AJAX FireProtect 2 Jeweller User Manual page 14

The test allows you to check the status of the detector's sensors. You can run it
in two ways: by pressing the Test/Mute button of the detector and in Ajax apps.
If the detector is in an alarm state, the self-test is not available.
To run the test using the Test/Mute button, press the center of the front panel
and hold it for 1.5 seconds.
To run the test in the Ajax app:
1. Open the Ajax app.
2. Select the hub if you have several of them or if you are using the
app .
3. Go to the Devices
4. Select FireProtect 2 (Heat/Smoke/CO).
5. Go to the settings by clicking on the gear icon
6. Click on the Self-test eld.
After starting the test, the red LED of the detector blinks 5 times in a row and
then blinks 3 more times but slower. The detector's siren sound in time with an
LED indication. When the test is over, users receive a noti cation about the
detector state in Ajax apps.
The detector also noti es about the test result with sound and LED indications.
If the test is failed and a malfunction is detected, the detector starts to Indicate
a malfunction 3 seconds after the test is begun: the yellow LED blinks twice, and
the siren beeps in time with the LED indication.
The self-test does not start immediately, but no later than 30 seconds after pressing the
Test/Mute button or running from the Ajax app.
menu.
