Underside panel
Fig. 4:
The following table contains details on the relevant elements found on the underside panel.
Underside panel elements table
Item
A
B
C

3.2 Assembly

3.2.1 Standalone and anti-theft security cable

The WWAN Enabler can be placed as a standalone device on a flat, stable surface.
Make sure there is enough space around the device for ventilation purposes and that electricity cables can reach it.
WWAN Enabler devices have been equipped with a standard Kensington security slot to which a security cable can
be attached. The T-bar lock of the security cable allows the device to be attached to an anchor point, thus preventing
potential thefts.
The security slot is located on the front panel of the housing, as shown in the following figure.
WWAN Enabler
Description
Rubber feet.
Slots for wall mounting.
Slots for ceiling mounting. (Optional.)
