2.1.4 Collecting tank
The gas-, odour- and pressure-tight collecting tank is
made of wastewater resistant polyethylene (PE) and
has all necessary ports for the connection of inlet
pipes, outlet pipe, vent pipe and a manually operated
diaphragm pump, which is available as an accessory.
MULTILIFT M, MD, MOG, MDG
The collecting tank has a turnable, eccentric disk in
the back allowing adjustment of the inlet to any height
between 180 and 315 mm above the floor. The most
common heights are marked beside the inlet.
The MULTILIFT M collecting tank offers three
horizontal inlets in the sides (2 × DN 100 and 1 × DN
50) and two vertical inlets at the top of the tank (1 ×
DN 150 and 1 × DN 50). The centres of the horizontal
inlets are 180 mm (DN 50) and 250 mm (DN 150)
above the floor.
The MULTILIFT MD collecting tank offers four
horizontal inlets in the sides (2 × DN 100 and 2 × DN
50) and three vertical inlets at the top of the tank (2 ×
DN 150 and 1 × DN 50). The centres of the horizontal
inlets are 120 mm (DN 50) and 250 mm (DN 150)
above the floor.
The MULTILIFT MOG and MDG collecting tank offers
four horizontal inlets in the sides (2 × DN 100 and 2 ×
DN 50) and two vertical inlets at the top of the tank (1
× DN 150 and 1 × DN 50). The centres of the
horizontal inlets are 115 mm (DN 50) and 250 mm
(DN 150) above the floor.
The side and back inlets 180 and 250 mm above the
floor are for direct connection to wall-hung or floor-
standing toilet according to EN 33 and EN 37. Further
sanitary appliances can be connected to the other
ports.
MULTILIFT MLD
The collecting tank offers one vertical inlet (DN 50) at
the top of the tank and one vertical inlet (DN 150) in
the stepped part of the tank.
Tank volume
The tank volume and effective volume (volume
between start and stop) for MULTILIFT lifting stations
appear from the following table:
Type of
Inlet level
tank
[mm]
180
MULTILIFT
250
M, MD
315
MULTILIFT
560
MLD
180
MULTILIFT
250
MOG, MDG
315
Setting to the relevant start inlet level must
be made during startup phase via the
setup menu.
The first step after power supply
connection is a startup phase with level
setting.
To minimise sedimentation, the tank
bottom is chamfered to lead the
wastewater to the pump.
2.1.5 Motor cable
The motor cable is fitted to the motor via a cable
entry. The enclosure class is IP68.
MULTILIFT M, MD, MLD: The length of the cable is
either 4 or 10 m.
MULTILIFT MOG, MDG: The length of the cable is 10
m.
Effective
Total tank
tank
volume [l]
volume [l]
49
130
69
86
270
190
23
93
37
50
9
