ZYNQ Ultrascale + FPGA Core Board ACU3EG User Manual

Part 1: ACU3EG core board Introduction

ACU3EG (core board model, the same below) FPGA core board, ZYNQ
chip is based on XCZU3EG-1SFVC784I of XILINX company Zynq UltraScale+
MPSoCs EG series.
This core board uses 5 Micron DDR4 chips MT40A512M16GE, of which 4
DDR4 chips are mounted on the PS side to form a 64-bit data bus bandwidth
and 4GB capacity. One DDR4 chip is mounted on the PL end, which is a 16-bit
data bus width and a capacity of 1GB. The highest operating speed of DDR4
SDRAM on the PS side can reach 1200MHz (data rate 2400Mbps), and the
highest operating speed of DDR4 SDRAM on the PL side can reach 1066MHz
(data rate 2132Mbps). In addition, a 256MBit QSPI FLASH and an 8GB eMMC
FLASH chip are also integrated on the core board to start storage configuration
and system files.
In order to connect with the carrier board, the four board-to-board
connectors of this core board expand the PS side USB2.0 interface, Gigabit
Ethernet interface, SD card interface and other remaining MIO ports; also
expand 4 pairs of PS MGT high-speed transceiver interface; and almost all IO
ports on the PL side (HP I/O: 96, HD I/O: 84). The wiring between the CZU3EG
chip and the interface has been processed with equal length and differential,
and the core board size is only 3.15*2.36 (inch), which is very suitable for
secondary development.
