. 4.
Page 127 9. Use the cursor pad to select the waypoint you want to insert. (You can switch between the local list and alphanumeric list by using the LOCAL LIST and ALPHA LIST soft keys.) When selecting INSERT WPT, this waypoint is inserted before the waypoint selected at step 7.
Page 128: Removing Waypoints From A Route
3. PLOTTER OPERATION 3.9.4 Removing waypoints from a route Removing a waypoint from the route list 1. Press the [MENU] key to open the menu. 2. Press the WAYPOINTS/ROUTES soft key. 3. Press the ROUTES soft key. 4. Select a route. 5.
Page 129: Navigation
3.10 Navigation This section shows you how to get to a desired destination by “quick points,” waypoints, port services and routes. Note: When the plotter data is received from other NavNet unit connected, reciprocal setting and canceling of destination is available by using ZDA sentenceReferring to “6.5 Outputting Data Through the Network”.
Page 130: Navigating To Waypoints
3. PLOTTER OPERATION Navigating to multiple quick points 1. Select “35 POINTS” following the procedure in “Selecting quick point entry method” on the previous page. 2. Press the GOTO soft key. 3. Place the cursor on an existing waypoint (SELECT WPT soft key appears) or a new location (ADD QP soft key appears).
Page 131: Navigating To Ports, Port Services (Navcharts™ C-Map)
Selecting an external waypoint You can select a waypoint (or route) entered at an external plotter connected with NMEA cable. This function requires RMB sentence. 1. Press the [MENU] key, PLOTTER SETUP soft key to show the PLOTTER SETUP menu. 2.
Page 132 3. PLOTTER OPERATION PORT & SERVICE ¤ ¡ ¡ ¡ Port services (NavChart ) 4. 4. If you selected PORT (NavCharts™ only) at step 3, use the trackball to select a port, then press the ENTER soft key. Make a route using the soft keys, then push the [ENTER] knob.
Page 133: Following A Route
3.10.4 Following a route Selecting the route to follow 1. Press the [MENU] key to open the menu. 2. Press the WAYPOINTS/ROUTES soft key. 3. Press the ROUTES soft key to open the route list. 4. Select a route. 5. Press the GOTO soft key to show the plotter display. The cursor is on the route waypoint nearest own ship.
Page 134 3. PLOTTER OPERATION Restarting navigation When you steer to avoid an obstacle or the vessel drifts, you may go off your intended course, as in Line 1 in the figure below. Also, if you don’t need to return to the original course, you can go directly to the next waypoint, as in Line 2 in the figure below.
Page 135 Setting speed for ETA calculation Speed, which may be input manually or automatically, is required to calculate ETA (Estimated Time of Arrival) to a waypoint. 1. Press the [MENU] key to open the menu. 2. Press the WAYPOINTS/ROUTES soft key. 3.
Page 136 3. PLOTTER OPERATION To select waypoint switching method do the following: 1. Press the [MENU] key. 2. Press the PLOTTER SETUP soft key. 3. Use the cursor pad to select WAYPOINT SWITCHING. 4. Press the EDIT soft key to show the waypoint switching window. 5.
Page 137: Alarms
3.11 Alarms When an alarm setting has been violated the buzzer sounds and the speaker icon appears (in red on the 1722C/1723C series). Press the [CLEAR] key to silence the alarm. You can see which alarm has been violated on the alarm menu display.
Page 138: Arrival Alarm
3. PLOTTER OPERATION 3.11.2 Arrival alarm The arrival alarm informs you that your boat is approaching a destination waypoint. The area that defines an arrival zone is that of a circle which you approach from the outside of the circle. The alarm will be released if your boat enters the circle.
Page 139: Anchor Watch Alarm
3.11.3 Anchor watch alarm The anchor watch alarm informs you that your boat is moving when it should be at rest. When the anchor watch is active, a dashed circle (red on the MODEL1722C/1723C series) with an “X” at its center marks the anchor watch area.
Page 140: Xte (Cross Track Error) Alarm
3. PLOTTER OPERATION 3.11.4 XTE (Cross Track Error) alarm The XTE alarm warns you when your boat is off its intended course. When the XTE alarm is active two dashed lines (red on the MODEL1722C/1723C series) mark the XTE alarm area. Own ship position Intended...
Page 141: Proximity Alarm
4. Use the cursor pad to select WITHIN, OVER/UNDER, or OFF. 5. For WITHIN and OVER/UNDER, use the cursor pad and [ENTER] knob to enter alarm range: Use ◄ or ► to select digit; rotate the [ENTER] knob to set value.
Page 142: Trip Alarm
3. PLOTTER OPERATION 3.11.7 Trip alarm The trip alarm informs you when you traveled a certain distance. 1. Press the [ALARM] key to open the alarm menu. 2. Use the cursor pad to select TRIP ALARM. 3. Press the EDIT soft key to show the trip alarm window. 4.
Page 143: Alarm Information
3.11.8 Alarm information When an alarm setting has been violated the buzzer sounds and the speaker icon appears (in red on the color model). Press the [CLEAR] key to silence the alarm. You can see which alarm has been violated on the alarm menu display. In the example below the arrival alarm has been violated.
