3. Receiving the product

3.1 Transportation

Do not stack the product.
WARNING
Falling objects
Death or serious personal injury
Secure the product during transport to
prevent it from tilting or falling down.
CAUTION
Back injury
Minor or moderate personal injury
Use lifting equipment.
CAUTION
Crushing of feet
Minor or moderate personal injury
Wear safety shoes when moving the
product.
The motor lifting bracket is only intended
for lifting the pump. Never lift or lower the
lifting station by means of the lifting
bracket.
Lift the lifting station by the collecting tank
lifting brackets.

3.2 Inspecting the product

Before installing the product, do the following:
1. Check that the product is as ordered.
2. Check that no visible parts have been damaged.
3. If parts are damaged or missing, contact your
local Grundfos sales company.
16

3.3 Scope of delivery

3.3.1 MULTILIFT M, MD
Grundfos MULTILIFT M (one pump) and MD (two
pumps) lifting stations are supplied complete with
collecting tank, non-return valves, a sensor unit with
cable and one or two pumps with cable, both
connected to the level controller. The controller
includes a power supply cable with plug.
An accessories bag containing the following items is
also included:
1 × installation and operating instructions
1 × quick guide for controller menu
1 × outlet adapter flange, DN 80, with connecting
piece, DN 100 (outer diameter, 110 mm)
1 × flexible hose, DN 100, and two clamps to
connect the outlet pipe
1 × flexible hose, DN 70, and two clamps to
connect the vent pipe
2 × screw and expansion anchor for tank fixation
3 × screw and washer for fastening a pipe plug in
the inlet disk, if required
1 × socket seal, DN 100
1 × socket seal, DN 50, for diaphragm pump
connection or inlet, DN 50
1 × gasket kit, DN 80, 4 bolts M16, nuts and
washers (galvanised).
3.3.2 MULTILIFT MLD
Grundfos MULTILIFT MLD lifting stations are supplied
complete with collecting tank, butterfly-non-return
valves, a sensor unit with cable and two pumps with
cable, both connected to the level controller. The
controller includes a power supply cable with plug.
An accessories bag containing the following items is
also included:
1 × installation and operating instructions
1 × quick guide for controller menu
1 × outlet adapter flange, DN 80, with connecting
piece, DN 100 (outer diameter, 110 mm)
1 × flexible hose, DN 100, and two clamps to
connect the outlet pipe
1 × flexible hose, DN 70, and two clamps to
connect the vent pipe
4 × screw and expansion anchor for tank fixation
1 × socket seal, DN 150
1 × flexible hose connection with two clamps, DN
50, for diaphragm pump connection or inlet, DN
50
1 × gasket kit, DN 80, 4 bolts M16, nuts and
washers (galvanised).
