FortiGate-7081F hardware assembly and rack mounting

Inserting FIMs and FPMs

All FortiGate-7081F chassis are shipped with a protective front panel installed in the chassis to protect internal chassis
components. This panel must be removed before you install FIMs and FPMs.
Insert FIMs into chassis slots 1 and 2. Insert FPMs into chassis slots 3 to 8.
To insert FIMs and FPMs, see the guide supplied with the module.
FortiGate-7081F 7.0.5 System Guide
Do not operate the FortiGate-7081F chassis with open slots on the front or back panel. For
optimum cooling performance and safety, chassis front panel slots 1 and 2 must contain FIMs
or FIM blank panels (also called dummy cards). Front panel slots 3 to 8 must contain FPMs or
FPM blank panels. In addition, all cooling fan trays, power supplies or power supply slot
covers must be installed while the chassis is operating. The FPM blank panels shipped with
the chassis should be kept available in case an FPM is removed from the chassis. If an FIM or
FPM fails and you don't have a replacement FIM or FPM or an available blank panel, you
should keep the failed FIM or FPM in the chassis slot until you receive a replacement.
FIM and FPM backplane connectors are shipped with a backplane connector protection label
and plastic cover. Before inserting the FIM or FPM module into the chassis slot, remove the
label and plastic cover and check the backplane connectors to make sure they are clean and
undamaged.
To install an FIM or FPM into a chassis, carefully slide the module all the way into the chassis
slot, close the module levers to seat the module into the slot, and tighten the secure screws to
make sure the module is fully engaged with the backplane and secured. You must also make
sure that the power sliders are fully closed by gently pushing them down.
Installation Highlights:
1. Remove backplane connector protection label.
2. Module levers must be closed.
3. Secure screws must be tightened.
4. Power sliders must be fully closed for the module to get power and start up.
If the module is not receiving power all LEDs remain off.
All FIM and FPM modules must be protected from static discharge and physical shock. Only
handle or work with these modules at a static-free workstation. Always wear a grounded
electrostatic discharge (ESD) preventive wrist strap when handling modules.
