Wireless Wan Interface (5Ge) - Teldat WWAN Enabler Installation Manual

Technical Information
CONNECTOR
SIM Slots
ANTENNA
A.4.4.1 Antenna connectors and bands (5Ge)
Bands used for each antenna connector
Antenna connectors
Connector
3G /
WCDMA
4G /
LTE
5G-NR /
FR1
Comments
• LB (Low Band): 617–960 MHz
• MHB (Middle High Band): 1452–2690 MHz
• UHB (Ultra High Band): 3400–3800 MHz
• n77/n78: 3300–4200 MHz
• n79: 4400–5000 MHz
• LAA (License Assisted Access): 5150-5925 MHz
• TX: Transmit
• PRX: Primary Reception
• DRX: Diversity Reception
32
• NSA: DL 3.3 Gbps; UL 600 Mbps
• SA: DL 2.4 Gbps; UL 900 Mbps
• LTE:
• DL Cat 19 (Up to 1.6Gbps)
• UL Cat 18: 2CC intra-band contiguous and inter-band, 256QAM (Up to 200
Mbps)
• Supported BW: 1.4–20 MHz, per 3GPP specs for supported bands
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
Four SMA connectors.
1 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
Devices equipped with this interface are shipped with four multi-band swivel-
mount dipole antennas.
ANT4 ANT3
MHB PRX MIMO & MHB TX1/DRX MIMO
UHB PRX MIMO & & UHB TX0/PRX
LAA PRX
- Refarmed: MHB PRX - Refarmed: MHB
MIMO & UHB PRX TX1/DRX MIMO &
MIMO UHBTX0/PRX
- n41 PRX MIMO - n41 TX1/DRX MIMO
- n77/n78/n79 PRX - n77/n78/n79
MIMO TX0/PRX
ANT2 ANT1
LMB TRX LMB DRX
LB TX0/PRX & MHB LB TX1/DRX & MHB
TX0/PRX & UHB DRX & UHB DRX
TX1/DRX MIMO &LAA DRX
- Refarmed: LB TX0 / - Refarmed: LB TX1 /
PRX & MHB TX0 /PRX DRX & MHB DRX &
&UHB TX1/DRX UHB DRXMIMO
- n41 TX0/PRX - n41 DRX
- n77/n78/n79 - n77/n78/n79 DRX
TX1/DRX MIMO
