FireProtect 2 RB (Heat/CO) Jeweller User
FireProtect 2 RB (Heat/CO) Jeweller is a wireless re detector with a built-in
siren. Designed for indoor installation. Detects temperature rise, and dangerous
CO (carbon monoxide) level. The detector also can work without a hub.
A list of compatible hubs and range extenders is
detector is compatible only with hubs on OS Malevich 2.15.0 and higher.
The detector operates as part of the Ajax system, communicating with the hub
via the
Jeweller
1,700 meters without obstacles.
Buy FireProtect 2 RB (Heat/CO)
Updated May 22, 2023
secure radio protocol. The hub communication range is up to
manual
available here
. FireProtect 2 (Heat/CO)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireProtect 2 RB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX FireProtect 2 RB

Summary of Contents for AJAX FireProtect 2 RB

  • Page 1 FireProtect 2 RB (Heat/CO) Jeweller User manual Updated May 22, 2023 FireProtect 2 RB (Heat/CO) Jeweller is a wireless re detector with a built-in siren. Designed for indoor installation. Detects temperature rise, and dangerous CO (carbon monoxide) level. The detector also can work without a hub.

  • Page 2: Functional Elements

    Versions of the detector with other sensor combinations are also available. All Ajax re detectors are available here Functional elements 1. Detector front panel with Test/Mute button . To activate the button, press the center of the panel. 2. SmartBracket mounting panel. To remove the panel, turn it counterclockwise.

  • Page 3: Operating Principle

    13. Second thermistor. Detects dangerous temperatures. Operating principle 0:00 / 0:12 FireProtect 2 RB (Heat/CO) is a wireless re detector designed for indoor installation. Operates for up to 7 years on pre-installed batteries. When the batteries are discharged, they can be replaced with new ones.
  • Page 4 . The tamper controls the removal of the detector from the SmartBracket mounting panel: the detector reacts with LED indication and sends noti cations to users in Ajax apps and the CMS. Ajax automation devices respond to FireProtect 2 alarms and perform user-...
  • Page 5 100 ppm (0.01%) and above — in no more than 40 minutes. 300 ppm (0.03%) and above — in no more than 3 minutes. A CO concentration of 400 ppm (0.04%) for three hours is life-threatening. The detector stops warning of a dangerous carbon monoxide level as soon as the concentration drops to 40 ppm (0.004%).

  • Page 6: Adding To The System

    Which CMSs Ajax connects to Addressability of Ajax devices allows you to send not only events but also the type of the device, the name, virtual room, and security group assigned to it to the PRO Desktop and to the CMS. The list of transmitted parameters may differ depending on the type of the CMS and the selected communication protocol.
  • Page 7 4. Make sure that the hub is on and has Internet access via Ethernet, Wi-Fi, and/or mobile network. You can do this in the Ajax app or by looking at the LED indicator of the hub: it should light up white or green.
  • Page 8 Ajax app. Autonomous operation mode FireProtect 2 detectors can be used autonomously without connecting to an Ajax hub. In this case, the detector noti es of re or dangerous CO level with only a built-in siren and LED indication .
  • Page 9 Also, you can mute the alarm by The siren Test/Mute pressing the The red LED sounds in rapid temperature rise; button or in the Ajax app.  ashes time with the continuously. temperature threshold The LED and sound indications indication. exceeding.
  • Page 10 You can also mute the alarm by Test/Mute pressing the  indication.  button or in the Ajax app. The alarm cannot be muted if the CO level exceeds 300 ppm. The LED and sound indications resume if the source of the...
  • Page 11 Technical Support The siren beeps in How to replace batteries The yellow LED time with the in FireProtect 2 RB ashes once Low battery charge level. per minute. indication (Heat/CO) once per minute. How to replace batteries...

