FireProtect 2 (Heat/Smoke/CO) Jeweller
User manual
Updated February 2, 2023
FireProtect 2 (Heat/Smoke/CO) Jeweller is a wireless re detector with a built-
in siren. Designed for indoor installation. Detects smoke, temperature rise, and
dangerous CO (carbon monoxide) level.
It is available in two modi cations: with sealed batteries (has SB in the name)
that run up to 10 years, and with replaceable ones (has RB in the name) that run
up to 7 years.
A list of compatible hubs and range extenders is
available here
.
The detector operates as part of the Ajax security system, communicating with
the hub via the
Jeweller
secure radio protocol. The hub communication range is
up to 1,700 meters without obstacles.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireProtect 2 Jeweller and is the answer not in the manual?

Questions and answers

Related Manuals for AJAX FireProtect 2 Jeweller

Summary of Contents for AJAX FireProtect 2 Jeweller

  • Page 1 7 years. A list of compatible hubs and range extenders is available here The detector operates as part of the Ajax security system, communicating with the hub via the Jeweller secure radio protocol. The hub communication range is...

  • Page 2: Functional Elements

    Buy FireProtect 2 (Heat/Smoke/CO) Versions of the detector with other sensor combinations are also available. All Ajax re detectors are available here Functional elements 1. The front panel of the detector with a Test/Mute button . To activate the button, press the center of the panel.

  • Page 3: Operating Principle

    5. Detector certi cation information. 6. Power button. 7. First thermistor. Detects dangerous temperatures. 8. Green LED indicator. 9. Yellow LED indicator. 10. Red LED indicator. 11. Siren. 12. Second thermistor. Detects dangerous temperatures. 13. Information about the detector’s end of life date. 14.
  • Page 4 FireProtect 2 is protected by two tampers. The rst tamper controls the removal of the detector from the SmartBracket mounting panel: the detector reacts with LED indication and sends noti cations to users in Ajax apps and the security company monitoring station. The second tamper signals the removal of the smoke chamber lid, which is located under the front panel of the detector.

  • Page 5: Smoke Sensor

    Smoke sensor FireProtect 2 detects smoke with a bispectral optical sensor. Inside the smoke chamber, the sensor has blue and infrared LEDs which emit light at different wavelengths. This technology allows the detector to determine the size of the volatile particles inside the chamber and respond only to smoke, ignoring vapour and steam.
  • Page 6 carbon monoxide is reached, a chemical reaction is triggered. The detector reads this event and transforms it into an alarm. The detector raises an alarm if the CO level reaches: 50 ppm (0.005%) and above — in no more than 90 minutes. 100 ppm (0.01%) and above —...

  • Page 7: Adding To The System

    Which CMSs Ajax connects to Addressability of Ajax devices allows you to send not only events but also the type of the device, the name, virtual room, and security group assigned to it to the PRO Desktop and to the CMS. The list of transmitted parameters may differ depending on the type of the CMS and the selected communication protocol.
  • Page 8 4. Make sure that the hub is on and has Internet access via Ethernet, Wi-Fi, and/or mobile network. You can do this in the Ajax app or by looking at the LED indicator of the hub: it should light up white or green.
  • Page 9 Once connected, FireProtect 2 will appear in the hub device list in the Ajax app. Device status update depends on the ping interval set in the Jeweller or Jeweller/Fibra settings. The default value is 36 seconds.
  • Page 10 CO level drops below 50 ppm. You can also mute the alarm by pressing the Test/Mute button or in the Ajax app. The The red LED blinks 3 The siren beeps in Alarm by dangerous alarm cannot be muted...
  • Page 11 The alarm cannot be muted if the CO level exceeds 300 ppm. The system has a muted alarm by The LED and sound smoke/rapid indication for alarm by temperature smoke/rapid The siren beeps 3 The red LED blinks rise/temperature temperature times every 3 every 8 seconds.
  • Page 12 Jeweller Signal Strength Test mode. All malfunctions are displayed in the states detector Ajax apps. Fields with malfunctions are The siren beeps in The yellow LED blinks highlighted in red. time with the LED 2 times in a row every Malfunction detected.

