AJAX FireProtect 2 Jeweller User Manual

Wireless fire detector with a built-in siren
Hide thumbs Also See for FireProtect 2 Jeweller:

Advertisement

Quick Links

Download this manual
FireProtect 2 (Heat/Smoke/CO) Jeweller user
FireProtect 2 (Heat/Smoke/CO) Jeweller is a wireless fire detector with a built-in
siren. Designed for indoor installation. Detects smoke, temperature rise, and
dangerous CO (carbon monoxide) level. The detector also can work without a hub.
There are two available modifications: one with sealed batteries (has SB in the
name) that run for 10 years, and another with replaceable batteries (has RB in the
name) that run for up to 7 years.
FireProtect 2 (Heat/Smoke/CO) detector is compatible only with hubs on
2.14.1
and higher.
Hubs and range extenders compatible with FireProtect 2 RB (Heat/Smoke/CO)
Jeweller
Hubs and range extenders compatible with FireProtect 2 SB (Heat/Smoke/CO)
Jeweller
manual
Updated July 23, 2024
OS Malevich

Advertisement

loading
Need help?

Need help?

Do you have a question about the FireProtect 2 Jeweller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX FireProtect 2 Jeweller

Summary of Contents for AJAX FireProtect 2 Jeweller

  • Page 1 FireProtect 2 (Heat/Smoke/CO) Jeweller user manual Updated July 23, 2024 FireProtect 2 (Heat/Smoke/CO) Jeweller is a wireless fire detector with a built-in siren. Designed for indoor installation. Detects smoke, temperature rise, and dangerous CO (carbon monoxide) level. The detector also can work without a hub. There are two available modifications: one with sealed batteries (has SB in the name) that run for 10 years, and another with replaceable batteries (has RB in the name) that run for up to 7 years.

  • Page 2: Functional Elements

    The detector operates as part of the Ajax system, communicating with the hub via Jeweller secure radio protocol. The hub communication range is up to 1,700 meters without obstacles. Buy FireProtect 2 (Heat/Smoke/CO) Versions of the detector with other sensor combinations are also available. All Ajax fire...

  • Page 3: Operating Principle

    Tamper button . Triggers when an attempt is made to detach the detector from the surface or remove it from the mounting panel. 5. Detector certification information. . Power button. 7. First thermistor. Detects dangerous temperatures. . Green LED indicator. 9.

  • Page 4: Smoke Sensor

    FireProtect 2 is protected by two tampers. The first tamper controls the removal of the detector from the SmartBracket mounting panel: the detector reacts with LED indication and sends notifications to users in Ajax apps and the security company monitoring station. The second tamper signals the removal of the smoke chamber lid, which is located under the front panel of the detector.
  • Page 5 wavelengths. This technology enables the detector to determine the size of volatile particles inside the chamber and respond to smoke. The smoke chamber in FireProtect 2 is protected from dust, dirt, and insects. Even if dust gets inside and settles, this does not threaten or impair fire detection. The optical system is designed to prevent non-volatile particles from getting within the field of both blue and infrared LEDs at the same time.
  • Page 6 LED indication for 12 hours. To run the self-test, wait at least 3 minutes after turning on the detector. Useany remote silencing feature (e.g., via the Ajax app) only within the line of sight of the CO sensor. Interconnected Fire Detectors Alarms* All fire detectors of the FireProtect 2 product line support the Interconnected...

  • Page 7: Adding To The System

    Which CMSs Ajax connects to Addressability of Ajax devices allows you to send not only events but also the type of the device, the name, virtual room, and security group assigned to it to the PRO Desktop and to the CMS. The list of transmitted parameters may differ depending on the type of the CMS and the selected communication protocol.
  • Page 8 The space functionality is available for apps of such versions or later: Ajax Security System 3.0 for iOS; Ajax Security System 3.0 for Android; Ajax PRO: Tool for Engineers 2.0 for iOS; Ajax PRO: Tool for Engineers 2.0 for Android; Ajax PRO Desktop 4.0 for macOS;...
  • Page 9 Once connected, FireProtect 2 will appear in the hub device list in the Ajax app. Device status update depends on the ping interval set in the Jeweller or Jeweller/Fibra settings. The default value is 36 seconds.
  • Page 10 To use the detector autonomously, follow these steps: 1. Select the optimal location of the detector using the recommendations in the Selection of installation place section. 2. Mount the detector on the SmartBracket panel as described in the Installation section. 3.
  • Page 11 CO level drops below 50 ppm. You can also mute the alarm by pressing the Test/Mute button or in the Ajax app. The The red LED flashes 3 The siren beeps in Alarm by dangerous alarm cannot be muted...
  • Page 12 detector is restored automatically. Tamper alarm. The detector is The yellow LED lights removed from the up for 1 second. SmartBracket mounting panel. The detector is The green LED lights installed on the Turns on when the up for 1 second. SmartBracket tamper is triggered.
  • Page 13 All malfunctions are displayed in the states detector Ajax apps. Fields with malfunctions are The siren beeps in The yellow LED highlighted in red. time with the LED flashes 2 times in a Malfunction detected. indication every row every minute.