Page 144: Resetting Trip Distance
3. PLOTTER OPERATION Alarm messages The table below shows the plotter alarm messages and their meanings Message ARRIVED AT XXX WAYPOINT! (XXX = waypoint number) ENTERED INTO AVOIDANCE AREA! EXCEEDED ANCHOR WATCH LIMIT! EXCEEDED XTE LIMIT! SPEED ALARM! TEMPERATURE ALARM! TRIP ALARM! MILEAGE EXCEEDED 3.12...
Page 145: Entering The Mob Mark, Setting Mob As Destination
3.13 Entering the MOB Mark, Setting MOB as Destination The MOB (Man Overboard) mark functions to mark man overboard position. You can inscribe this mark from any mode, except while playing back data or conducting a self-test. Note that this function requires position data. 1.
Page 146 3. PLOTTER OPERATION This page is intentionally left blank. 3-62...
Page 147: Video Sounder Operation
VIDEO SOUNDER OPERATION With connection of the optional network sounder you can show video sounder images on the display. Principle of Operation The video sounder determines the distance between its transducer and underwater objects such as fish, lake bottom or seabed and displays the results on screen.
Page 148: Sounder Displays
4. VIDEO SOUNDER OPERATION Sounder Displays 4.2.1 Selecting a sounder display There are seven display modes from which to choose: dual frequency, single frequency, marker zoom, bottom zoom, bottom lock, bottom discrimination, and A-scope To select a display; 1. Press the [DISP] key and select a sounder display. 2.
Page 149: Description Of Sounder Displays
4.2.2 Description of sounder displays Single frequency display Zero line Icons (alarm, battery, simulation) Color bar Temp. scale (orange) Water temp. graph Water temp. display Note 1: The water temperature display requires an appropriate water temperature sensor. It can be turned on or off with TEMPERATURE GRAPH on the SOUNDER menu.
Page 150 4. VIDEO SOUNDER OPERATION Dual-frequency display The dual-frequency display provides both 50 kHz and 200 kHz pictures. This display is useful for comparing the same picture with two different sounding frequencies. LF picture The sounder uses ultrasonic pulses to detect bottom conditions. The lower the frequency of the pulse, the wider the detection area.
Page 151 Marker-zoom display The marker-zoom display expands a selected area of the normal sounder picture to full vertical size of the screen on the left-half window. You may specify the portion to expand by operating the VRM (Variable Range Marker), which you can shift with the [ENTER] knob.
Page 152 4. VIDEO SOUNDER OPERATION Bottom-lock display The bottom-lock display provides a compressed normal picture on the right half of the screen and a 3 or 6 meter (10 or 20 feet) wide layer in contact with the bottom is expanded onto the left half of the screen. This mode is useful for discriminating bottom fish from the bottom echo.
Page 153: Selecting Screen Split Method In Combination Displays
A-scope display (display only) The A-scope display, available in all modes, shows echoes at each transmission with amplitudes and tone proportional to their intensities, on the right of the screen. It is useful for estimating fish species and seabed composition. To turn on the A-scope display, press the DISPLAY MODE soft key, select display mode desired, then press the A-SCPE soft key to turn the A-scope display on or off as appropriate.
Page 154: Automatic Sounder Operation
4. VIDEO SOUNDER OPERATION Automatic Sounder Operation Automatic sounder operation is useful when you are preoccupied with other tasks and do not have the time to adjust the display. 4.3.1 How the automatic sounder works The automatic sounder function automatically selects the proper gain, range scale and clutter suppression level according to depth.
Page 155: Manual Sounder Operation
Manual Sounder Operation Manual operation is useful for observing fish schools and bottom using fixed gain setting. The gain, range and range shifting functions used together give you the means to select the depth you can see on screen. 4.4.1 Selecting the manual mode 1.
Page 156: Range Shifting
4. VIDEO SOUNDER OPERATION Press the [GAIN] key to show the gain window, and rotate the [ENTER] knob to set the gain. Current level is shown on the bar. Press the RETURN key to finish. The setting range is 0-100. Note 1: On the dual-frequency display, the gain can be independently set for LF and HF.
Page 157: Measuring Depth, Time
Measuring Depth, Time The VRM functions to measure the depth, and the time cursor measures time. 1. Rotate the [ENTER] knob to shift the VRM; counterclockwise the shift it downward, clockwise to shift it upward. You may also use the cursor pad to shift the VRM, in which case use ▲...
Page 158: Reducing Interference
4. VIDEO SOUNDER OPERATION Reducing Interference Interference from other acoustic equipment operating nearby or other electronic equipment on your boat may show itself on the display as shown below. To reduce interference, do the following: 1. Press the [MENU] key. 2.
Page 159: Reducing Low Level Noise
Reducing Low Level Noise Dots (light-blue on the color model) may appear over most of the screen. This is mainly due to sediment in the water or noise. This noise can be suppressed by adjusting CLUTTER on the SOUNDER menu. When the sounder mode is Auto, the clutter suppression setting is fixed at AUTO.
