Managing individual FortiGate 6000F management boards and FPCs
FortiGate 6000F special management port numbers
Slot Address
Slot 0, (MBD)
Slot 1 (FPC01)
Slot 2 (FPC02)
Slot 3 (FPC03)
Slot 4 (FPC04)
Slot 5 (FPC05)
Slot 6 (FPC06)
Slot 7 (FPC07)
Slot 8 (FPC08)
Slot 9 (FPC09)
Slot 10 (FPC10)
For example, to connect to the CLI of the FPC in slot 3 using SSH, you would connect to ssh://192.168.1.99:2203.
To verify which slot you have logged into, the GUI header banner and the CLI prompt shows the current hostname. The
System Information dashboard widget also shows the host name and serial number. The CLI prompt also shows slot
address in the format <hostname> [<slot address>] #.
Logging in to different FPCs allows you to use the FortiView or Monitor GUI pages to view the activity on that FPC. You
can also restart the FPC from its GUI or CLI. Even though you can log in to different FPCs, you can only make
configuration changes from the management board.

HA mode special management port numbers

In an HA configuration consisting of two FortiGate 6000Fs in an HA cluster, you can connect to individual FPCs or to the
management board in chassis 1 (chassis ID = 1) using the same special port numbers as for a standalone FortiGate
6000F.
You use different special port numbers to connect to individual FPCs or the management board in the FortiGate 6000F
with chassis ID 2 (chassis ID = 2).
FortiGate 6000F special management port numbers (chassis ID = 2)
Slot Address
Slot 0, (MBD)
Slot 1 (FPC01)
Slot 2 (FPC02)
FortiGate 6000F Series 7.0.12 System Guide
HTTP (80) HTTPS (443)
8000 44300
8001 44301
8002 44302
8003 44303
8004 44304
8005 44305
8006 44306
8007 44307
8008 44308
8009 44309
8010 44310
HTTP HTTPS (443)
(80)
8020 44320
8021 44321
8022 44322
Telnet (23) SSH (22)
2300 2200
2301 2201
2302 2202
2303 2203
2304 2204
2305 2205
2306 2206
2307 2207
2308 2208
2309 2209
2310 2210
Telnet SSH (22)
(23)
2320 2220
2321 2221
2322 2222
Fortinet Technologies Inc.
SNMP (161)
16100
16101
16102
16103
16104
16105
16106
16107
16108
16109
16110
SNMP (161)
16120
16121
16122