  • Page 14: Functionality Testing

    The test allows you to check the status of the detector’s sensors. You can run it in two ways: by pressing the Test/Mute button of the detector and in Ajax apps. To run the self-test, wait at least 3 minutes after turning on the detector.
  • Page 15 If no sound and LED indications occurred during the self-test, the detector may not be used. Contact our Technical Support Testing at the place of installation Ajax system provides several tests to select the correct installation place of devices. Jeweller Signal Strength Test is available for FireProtect 2. The test...
  • Page 16 The default value is 36 seconds. You can change the detector ping interval in the Jeweller (or Jeweller/Fibra) menu in the hub settings. Icons The icons show some of the device states. You can view them in Ajax apps in the Devices tab.
  • Page 17 Learn more The detector operates in the Always Active mode. The icon is displayed permanently. FireProtect 2 is always active and responds to a fire 24/7, regardless of the system’s security mode. Learn more radio signal range extender The detector operates through the The detector is deactivated.
  • Page 18 FireProtect 2 (Heat/Smoke/CO) states in Ajax apps. To access them: 1. Open the Ajax app. 2. Select a hub if you have several of them or if you are using the Ajax PRO app. 3. Go to the Devices tab.
  • Page 19 Offline — no connection between the detector and the hub or range extender. Check the detector connection. The battery charge level of the device: OK — detector batteries have sufficient charge. Normal state. Battery low — detector batteries are discharged. When the batteries are discharged, users and the security company monitoring station receive a notification.
  • Page 20 The status of the detector’s tamper that responds to detachment of the device from the surface or opening of the enclosure: Open — the detector is removed from the SmartBracket mounting panel, or the enclosure integrity is violated in another way. Check the mounting of the detector.
  • Page 21 If a rapid temperature rise is detected, the text field highlights red. Learn more CO (carbon monoxide) level in the room where FireProtect 2 is installed: No — the CO level is normal. Alarm — the detector has detected a High CO Level dangerous CO level.
  • Page 22 Settings To change FireProtect 2 (Heat/Smoke/CO) settings in an Ajax app: 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the Ajax PRO 3. Go to the Devices tab.
  • Page 23 Runs a detector self-test. Smoke Sensor Self-test Learn more User Guide Opens FireProtect 2 User Manual in the Ajax app. Allows to deactivate the device without removing it from the system. Three options are available: No — the device operates in normal mode.

  • Page 24: Selection Of Installation Place

    FireProtect 2 detectors. This feature doesn’t affect alarm notification delivery time. To disable the Battery Life Optimization feature: 1. Open the Ajax app. 2. Select the hub with FireProtect 2 detectors connected. 3. Go to: Hub → Settings →...
  • Page 25 The coverage area of one FireProtect 2 (Heat/Smoke/CO) is 50 to 60 m², depending on the type of premises. The detector should be installed in every room. The detector is placed in the center of the ceiling at a distance of 30 cm from light fixtures, chandeliers, or any other decorative objects that may interfere with alarm detection.

  • Page 26: Signal Strength

    Presence of barriers for radio signal passage between devices: walls, interfloor ceilings, large objects located in the room. Consider the placement recommendations when designing your Ajax system for the object. The security system must be designed and installed by specialists. The...
  • Page 27 The Jeweller signal strength is determined by the ratio of the number of undelivered/corrupted data packets that are exchanged between the hub and the detector to expected ones within a certain period of time. Signal strength is indicated by the icon on the Devices tab: Three bars —...

  • Page 28: Installation

    due to vehicle exhaust gases exists. For such premises we recommend using a detector without a smoke sensor: FireProtect 2 (Heat/CO) In very dusty places or areas with a lot of insects. Insects, dust, and other contaminants can settle on the smoke chamber lid and prevent fire detection. Near lighting fixtures, decorations, and other interior items that may interfere with the circulation of air in the room.
  • Page 29 Use double-sided adhesive tape for temporary fixation only. The device fixed by the adhesive tape can peel off the surface at any time, which can lead to damage if the device is dropped. 3. Run the Jeweller signal strength test. The recommended value is two or three bars.
  • Page 30 2. Evacuate as quickly as you can, don’t panic. Save time, and don’t pack your things. Arrange a meeting place outside for everybody in the building. Check if everyone got out safely. 3. Call the fire department immediately by yourself or ask someone nearby. Remember, even the smallest fire can spread quickly, so do not hesitate to call the fire department.
  • Page 31 If the alarm was silenced by pressing the Test/Mute button (for CO level under 300 ppm), check the CO level in the Ajax app. If it is safe to enter the premises, press the Test/Mute button again to check the CO level.
  • Page 32 The CO exposure period is also important. A low level for a long period (e.g., 150 ppm for 90 minutes) can cause the same symptoms as a high level of CO for a short period (e.g., 300 ppm CO for 30 minutes). The table below shows how different concentrations of CO affect people.

  • Page 33: Maintenance

    If FireProtect 2 malfunction is detected (for example, there is no connection with the hub), the malfunction counter is displayed in the device field in the Ajax apps. All malfunctions are displayed in the detector States . Fields with malfunctions are highlighted in red.
  • Page 34 Ensure the batteries are installed with the correct polarity. The polarity is marked inside the enclosure. Please run a self-test with Ajax apps or by pressing the Test/Mute button after the batteries are replaced to check the correct operation of the detector.
  • Page 35 Situations that must be avoided Situation Possible consequences Contamination by alkaline Significant changes to the sensor characteristics when the sensor is metals contaminated by alkaline metals, especially salt water spray. Exposure to high Exposure to high concentrations of common gases such as ammonia concentrations of common may cause irreversible changes.

  • Page 36: Technical Specifications

    Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase. If the device does not function correctly, please contact the Ajax Technical Support first. In most cases, technical issues can be resolved remotely.