Page 160: Erasing Weak Echoes
4. VIDEO SOUNDER OPERATION Erasing Weak Echoes Sediment in the water or reflections from plankton may be painted on the display in green or light blue (color display) or “spots” on the background (monochrome display). These weak echoes may be erased as below. 1.
Page 161: White Marker (Model1722C/1723C Series)
White Marker (MODEL1722C/1723C series) The white marker functions to display a particular echo color in white. For example, you may want to display the bottom echo in white to discriminate fish echoes near the bottom. 1. Press the [MENU] key. 2.
Page 162: Picture Advance Speed
4. VIDEO SOUNDER OPERATION 4.10 Picture Advance Speed The picture advance speed determines how quickly the vertical scan lines run across the screen. When selecting a picture advance speed, keep in mind that a fast advance speed will expand the size of the fish school horizontally on the screen and a slow advance speed will contract it.
Page 163: Advancement Synchronized With Ship's Speed
4. VIDEO SOUNDER OPERATION 4.10.2 Advancement synchronized with ship’s speed With speed data provided by a speed measuring device, picture advance speed may be automatically synchronized with ship’s speed. As shown in the figure below the horizontal scale of the display is not influenced with the speed dependent picture advance mode active, thus it permits judgment of fish school size and abundance at any speed.
Page 164: Display Colors (Model1722C/1723C Series)
4. VIDEO SOUNDER OPERATION 4.11 Display Colors (MODEL1722C/1723C series) You can select the number of colors and background color to display as follows: 1. Press the [MENU] key. 2. Press the SOUNDER MENU soft key. 3. Select HUE, and then press the EDIT soft key to show the hue window. 4.
Page 165: Alarms
4.12 Alarms The sounder section has five conditions which generate visual and aural alarms: bottom alarm, fish alarm (bottom lock), fish alarm (normal) and water temperature alarm (temperature sensor required). For 1722C/1723C series, note that the alarm icon is red when an alarm setting is violated, and changes to background color when the [CLEAR] key or CLEAR ALARM soft key is pressed.
Page 166: Bottom Alarm
4. VIDEO SOUNDER OPERATION 4.12.2 Bottom alarm The bottom alarm sounds when the bottom echo is within the alarm range set. To activate the bottom alarm the depth must be displayed. Note that the bottom alarm is turned on or off reciprocally with the bottom alarm on the plotter alarm menu.
Page 167: Fish Alarm (B/L)
4.12.4 Fish alarm (B/L) The bottom-lock fish alarm sounds when a fish echo is within a predetermined distance from the bottom. Note that the sensitivity of the fish alarm can be set on the SOUNDER SYSTEM SETUP menu. 1. Press the [ALARM] key to show the ALARM menu. 2.
Page 168: Water Temperature Alarm
4. VIDEO SOUNDER OPERATION 4.12.5 Water temperature alarm There are two types of water temperature alarms: WITHIN RANGE and OUT OF RANGE. The WITHIN RANGE alarm sounds when the water temperature is within the range set, the OUT OF RANGE alarm sounds when the water temperature is higher or lower than the range set.
Page 169: When An Alarm Setting Is Violated
4.12.6 When an alarm setting is violated... When an alarm setting has been violated the buzzer sounds and the speaker icon appears (in red on the color model). Press the [CLEAR] key to silence the alarm. For color models, press the [ALARM] key, CLEAR ALARM soft key to change the speaker icon from red to black.
Page 170: Water Temperature Graph
4. VIDEO SOUNDER OPERATION Alarm messages The table below shows the sounder alarm messages and their meanings Message DEPTH ALARM! FISH ALARM! TEMPERATURE ALARM! 4.13 Water Temperature Graph The water temperature graph (appropriate sensor required) plots water temperature on the sounder display. (See the figure on page 4-3.) It can be turned on or off as below.
Page 171: Interpreting The Sounder Display
4.15 Interpreting the Sounder Display 4.15.1 Zero line The zero line (sometimes referred to as the transmission line) represents the transducer’s position. 4.15.2 Bottom echo Echoes from the bottom are normally the strongest and are displayed in reddish-brown (color model) or darkest tone (monochrome model) but the color (tone on the monochrome model) and width will vary with bottom composition, water depth, frequency, sensitivity, etc.
Page 172: Fish School Echoes
4. VIDEO SOUNDER OPERATION 4.15.3 Fish school echoes Fish school echoes will generally be plotted between the zero line and the bottom. Usually the fish school/fish echo is weaker than the bottom echo because its reflection property is much smaller compared to the bottom. The size of the fish school can be ascertained from the density of the display.
Page 173: Customizing Your Unit
CUSTOMIZING YOUR UNIT This chapter describes the various options which allow you to set up your unit to suit your needs. For mode specific menus, e.g. radar plotter and sounder, make sure that you select the appropriate display when making changes or viewing menu option.
Page 174 5. CUSTOMIZING YOUR UNIT Item Key Beep Turns key operation beep on/off. Language Chooses menu language. Range Unit Chooses unit of range and speed measurement. Temperature Unit Chooses unit of water temperature measurement. Depth Unit Chooses unit of depth measurement. Temperature Chooses source of water temperature data.