  • Page 13: Detector Testing

    Performing a self- more times but more times but test. or in the detector slower. longer. settings in the Ajax app. The device has operated for more than 10 years. The sensitivity of its The yellow LED blinks sensors may have...
  • Page 14 The test allows you to check the status of the detector’s sensors. You can run it in two ways: by pressing the Test/Mute button of the detector and in Ajax apps. If the detector is in an alarm state, the self-test is not available.
  • Page 15 The default value is 36 seconds. You can change the detector ping interval in the Jeweller (or Jeweller/Fibra) menu in the hub settings. Icons The icons show some of the device states. You can view them in Ajax apps in the Devices tab.
  • Page 16 Learn more Battery charge level of the device. Learn more The Interconnected Fire Detectors Alarm feature is activated. Learn more The detector operates in the Always Active mode. The icon is displayed permanently. FireProtect 2 is always active and responds to a re 24/7, regardless of the system’s security mode.
  • Page 17 You can see FireProtect 2 (Heat/Smoke/CO) states in Ajax apps. To access them: 1. Open the Ajax app. 2. Select a hub if you have several of them or if you are using the Ajax PRO app. 3. Go to the Devices tab.
  • Page 18 Online — the detector is connected to the hub or range extender. Normal state. O ine — no connection between the detector and the hub or range extender. Check the detector connection. The battery charge level of the device: OK — detector batteries have su cient charge.
  • Page 19 of the device enclosure and the mounting panel is not violated. Normal state. Learn more Smoke sensor status: Clear — normal state, the detector does not detect smoke. Alarm — the detector detects smoke. Smoke If smoke is detected, the text eld highlights red.
  • Page 20 QR code and on the packaging box. The number of FireProtect 2 loop (zone). Events Device No. are sent to the CMS with this number. Settings To change FireProtect 2 (Heat/Smoke/CO) settings in an Ajax app: 1. Open the Ajax app.
  • Page 21 2. Select the hub if you have several of them or if you are using the Ajax PRO 3. Go to the Devices tab. 4. Select the device from the list. 5. Go to Settings by clicking on the gear icon 6.
  • Page 22 The recommended value is two or three bars. Learn more Runs a detector self-test. Device Self-test Learn more Opens FireProtect 2 User Manual in the Ajax User Guide app. Allows to temporarily deactivate the device without removing it from the system. Three options are available: No —...

  • Page 23: Selection Of Installation Place

    Selection of installation place The detector is designed for indoor installation only. The coverage area of one FireProtect 2 (Heat/Smoke/CO) is 50 to 60 m², depending on the type of premises. The detector should be installed in every room. The detector is placed in the center of the ceiling at a distance of 30 cm from light xtures, chandeliers, or any other decorative objects that may interfere with alarm detection.

  • Page 24: Signal Strength

    Presence of barriers for radio signal passage between devices: walls, inter oor ceilings, large objects located in the room. Consider the placement recommendations when designing your Ajax security system for the object. The security system must be designed and installed by specialists.
  • Page 25 Do not install the detector Outdoors. This can lead to the detector failure. In places with low or unstable Jeweller signal strength. This can result the connection loss. Inside premises with temperature and humidity outside the permissible limits. This could damage the detector. In places with fast air circulation.

  • Page 26: Installation

    Installation Make sure that you have selected the optimal installation place and it complies with the requirements of this manual. To install the detector: 1. Remove the SmartBracket mounting panel from the detector. To remove the panel, turn it counterclockwise. 2.
  • Page 27 Malfunctions If FireProtect 2 malfunction is detected (for example, there is no connection with the hub), the malfunction counter is displayed in the device eld in the Ajax apps. All malfunctions are displayed in the detector States .

  • Page 28: Maintenance

    Ensure the batteries are installed with the correct polarity. The polarity is marked inside the enclosure. Please run a self-test with Ajax apps or by pressing the Test/Mute button after the batteries are replaced to check the correct operation of the detector.

  • Page 29: Complete Set

    Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase. If the device does not function correctly, please contact the Ajax Technical Support rst. In most cases, technical issues can be resolved remotely.
