FortiGate-7081F chassis
One set of 4-post rack mounting components.
l
One set of 2-post rack mounting components.
l
Sixteen M4x8 flat-head screws.
l
Two M4x6 pan-head screws.
l
Eight rubber feet.
l
Two USB to RJ-45 RS-232 console cables.
l
One RJ-45 Ethernet cable.
l

Optional accessories and replacement parts

The following optional accessories can be ordered separately:
SKU
FG-7081F-FAN
FG7K-PS-2K5AC
FG-7081F-CH
Additional FIMs and FPMs.
l
FIM and FPM blank panels to be installed in empty chassis slots.
l
Transceivers.
l
Cable bracket kit for data cable management.
l
Front air filter kit.
l
Additional AC PSUs.
l
Additional FAN trays.
l

Physical description of the FortiGate-7081F chassis

The FortiGate-7081F chassis is a 12U chassis that can be installed in a standard 19-inch rack. The following table
describes the physical characteristics of the FortiGate-7081F chassis.
Dimensions (H x W x D)
Chassis weight completely assembled with FIMs
and FPMs installed
Operating Temperature
Storage Temperature
Relative Humidity
AC Input Voltage Range
Supplied Power Supply Units (PSUs)
Power supplied by each PSU
Max Power Consumption
FortiGate-7081F 7.0.5 System Guide
Description
FortiGate-7081F fan tray.
2500W AC power supply units (PSUs) for the FortiGate-7081F.
FortiGate-7081F chassis including 2x SMM, 3x fan trays, and 6x ACPSUs.
21.41 x 17.33 x 26.6 in (543.9 x 440 x 675.5 mm)
365.26 lbs. (165.68 kg)
32 to 113°F (0 to 45°C)
-31 to 158°F (-35 to 70°C)
10% to 90% non-condensing
200 to 240 VAC (50 to 60 Hz)
6
2500W
7300W