Page 175: Radar Setup
Radar Setup This paragraph explains how to customize the radar display to suit your operational needs. Be sure to show the radar display before executing any of the procedures. 5.2.1 Radar display setup The radar display may be set up from the RADAR DISPLAY SETUP menu, which contains items such as EBL reference and cursor position format.
Page 176 5. CUSTOMIZING YOUR UNIT Item References EBL bearing, shown in the Reference EBL data box, to North (True) or heading (Relative) Cursor Chooses how to display cursor position. Position Tuning Selects receiver tuning method. For further details see “2.3 Tuning.” TX Sector Turns on/off dead sector graphic, which Blanking...
Page 177 Contents of radar setting menu (con’t from previous page) Item Description Chooses echo color. Echo Color (Color model) Sets watchman stand-by period. For Watchman further details see paragraph 2.23 Time Watchman. Sets unit of range measurement. Range Unit 5. CUSTOMIZING YOUR UNIT Settings Default Setting Yellow, Green,...
Page 178: Radar Range Setup
5. CUSTOMIZING YOUR UNIT 5.2.2 Radar range setup You may choose the radar ranges you wish to use, from the RADAR RANGE SETUP menu. (Available ranges depends on the network radar used.) After choosing the ranges desired change the range with the [RANGE] key to activate range settings.
Page 179: Function Key Setup
5.2.3 Function key setup The function keys provide one-touch call up of a desired function. The default radar function key settings are as shown in the table below. Function Key Turn heading line off. Turn range rings on/off. Turn echo trail on/off. Turn display offcenter on/off.
Page 180 5. CUSTOMIZING YOUR UNIT 4. Select function desired with the cursor pad or [ENTER] knob and press the ENTER soft key or [ENTER] knob to register your selection. 5. Press the [MENU] key to close the menu. Menu Item Assigns no function. HL: HDG LINE OFF Turns heading line off.
Page 181: Plotter Setup
Plotter Setup This paragraph provides the information necessary for setting up the plotter display. 5.3.1 Navigation options Navigation options, for example, waypoint switching method, may be set on the plotter setup menu. 1. Show the plotter display and press the [MENU] key open the main menu. 2.
Page 182: Function Key Setup
5. CUSTOMIZING YOUR UNIT 5.3.2 Function key setup The function keys provide one-touch call up of a desired function. The default plotter function key settings are as shown in the table below. Function Key Start/stop recording/plotting own ship’s track. Edit mark/line. Ruler (measure range and bearing between two points).
Page 183 4. Select function desired with the cursor pad or [ENTER] knob and press the ENTER soft key or [ENTER] knob to register your selection. 5. Press the RETURN soft key. 6. Press the [MENU] key to close the menu. Menu Item Assigns no function.
Page 184: Chart Setup
5. CUSTOMIZING YOUR UNIT Chart Setup This paragraph shows you how to setup digital charts, from offsetting chart position to turning chart attributes on or off. 5.4.1 Chart offset In some instances position may be off by a few seconds. For example, the position of the ship is shown to be at sea while it is in fact moored at a pier.
Page 185: Furuno, Nav-Charts™ Chart Attributes
™ CHART DETAILS GREEN EDIT LARGE CNTOUR LINE BRT YELLOW BLACK RETURN WHITE LARGE Chart details menu (FURUNO, Nav-Charts ™) 5. CUSTOMIZING YOUR UNIT CHART LAT/LON GRID DETAILS TEXT INFORMATION EDIT WAYPOINTS LARGE CNTOUR LINE WAYPOINT NAMES CHART BORDER LINES...
Page 186 5. CUSTOMIZING YOUR UNIT Contents of chart details menu (FURUNO, NavCharts Item Description Lat/Lon Grid Latitude and longitude grids Text Information Geographic place, name Waypoints Waypoint size Waypoint Waypoint name Names Chart Border Border lines Lines (indices) Landmass Landmass brilliance...
Page 187 DEPTH = 10m YELLOW DEPTH > 10m LIGHT BLUE DEPTH INFORMATION 10m: APPROX. 30ft OR 5fa OR 6pb Contour line menu (FURUNO, Nav-Charts ™) 5. CUSTOMIZING YOUR UNIT CNTOUR DEPTH < 10m LINE DEPTH = 10m EDIT DEPTH > 10m DEPTH INFORMATION 10m: APPROX.
Page 188: C-Map Chart Attributes
5. CUSTOMIZING YOUR UNIT 5.4.3 C-MAP chart attributes Charts attributes may be turned on or off from the CHART DETAILS menu, which you may display as follows: 1. Press the [MENU] key. 2. Press the CHART SETUP and CHART DETAILS soft keys. WAYPOINT WAYPOINT NAME PLOTTER/OVERLAY...
Page 189 Item Description Waypoints Waypoint display Plotter/Overlay, Waypoint Names Waypoint name Lat/Lon Grid Latitude and longitude grids Chart Border Border lines Lines (indices) Background Chart background color Port & Service Port services icon display Attention Area Attention area icon display Nav Lane Navigation lanes Light Lighthouse icon,...
Page 190 5. CUSTOMIZING YOUR UNIT Contents of C-MAP chart details menu (continued from previous page) Item Description Chart Generation Chart generation category icons New Object New object category icons Complex Object Single or multiple Icon icon for object composed of several icons Information Level Basic or detailed data for objects DEPTH INFO...
