Installation

Make sure that you have selected the optimal installation place and it complies with the
requirements of this manual.
To install the detector:
1. Remove the SmartBracket mounting panel from the detector. To remove the
panel, turn it counterclockwise.
2. Fix the SmartBracket panel to a surface using double-sided adhesive tape or
other temporary fasteners. The mounting panel has an UP sign, which
indicates the correct position.
Use double-sided adhesive tape for temporary xation only. The device xed by the
adhesive tape can peel off the surface at any time, which can lead to damage if the
device is dropped.
3. Run the Jeweller
three bars.
If the signal strength is a single bar or lower, we cannot guarantee the stable
operation of the detector. Consider to relocate the device as repositioning
even by 20 cm can signi cantly improve the signal strength. If there is still
low or unstable signal after the relocation, use a
extender .
4. Remove the detector from the mounting panel.
5. Attach the SmartBracket panel with the bundled screws using all xation
points. When using other fasteners, make sure they do not damage or
deform the mounting panel.
6. Place the detector on the SmartBracket mounting panel.
7. Adjust the position of the detector if necessary.
signal strength test. The recommended value is two or
radio signal range
