Firmware upgrades
During this procedure, the FPM will not be able to process traffic. However, the other FPMs and the FIMs should
continue to operate normally.
1. Set up a TFTP server and copy the firmware file into the TFTP server default folder.
2. Set up your network to allow traffic between the TFTP server and the MGMT1 or MGMT2 interface of one of the
FIMs.
3. Log into the CLI of the FIM.
4. Enter the following command to upload the firmware file from the TFTP server to the FIM:
execute upload image tftp <firmware-filename> comment <tftp-server-ip-address>
5. Enter the following command to verify that the firmware file has been uploaded to the FIM:
fnsysctl ls /data2/tftproot/
6. Confirm the internal address of FIM, which is also the address of the FIM's TFTP server:
fnsysctl ifconfig base-tftp
Example output:
base-tftp Link encap:Ethernet HWaddr 06:76:A0:75:E8:F1
inet addr:169.254.254.1 Bcast:169.254.254.255 Mask:255.255.255.0
The internal IP addresses of each FIM and FPM is 169.254.254.<slot-number>.
7. Using the console cable supplied with your FortiGate-7081F, connect the SMM Console 1 port on the FortiGate-
7081F to the USB port on your management computer.
8. Start a terminal emulation program on the management computer. Use these settings:
Baud Rate (bps) 9600, Data bits 8, Parity None, Stop bits 1, and Flow Control None.
9. Press Ctrl-T to enter console switch mode.
10. Repeat pressing Ctrl-T until you have connected to the module to be updated. Example prompt:
<Switching to Console: FPM03 (9600)>
11. Optionally log into the FPM's CLI.
12. Reboot the FPM.
You can do this using the execute reboot command from the FPM's CLI or by pressing the power switch on the
FPM front panel.
13. When the FPM starts up, follow the boot process in the terminal session and press any key when prompted to
interrupt the boot process.
14. To set up the TFTP configuration, press C.
15. Use the BIOS menu to set the following. Change settings only if required.
[P]: Set image download port: FIM01 TFTP Server (the FIM that you uploaded the firmware file to).
[D]: Set DHCP mode: Disabled.
[I]: Set local IP address: The internal IP address of the FPM. For example, if you are installing firmware
on the FPM in slot 5, the local IP address of the FPM in slot 5 is 169.254.254.5.
[S]: Set local Subnet Mask: 255.255.255.0.
[G]: Set local gateway: 169.254.254.1.
[V]: Local VLAN ID: Should be set to <none>. (use -1 to set the Local VLAN ID to <none>.)
[T]: Set remote TFTP server IP address: The internal IP address of the FIM that you uploaded to the
firmware file to. For example: 169.254.254.1 for the FIM in slot 1.
[F]: Set firmware image file name: The name of the firmware file that you want to install.
16. To quit this menu, press Q.
17. To review the configuration, press R.