Page 191 DEPTH INFO soft key 1. Press the [MENU] key. 2. Press the CHART SETUP and CHART DETAILS soft keys. 3. Press the DEPTH INFO soft key. BATHYMETRIC LINE PLOTTER/OVERLAY SPOT SOUNDING PLOTTER/OVERLAY BOTTOM TYPE PLOTTER/OVERLAY CONTOUR SHADING 00020, 00164ft SPOT SOUNDING RANGE 00000 - 00033ft MODEL1722C/1723C series Depth info menu (C-map)
Page 192: Data Boxes Setup
5. CUSTOMIZING YOUR UNIT Data Boxes Setup You may select the data to show in the data boxes for the plotter, radar and sounder displays. Six boxes may be displayed in case of small size data box and two for large size data box. 1.
Page 193: Hot
Hot Page Setup Five user-arrangeable hot pages are provided for quick selection of desired display. 1. Press the [MENU] key followed by pressing the SYSTEM CONFIGURATION, SYSTEM SETUP, HOT PAGE & NAV DISP SETUP and HOT PAGE SETUP soft keys in that order. 2.
Page 194 5. CUSTOMIZING YOUR UNIT 3. Rotate the [ENTER] knob to select the full-screen picture desired and push the [ENTER] knob. A set of combination screens, corresponding to the full-screen selected, appears. 4. Rotate the [ENTER] knob to select the full screen or combination screen desired and push it to set.
Page 195: Navigator Setup
Depth Offsets NMEA/NETWORK depth data. Calibration 5. CUSTOMIZING YOUR UNIT Contents of nav setup menu Settings FURUNO BB GPS: GPS Receiver GP-310B/320B GP: GPS navigator (via NETWORK or NMEA connector) LC: Loran C navigator (via NETWORK or NMEA connector) All: Multiple navaid connection...
Page 196: Gps Receiver Setup (Set Equipped With Gp-310B/320B)
5. CUSTOMIZING YOUR UNIT 5.7.2 GPS receiver setup (Set equipped with GP-310B/320B) The GPS SETUP menu sets up the GPS Receiver GPS-310B/320B. Press the [MENU] key followed by the SYSTEM CONFIGURATION, NAV OPTION and GPS SENSOR SETTINGS soft keys to display this menu. Item Local Time Offset Lets you use local time (instead of UTC time).
Page 197 Contents of GPS sensor setup menu (con’t from previous page) Item Description Spd/Cse During position fixing, ship’s velocity (speed and course) Smoothing is directly measured by receiving GPS satellite signals. The raw velocity data may vary too much depending on receiving conditions and other factors.
Page 198 5. CUSTOMIZING YOUR UNIT WAAS SETUP Press the WAAS SETUP soft key to show the WAAS SETUP display. Note: This function requires GP-320B antenna. Also, confirm that your display unit has the program version no. shown below. NavChart type: Ver. 12 and after C-map type: Ver.8 and after Item WAAS MODE...
Page 199: Td Display Setup
5.7.3 TD display setup The TD SETUP menu sets which Loran C or Decca chain to use to display TD position. (Connection of a Loran C or Decca navigator is not necessary to display TD position.) 1. Press the [MENU] key. 2.
Page 200 5. CUSTOMIZING YOUR UNIT 5. Press the ENTER soft key to register your selection. 6. If necessary, you may enter a position offset to refine Loran C position accuracy. Select (GRI) CORRECTION 1 or CORRECTION 2 and press the EDIT soft key. Enter correction value with the cursor pad and [ENTER] knob and then press the ENTER soft key or the [ENTER] knob.
Page 201: Nav Data Display Setup
Nav Data Display Setup The nav data display provides various navigation data, fed from a navigator, network equipment, etc. You may select the data to display and where to display it, on the NAV DATA menu. 1. Press the [MENU] key to open the main menu. 2.
Page 202: Sounder Setup
5. CUSTOMIZING YOUR UNIT Sounder Setup This section shows you how to customize your sounder to your liking. You can set fish alarm sensitivity, fine tune sensor data, etc. 5.9.1 System setup 1. Show the sounder display and press the [MENU] key. 2.
Page 203 Sounder system setup menu description (con’t) Item TVG (Time Varied Gain) compensates for propagation (LF, HF) attenuation of the ultrasonic waves. It does this by equalizing echo presentation so that fish schools of the same size appear in the same density in both shallow and deep waters.
Page 204: Sensor Setup
5. CUSTOMIZING YOUR UNIT 5.9.2 Sensor setup The sensor setup menu lets you further refine speed, temperature and depth data fed from the network sounder. 1. Show the sounder display and press the [MENU] key. 2. Press the SOUNDER SYSTEM SETUP and SENSOR SETUP soft keys to show the SENSOR SETUP menu.
Page 205: Sounding Range, Zoom Range, Bottom Lock Range
5.9.3 Sounding range, zoom range, bottom lock range This paragraph shows you how to set custom ranges for basic range, zoom range (marker and bottom zoom) and bottom lock range. All default basic ranges are restored whenever the unit of depth measurement is changed. Therefore, change the depth unit before changing the basic ranges.
