- Page 1 QuickStart Guide FortiGate 30G Series FG-30G, FG-31G...
-
Page 2: Package Contents
The Essentials Package Contents FortiGate 30G Series Secure your Network FG-30G, FG-31G Register at https://support.fortinet.com for the latest threat protection updates Connect Port 1 to an Ethernet port or USB-RJ45 adapter on your computer using the provided Ethernet cable Open a browser to https://192.168.1.99... - Page 3 Parity: None (available for purchase) Flow Control: None Console Port Port 1 If Static IP: 192.168.1.1/24 Ethernet Cable FortiGate Cloud Login to https://fortigate.forticloud.com using your Fortinet Credentials, then click Add FortiGate and enter the Cloudkey Internet Ethernet Cable WAN port...
- Page 4 Front FG-30G FortiGate 30G STATUS RESET Ports (4x RJ-45) WAN, 1, 2, A – FortiLink RESET Press and hold for system reset LINK/ACT (Left LED) SPEED (Right LED) Green: Connected Green: 1 Gbps CONSOLE Port (RJ-45) CLI management Green: Data activity Amber: 100 Mbps Flashing Off: Not connected...
- Page 5 Rear FG-30G Power Input 12V DC, 100-240V AC, 50/60Hz adapter...
-
Page 6: Regulatory Notices
この装置は、クラスＢ機器です。この装置は、住宅環境で使用することを目的としていますが、この装置がラジオやテレビジョン受信機に近接 して使用されると、受信障害を引き起こすことがあります。取扱説明書に従って正しい取り扱いをして下さい。 ＶＣＣＩ－Ｂ Bureau of Standards Metrology and Inspection (BSMI) – Taiwan The presence conditions of the restricted substance (BSMI RoHS table) are available at the link below: 限用物質含有情況表 (RoHS Table) 請到以下 網址下載： https://www.fortinet.com/bsmi 請仔細閱讀以下說明 本設備勿置於潮濕處。 連接至電源前，請先檢查電壓。 當設備不用時，請將所有電源線拔除，避免電壓不穩而造成傷害。 勿將任何液體濺入設備中，避免線路短路。 基於安全理由，只有受到專業訓練的從業人員，才可以打開本設備。... - Page 7 Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s SVP Legal and above, with a purchaser that expressly warrants that the identified product will perform according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet.