  • Page 12: Functionality Testing

    The test allows you to check the status of the detector’s sensors. You can run it in two ways: by pressing the Test/Mute or in Ajax apps. If the detector is in an alarm state, the self-test is not available.
  • Page 13 Technical Support Testing at the place of installation Ajax system provides several tests to select the correct installation place of devices. Jeweller Signal Strength Test is available for FireProtect 2. The test determines the strength and stability of the signal at the intended location of the device.
  • Page 14 The default value is 36 seconds. You can change the detector ping interval in the Jeweller (or Jeweller/Fibra) menu in the hub settings. Icons The icons show some of the device states. You can view them in Ajax apps in the Devices tab.
  • Page 15 You can see FireProtect 2 (Heat/CO) states in Ajax apps. To access them: 1. Open the Ajax app. 2. Select a hub if you have several of them or if you are using the Ajax PRO app. 3. Go to the Devices ...
  • Page 16 whether re-related temperature changes are detected. These values may differ from the temperature in the room. Parameter Meaning Air temperature in the premise where FireProtect 2 is installed. Measured in Celsius or Fahrenheit degrees depending on the app settings. In the normal state, the temperature value is Temperature displayed in black.
  • Page 17 battery charge is enough to ensure 4 minutes of the sound and LED indication operation. How the battery charge is displayed Battery life calculator The status of the detector’s tamper that responds to detachment of the device from the surface or opening of the enclosure: Open —...
  • Page 18 Learn more CO (carbon monoxide) level in the room where FireProtect 2 is installed: No — the CO level is normal. Alarm — the detector has detected a High CO Level dangerous CO level. If a dangerous CO level is detected by the detector, the text eld highlights red.
  • Page 19 To change FireProtect 2 RB (Heat/CO) settings in the Ajax app: 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the Ajax PRO 3. Go to the Devices tab.
  • Page 20 Runs a detector self-test. Device Self-test Learn more User Guide Opens FireProtect 2 User Manual in the Ajax app. Allows to deactivate the device without removing it from the system. Three options are available: No — the device operates in normal mode.

  • Page 21: Selection Of Installation Place

    → Service → Fire Detectors Settings. Disable the Battery Life Optimization toggle. Click Back to save the settings. If the Battery Life Optimization feature is disabled FireProtect 2 RB (Heat/CO) battery life is 3.5 years (instead of 7). Selection of installation place...
  • Page 22 The coverage area of one FireProtect 2 RB (Heat/CO) is 50 to 60 m², depending on the type of premises. The detector is suitable for installation in premises where the generation of gases/vapours/smoke is part of the operating process. For example, in a garage, kitchen, or boiler room.

  • Page 23: Signal Strength

    Presence of barriers for radio signal passage between devices: walls, inter oor ceilings, large objects located in the premise. Consider the placement recommendations when designing your Ajax system for the object. The security system must be designed and installed by specialists.

  • Page 24: Installation

    Do not install the detector Outdoors. This can lead to the detector failure. In places with low or unstable Jeweller signal strength. This can result in connection loss. Inside premises with temperature and humidity outside the permissible limits. This can lead to the detector failure. In places with fast air circulation.
  • Page 25 To install the detector: 1. Remove the SmartBracket mounting panel from the detector. To remove the panel, turn it counterclockwise. 2. Fix the SmartBracket panel to a surface using double-sided adhesive tape or other temporary fasteners. The mounting panel has an UP sign, which indicates the correct position.
  • Page 26 signal. 1. Don’t open the doors if you feel heat or smoke behind them. Check other entries and use an alternative way to escape. Close all doors behind you as you leave. If heavy smoke enters a room, stay close to the oor and crawl out. If possible, breathe through a wet cloth or hold your breath.
  • Page 27 If the alarm was silenced by the Test/Mute button (for CO level under 300 ppm), check the CO level at the Ajax app. If it is safe to enter the premises, press the Test/Mute button again to check the CO level.
  • Page 28 Incorrectly or poorly installed fuel-burning appliances. Blocked or damaged vents or chimneys/ ues. The tightness of rooms where appliances for burning fuel or replaces are installed. Bad ventilation in rooms with portable gas/para n heaters. IMPORTANT: A CO alarm should not be used as a substitute for proper installation, use, and maintenance of fuel-burning appliances, including appropriate ventilation and exhaust systems.
  • Page 29 Malfunctions If FireProtect 2 malfunction is detected (for example, there is no connection with the hub), the malfunction counter is displayed in the device eld in the Ajax apps. All malfunctions are displayed in the detector States .

  • Page 30: Maintenance

     to familiarize people with the alarm sound and LED indication. FireProtect 2 devices connected to the Ajax hubs generally do not require routine testing. All connected devices are constantly monitored for possible Faults, Low battery, and EOL signals. However, we encourage all users to test FireProtect 2 devices periodically (monthly)* to allow residents of the building to become familiar with the re alarm signals of the system.
  • Page 31 The detector operates for up to 7 years with pre-installed batteries. When the batteries are discharged, replace them with new ones. How to replace batteries in FireProtect 2 RB (Heat/CO) Ensure the batteries are installed with the correct polarity. The polarity is marked inside the enclosure.

  • Page 32: Technical Speci Cations

    Additional cautions for installation The sensor requires oxygen to function properly and have the characteristics described in this manual. The sensor will not operate properly in a zero-oxygen environment. Technical speci cations All technical speci cations of FireProtect 2 RB (Heat/CO)

  • Page 33: Complete Set

    Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after purchase. If the device does not function correctly, please contact the Ajax Technical Support rst. In most cases, technical issues can be resolved remotely.