Page 206: Function Key Setup
5. CUSTOMIZING YOUR UNIT 5.9.4 Function key setup The function keys provide one-touch call up of a desired function. The default sounder function key settings are as shown in the table below. Function Key Output cursor position Suppress clutter. Erase weak signal. Suppress noise.
Page 207 5. Select function desired with the cursor pad or [ENTER] knob and press the ENTER soft key or [ENTER] knob to register your selection. 6. Press the ENTER soft key or the [ENTER] knob to register your selection. 7. Press the [MENU] key to close the menu. Menu Item Assigns no function.
Page 208 This page is intentionally left blank. 5-36...
Page 209: Data Transfer
DATA TRANSFER This chapter provides information for saving and replaying data to and from memory cards, and uploading and downloading data. Memory Card Operations The memory cards function to store data, and the following data can be saved: Marks/lines Waypoints/routes Track Setting data (plotter only) 6.1.1...
Page 210: Saving Data To A Memory Card
6. DATA TRANSFER 6.1.2 Saving data to a memory card 1. Insert a formatted memory card into the slot. 2. Press the [MENU] key followed by the SYSTEM CONFIGURATION, DATA TRANSFER, UPLOAD/DOWNLOAD DATA and SAVE DATA TO MEMORY CARD soft keys to show the SAVE DATA menu. 3.
Page 211 Memory card messages Various memory card messages appear to alert you to memory card-related error. These are tabulated below. Message Memory card is not Memory card not inserted. Please insert inserted. card. Push ENTER knob to continue. Memory card is not Unformatted memory formatted.
Page 212: Playing Back Data From A Memory Card
6. DATA TRANSFER 6.1.3 Playing back data from a memory card Data (track, marks, lines, waypoints, routes and setting data) can be loaded from a memory card and displayed on the screen. This feature is useful for observing past data and setting up the equipment for a specific purpose with “setup data.” 1.
Page 213: Uploading, Downloading Data
Uploading, Downloading Data You can upload waypoint and route data from a PC and download like data to a PC, through the DATA 3 port at the rear of the display unit. Note that sounder and radar data cannot be uploaded or downloaded. 6.2.1 Setting communication software on the PC Set communication software on the PC as follows:...
Page 214 6. DATA TRANSFER 7. To change the baud rate, press the SELECT BPS soft key. 8. Select baud rate and press the ENTER soft key. Note: Select the speed among 4800, 9600 and 19200 bps. 9. Press the DWLOAD or UPLOAD soft key. You are asked if you are ready to download or upload waypoints and routes.
Page 215 Route data menu $PFEC, GPrtc, 1: Number of sentences required for one complete route data (1 to 4). See Note 2: Number of sentences currently used (1 to 4) 3: Message mode (Always set to C) 4: Route No. (001 to 300, 3 digits required) 5 through 12: Waypoint name (Max.
Page 216: Loading Waypoint Data From Yeoman
6. DATA TRANSFER Loading Waypoint Data from Yeoman Waypoint data can be loaded from a Yeoman to this equipment. Connect the Yeoman to any DATA port on this equipment and then follow the procedure below. 1. Press the [MENU] key. 2.
Page 217: Receiving Data Via Network Equipment
Receiving Data Via Network Equipment You can receive waypoints, routes, marks and lines from NavNet equipment. 1. Press the [MENU] key. 2. Press the SYSTEM CONFIGURATION soft key. 3. Press the DATA TRANSFER soft key. 4. Press the RECEIVE DATA VIA NETWORK soft key. 5.
Page 218: Outputting Data Through The Network
6. DATA TRANSFER 10. Press the RCV soft key to receive data. The message “START RECEIVING DATA VIA NETWORK.” is displayed. IF no data could be found the message “(HOST NAME)’ IS NOT FOUND.” appears. 11. When the transfer is completed, the message “DATA TRANSFER COMPLETED.
Page 219: Maintenance, Troubleshooting
MAINTENANCE, TROUBLESHOOTING This chapter provides information necessary for keeping your unit in good working order and remedying simple problems. Preventive Maintenance Regular maintenance is important for optimum performance. A maintenance schedule should be established and should at least include the items below. Item Display unit connectors...
Page 220: Replacement Of Fuse
7. MAINTENANCE, TROUBLESHOOTING Replacement of Fuse The fuse on the power cable protects the equipment from reverse polarity of the ship’s mains and equipment fault. If the fuse blows, find out the cause before replacing it. Use the correct fuse (10A for 12 V, 5A for 24 V). Using the wrong fuse will damage the equipment and void the warranty.
Page 221: Simple Troubleshooting
Simple Troubleshooting This section provides simple troubleshooting procedures which the user can follow to restore normal operation. If you cannot restore normal operation do not attempt to check inside the unit. Any trouble should be referred to a qualified technician. 7.4.1 General If…...
Page 222: Radar
7. MAINTENANCE, TROUBLESHOOTING 7.4.2 Radar Requires a network radar. If… you pressed the nothing appears on the display [POWER/BRILL] key and the RADAR TX soft key to show the radar picture marks, legends appear no echo appears picture not updated or picture freezes tuning is adjusted sensitivity is poor...
