Managing individual FortiGate-7081F FIMs and FPMs
Chassis and Slot Address
Slot Number
Ch2 slot 7 FPM07
Ch2 slot 5 FPM05
Ch2 slot 3 FPM03
Ch2 slot 1 FIM01
Ch2 slot 2 FIM02
Ch2 slot 4 FPM04
Ch2 slot 6 FPM06
Ch2 slot 8 FPM08

Managing individual FIMs and FPMs from the CLI

From any CLI, you can use the execute load-balance slot manage <slot> command to log into the CLI of
different FIMs and FPMs. You can use this command to view the status or configuration of the module, restart the
module, or perform other operations. You should not change the configuration of individual FIMs or FPMs because this
can cause configuration synchronization errors.
<slot> is the slot number of the slot that you want to log in to.
After you log in to a different module in this way, you can't use the execute load-balance slot manage command
to log in to another module. Instead, you must use the exit command to revert back to the CLI of the component that
you originally logged in to. Then you can use the execute load-balance slot manage command to log into
another module.
Connecting to individual FIM and FPM CLIs of the secondary
FortiGate-7081F in an HA configuration
From the primary FIM of the primary FortiGate-7081F in an HA configuration, you can use the following command to log
in to the primary FIM of the secondary FortiGate-7081F:
execute ha manage <id>
Where <id> is the ID of the other FortiGate-7081F in the cluster. From the primary FortiGate-7081F, use an ID of 0 to
log into the secondary FortiGate-7081F. From the secondary FortiGate-7081F, use an ID of 1 to log into the primary
FortiGate-7081F. You can enter the ? to see the list of IDs that you can connect to.
After you have logged in, you can manage the secondary FortiGate-7081F from the primary FIM or you can use the
execute-load-balance slot manage command to connect to the CLIs of the other FIM and the FPMs in the
secondary FortiGate-7081F.
FortiGate-7081F 7.0.5 System Guide
HTTP HTTPS (443)
(80)
8027 44327
8025 44325
8023 44323
8021 44321
8022 44322
8024 44324
8026 44326
8028 44328
Telnet SSH (22)
(23)
2327 2227
2325 2225
2323 2223
2321 2221
2322 2222
2324 2224
2326 2226
2328 2228
Fortinet Technologies Inc.
SNMP (161)
16127
16125
16123
16121
16122
16124
16126
16128
