FortiGate-7081F chassis
Cooling Fan Tray
Retention
Screw
Retention
Screw

Cooling air flow and required minimum air flow clearance

When installing the chassis, make sure there is enough clearance for effective cooling air flow. The following diagram
shows the cooling air flow through the chassis and the locations of fan trays. Make sure the cooling air intake and warm
air exhaust openings are not blocked by cables or rack construction because this could result in cooling performance
reduction and possible overheating and component damage.
FortiGate-7081F 7.0.5 System Guide
Retention
Screw
Retention
Screw
Fan
LED