Page 223: Plotter
7.4.3 Plotter Requires GPS Receiver GP-310B/320B. If… position is not fixed within ! check that antenna connector is firmly fastened. three minutes ! Check the satellites numbers received, on the GPS status display (GPS SENSOR SETTINGS menu, GPS STATUS key see page 7-11). position is wrong ! check that the correct geodetic chart system is selected, on the GPS SENSOR SETTINGS menu.
Page 224: Sounder
7. MAINTENANCE, TROUBLESHOOTING 7.4.4 Sounder Requires Network Sounder ETR-6/10N or ETR-30N. If… If you selected a no sounder display appears sounder display with the DISP key marks and characters picture does not appear appear picture appears zero line does not appear picture sensitivity is too depth is not displayed noise or interference...
Page 225: Diagnostics
Diagnostics This paragraph provides the procedures for testing the equipment for proper operation. Four tests are provided: Memory I/O test, Keyboard test, Remote controller test, and Test pattern. 7.5.1 Memory I/O test The memory I/O test provides for individual testing of the display unit, GPS receiver GP-310B/320B, network sounder ETR-6/10N, ETR-30N and ARP, displaying program number and checking for proper operation.
Page 226 7. MAINTENANCE, TROUBLESHOOTING Display unit test Press the DISPLAY UNIT TEST soft key at the MEMORY I/O TEST menu to test the display unit. The equipment displays program version number, checks devices and shows the number of the chart card inserted in the chart slot (if inserted).
Page 227 Network sounder (ETR-6/10N, ETR-30N) test Press the NETWORK SOUNDER TEST soft key at the MEMORY I/O TEST menu to test the Network Sounder ETR-6/10N or ETR-30N. The equipment displays network sounder program version number, checks the ROM and RAM, and displays water temperature (appropriate sensor required) and depth. The results of the ROM and RAM check are shown as OK or NG (No Good).
Page 228: Test Pattern
7. MAINTENANCE, TROUBLESHOOTING 7.5.2 Test pattern The test pattern test checks the display for proper display of colors (MODEL1722C/1723C series) or tones (MODEL1722 series). 1. Press the [MENU] key to show the menu. 2. Press the SYSTEM CONFIGURATION soft key. 3.
Page 229: Keyboard, Remote Controller Test
7.5.3 Keyboard, remote controller test The keyboard test checks the controls on the display unit and remote controller for proper operation. 1. Press the [MENU] key to show the menu. 2. Press the SYSTEM CONFIGURATION soft key. 3. Press the SYSTEM SETUP soft key. 4.
Page 230: Gps Status Display
7. MAINTENANCE, TROUBLESHOOTING GPS Status Display The GPS status display provides data about the GPS satellites, and is available with connection of the GPS Receiver GP-310B/320B or a GPS navigator outputting the data sentence GSA or GSV. 1. Press the [MENU] key. 2.
Page 231: Clearing Memories
11. Turn the power off, and on again. Note: Though the message “SYSTEM HAS FAILED START UP TEST. PLEASE CONTACT A LOCAL FURUNO REPRESENTATIVE FOR REPAIR. PUSH ANY KEY TO CONTENUE” may appear when powering on the display unit immediately after the clearing memories, there is no problem in fact. Press any key to continue the operation.
Page 232: Error Messages
7. MAINTENANCE, TROUBLESHOOTING Error Messages In addition to alarm message your equipment also displays equipment status menus. Error Message Connection with the ETR was cut. Connection with the RADAR was cut. Low Voltage! Internal Battery No bearing pulse detected. No GPS fix! Heading data missing! No heading pulse detected.
Page 233: Appendix
APPENDIX Menu Overview MENU key Radar AP-1...
Page 234 APPENDIX Plotter AP-2...
Page 235 APPENDIX AP-3...
Page 236 APPENDIX AP-4...
Page 237 APPENDIX Sounder AP-5...
Page 238 APPENDIX System configuration AP-6 ENGLISH nm, kt; NMEA NMEA NMEA DD MM. MMMM LORAN C LAT/LON 24 HOURS RHUMB LINE MAGNETIC AUTO, 0060 sec 0:00 0 ft...
Page 239 APPENDIX AP-7...
Page 240 APPENDIX AP-8...
Page 241 APPENDIX AP-9...
Page 242 APPENDIX AP-10...
Page 243 APPENDIX ALARM key AP-11...
Page 244: Geodetic Chart List
APPENDIX Geodetic Chart List 001: WGS84 002: WGS72 003: TOKYO : Mean Value (Japan, Korea, and Okinawa) 004: NORTH AMERICAN 1927 : Mean Value (CONUS) 005: EUROPEAN 1950 : Mean Value 006: AUSTRALIAN GEODETIC 1984 : Australia and Tasmania Island 007: ADINDAN : Mean Value (Ethiopia and Sudan) 008: : Ethiopia 009: : Mall...
Page 245: World Time Chart
APPENDIX World Time Chart AP-13...
