FortiGate 6000F series hardware description

FortiGate 6000F series hardware information

This section introduces FortiGate 6000F series hardware components and accessories.

Shipping components

The FortiGate 6000F ships pre-assembled with the following components:
The 3U FortiGate 6000F.
l
The AC version of the FortiGate 6000F includes three AC Power Supply Units (PSUs) installed in the back panel.
l
The DC version of the FortiGate 6000F includes two DC PSUs installed in the back panel.
l
The AC version of the FortiGate 6000F includes three power cords with C15 power connectors.
l
The DC version of the FortiGate 6000F includes two custom DC power cables that include a two prong connector
l
with a release tab on one end and double hole lug plates on the other end.
Three cooling fan trays installed in the back panel.
l
One set of two sliding rails for 4-post rack mounting.
l
Six rubber feet.
l
One USB to RJ-45 RS-232 console cable.
l
One RJ-45 Ethernet cable.
l
Two FG-TRAN-SFP+SR transceivers.
l

Optional accessories and replacement parts

The following optional accessories can be ordered separately:
SKU
FG-6000F-FAN
SP-FG4000F-PS
SP-FG4000F-DC-PS
FG-7040E-PS-AC
You can also order the following:
Transceivers
l

Physical description of the FortiGate 6000F

The FortiGate 6000F is a 3U appliance that can be installed in a standard 19-inch rack. The following table describes the
physical characteristics of the FortiGate 6000F chassis.
Form factor
FortiGate 6000F Series 7.0.12 System Guide
Description
FortiGate 6000F fan tray.
2000W AC PSU when connected to high line AC power (200VAC or higher). 1500W AC if
connected to low-line AC (120VAC or below).
2000W DC PSU.
1500W AC PSU. (FortiGate 6000F Generation 1)
3RU
