4.1 Installation requirements

The guidelines for correct mechanical installation of
lifting stations are according to EN 12056-4.
Install the lifting station in a properly lit and vented
room with 60 cm free space around all parts to be
serviced and operated.
Provide a pump sump below the floor level. If a
lifting station is installed in a basement with the
risk of penetrating groundwater, we
recommend (and in certain countries it is required)
to install a drainage pump in a separate pump
sump below floor level in order to drain the room.
See fig. Installation sketch.
The collecting tank, pump and cables may
be flooded (max. 2 m for 7 days).
The controller must be installed in a dry
and well-ventilated place.
All pipe connections must be flexible to reduce
resonance.
Lifting stations must be secured against uplift and
twist.
All outlet pipes from lifting station, diaphragm
pump and drainage pump must have a bend
above the local backwater level. The highest point
of the bend/reversed water seal must be above
street level.
For outlet pipes, DN 80 and upwards, install an
isolating valve in the outlet pipe. Also provide an
isolating valve in the inlet line.
Surface water must not be discharged into the
lifting station inside the building. It must have its
own pumping station outside the building.
Lifting stations must be provided with an approved
non-return valve according to EN 12050-4.
The volume of the outlet pipe above the non-
return valve up to the backwater level must be
smaller than the effective tank volume.
In general, a lifting station for black wastewater
must be vented above roof level. However, it
is permitted to lead the ventilation, as a secondary
ventilation, into the main building ventilation
system. Special vent valves (accessory) must be
placed outside the building.
If the wastewater is discharged into a collecting
line, this collecting line must have a filling ratio of
at least h/d = 0.7. The collecting line must be at
least one nominal diameter bigger after the outlet
pipe connection.
The controller must be placed in a flood-safe
place and be equipped with an alarm.
Use a diaphragm pump for simple, manual
draining of the collecting tank in case of pump
failure (not obligatory).
18