Page 246: Icons
APPENDIX Icons Icon North marker. Points to North. Correct chart and suitable scale - full chart reliability. Chart overenlarged. Chart card not inserted. Wrong chart card inserted. Chart scale too small. Plotter, sounder alarm setting violated. Track is not being recorded or plotted. Chart offset applied.
Page 247: Specifications
SPECIFICATIONS OF MARINE RADAR MODEL 1722/1732/1742/1752/1762 MODEL 1722C/1732C/1742C/1752C/1762C MODEL 1723C/1733C/1753C/1763C 1. GENERAL Indication System M1722 series M1722C/1723C series Range, Pulse length (PL) & Pulse Repetition Rate (PRR) Range (nm) Pulse length ( s) 0.125 to 1.5 0.08 1.5 to 3...
Page 248 2.2.4 Radiator Length 2.2.5 Horizontal Beamwidth 2.2.6 Vertical Beamwidth 2.2.7 Sidelobe Attenuation MODEL1742/1742C: 2.3.1 Radiator 2.3.2 Polarization 2.3.3 Antenna Rotation Speed 24 rpm nominal 2.3.4 Radiator Length 2.3.5 Horizontal Beamwidth 2.3.6 Vertical Beamwidth 2.3.7 Sidelobe Attenuation MODEL1752/1752C/1753C: 2.4.1 Radiator 2.4.2 Polarization 2.4.3 Antenna Rotation Speed 24 rpm nominal 2.4.4 Radiator Length 2.4.5 Horizontal Beamwidth...
Page 249 Tuning Receiver Front End Bandwidth Duplexer Warming up 4. DISPLAY UNIT Display M1722 /1732/1742/1752/1762: M1722C/1732C/1742C/1752C/1762C: M1723C/1733C/1753C/1763C: Range, Range Ring Interval (RRI), Number of Rings Range (NM) 0.125 RRI (NM) 0.0625 0.125 0.125 0.25 0.25 0.5 0.5 1 1 2 2 3 4 6 12 12 Number of Rings Maximum range: M1722/C/1723C: 24nm, M1732/1742/1752(C)/1733C/1753C: 36nm, M1762/C/1763C: 48nm...
Page 250 Simple route: 200 routes with 35 waypoints each 1 point 1 course with 35 waypoints max. FURUNO chart card or NAVIONICS chart card available C-MAP chart card also available for C-MAP NT Model Arrival and anchor watch, Cross track error and proximity alarms, Ship’s speed in and out alarms, Water temperature, Trip alarm,...
Page 251 M1742C M1752C M1762C M1723C M1733C M1753C M1763C Rectifier PR-62 (option for M1722/1732 (C)/1723C/1733C) RU-3423 (option for M1742/1752/1762 (C)/1753C/1763C) 7. ENVIRONMENTAL CONDITION Ambient Temperature (IEC 60945) Relative Humidity Waterproofing (IEC 60529) Bearing Vibration 8. COATING COLOR Display Unit Scanner Unit M1722/1732 (C)/1723C/1733C M1742/1752/1762 (C)/1753C/1763C N9.5 12-24 VDC: 5.0-2.5 A 12-24 VDC: 5.4-2.7 A...
Page 252 This page is intentionally left blank. SP - 6 E3494S01K...
Page 253: Index
... 3-13 inserting ... 1-6 Nav-Charts™ chart attributes... 5-13 offsetting ... 5-16 port service icons ... 3-13 symbols for FURUNO, Nav-Charts™ ... 3-12 tide information (C-MAP) ... 3-16 CLEAR ALARM soft key ... 4-19 Clutter rejector... 4-13 C-MAP charts attributes ...
Page 254 INDEX Compass display ... 3-3 Contrast... 1-9 Controls display unit... 1-2 remote controller... 1-5 Course-up mode plotter ... 3-8 radar... 2-10 CPA/TCPA alarm... 2-42 Cursor ... 1-8 CURSOR soft key... 2-18 Data boxes erasing ... 1-15 hiding... 1-15 rearranging ... 1-15 setup ...
Page 255 charts, radar (MODEL-1722C/1723C series) ... 1-10 sounder (MODEL-1722C/1723C series) .. 4-18 I. REJ. soft key... 2-18 Icons... AP-14 Interference rejection radar... 2-18 sounder ... 4-12 Keyboard test... 7-11 Keying pulse ... 5-30 Language... 5-2 Latitude, longitude display... 5-2 LOAD DATA menu ... 6-5 Local time ...
Page 256 INDEX Port, port services icons... 2-12 navigating to ... 2-44 Position smoothing... 5-18 POWER/BRILL key... 1-7, 1-8 Presentation mode plotter ... 2-7 radar... 3-8 Proximity alarm ... 3-57 Pulselength (radar) ... 3-7 Racon... 3-46 RADAR SETTING menu (radar)... 5-23 RADAR TX soft key... 3-2 Range measurement by cursor (plotter) ...
Page 257 erasing own ship's by area ... 2-22 erasing own ship's by color ... 2-23 memory capacity... 2-21 plotting interval... 2-20 plotting method ... 2-20 plotting of own ship's... 2-18 TRACK HALT soft key... 2-18 TRACK RESUME soft key ... 2-18 TRAIL COLOR soft key ...
