Managing individual FortiGate-7081F FIMs and FPMs
To verify which FIM or FPM you have logged into, the GUI header banner and the CLI prompt shows its hostname. The
System Information dashboard widget also shows the host name and serial number. The CLI prompt also shows the slot
address in the format <hostname> [<slot address>] #.
Logging in to different FIMs or FPMs allows you to use dashboard widgets, FortiView, or Monitor GUI pages to view the
activity of that FIM or FPM. Even though you can log in to different modules, you can only make configuration changes
from the primary FIM; which is usually the FIM in slot 1.
FortiGate-7081F special management port numbers (slot numbers in order as installed in the chassis)
Slot Number Slot Address
7 FPM07
5 FPM05
3 FPM03
1 FIM01
2 FIM02
4 FPM04
6 FPM06
8 FPM08

HA mode special management port numbers

In HA mode, you use the same special port numbers to connect to FIMs and FPMs in chassis 1 (chassis ID = 1) and
different special port numbers to connect to FIMs and FPMs in chassis 2 (chassis ID = 2):
FortiGate-7081F HA special management port numbers
Chassis and Slot Address
Slot Number
Ch1 slot 7 FPM07
Ch1 slot 5 FPM05
Ch1 slot 3 FPM03
Ch1 slot 1 FIM01
Ch1 slot 2 FIM02
Ch1 slot 4 FPM04
Ch1 slot 6 FPM06
Ch1 slot 8 FPM08
FortiGate-7081F 7.0.5 System Guide
HTTP (80) HTTPS (443)
8007 44307
8005 44305
8003 44303
8001 44301
8002 44302
8004 44304
8006 44306
8008 44308
HTTP HTTPS (443)
(80)
8007 44307
8005 44305
8003 44303
8001 44301
8002 44302
8004 44304
8006 44306
8008 44308
Telnet (23) SSH (22)
2307 2207
2305 2205
2303 2203
2301 2201
2302 2202
2304 2204
2306 2206
2308 2208
Telnet SSH (22)
(23)
2307 2207
2305 2205
2303 2203
2301 2201
2302 2202
2304 2204
2306 2206
2308 2208
Fortinet Technologies Inc.
SNMP (161)
16107
16105
16103
16101
16102
16104
16106
16108
SNMP (161)
16107
16105
16103
16101
16102
16104
16106
16108
