AK-CC55 Compact
Function Description
Refrigerant factor K2 Refrigerant factor for a custom refrigerant - please
contact Danfoss for detailed information
Refrigerant factor K3 Refrigerant factor for a custom refrigerant - please
contact Danfoss for detailed information
Refrigerant factor Refrigerant factor for a custom refrigerant - please
A1 contact Danfoss for detailed information
Refrigerant factor Refrigerant factor for a custom refrigerant - please
A2 contact Danfoss for detailed information
Refrigerant factor Refrigerant factor for a custom refrigerant - please
A3 contact Danfoss for detailed information
Pe Min range Minimum measuring range for sensor
Pe Max range Maximum measuring range for sensor
Temperature sensor Sensor type for S3, S4 and S5. Normally a Pt 1000 sen-
type sor with great signal accuracy is used. But you can al-
so use a sensor with another signal accuracy. That
could e.g. be a PTC sensor (1000 ohm at 25 °C). All the
mounted sensors S3-S5 must be of the same type.
Sensor point 1 - The temperature value for the user-defined tempera-
Temp. ture sensor in the reference point.
Sensor point 1 - The resistance value in kohm for the user-defined
kohm temperature sensor in the reference point.
Sensor point 1 - The resistance value in ohm for the user-defined tem-
ohm perature sensor in the reference point.
Sensor point 2 - The temperature value for the user-defined tempera-
Temp. ture sensor in the reference point.
Sensor point 2 - The resistance value in kohm for the user-defined
kohm temperature sensor in the reference point.
Sensor point 2 - The resistance value in ohm for the user-defined tem-
ohm perature sensor in the reference point.
Sensor point 3 - The temperature value for the user-defined tempera-
Temp. ture sensor in the reference point.
Sensor point 3 - The resistance value in kohm for the user-defined
kohm temperature sensor in the reference point.
Sensor point 3 - The resistance value in ohm for the user-defined tem-
ohm perature sensor in the reference point.
Defrost method Select method of defrost
Defrost stop meth- Here you define whether a defrost cycle is to be stop-
od ped by time or by a temperature sensor
Defrost stop limit A When the selected defrost stop sensor reaches the set
limit, the defrost cycle is terminated
Food type When changing the food type the controller will auto-
matically adapt temperature setpoints and alarm lim-
its according to the selected food type. Please be
aware that the setting will revert to "None" after hav-
ing been changed.
Food temp. sensor Select the temperature to be used for the food tem-
perature representation
Network address Network address of the controller

Thermostat control

Table 25: Thermostat control
Function Description
Control state A Readout of the actual control state of the controller
Thermostat air Thermostat temperature
temp. A
Food temperature A Read out of food temperature
S3 Air ON evap. A Actual sensor value
© Danfoss | Climate Solutions | 2022.08
Values
0=Pt 1000, 1=PTC 1000, 2=NTC 5k, 3=NTC 10k,
4=User-defined
0=None, 1=Electrical, 2=Hot gas, 3=Brine, 4=Air/
Offcycle
0=Time, 1=S5 sensor, 2=S4 sensor
0=None, 1=Vegetables, 2=Dairy, 3=Meat and fish,
4=Frozen food, 5=Ice cream
1=Thermostat air, 2=Alarm air, 3=S3 Air ON evap.
Values
0=Normal ctrl., 1=Hold after defrost, 2=Min ON timer,
3=Min OFF timer, 4=Drip off, 10=Main switch OFF,
11=Thermostat cut-out, 12=Frost protection S4,
14=Defrost, 15=Fan delay, 16=Forced closing,
17=Door open, 18=Melt period, 19=Modulating
temp. control, 20=Emergency control, 23=Adaptive
superheat control, 24=Start injection, 25=Manual
control, 26=No refrigerant selected, 29=Case clean-
ing, 30=Forced cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down controller,
48=Adaptive liquid control
Code Short name
P84 P84 RfgFac.K2
P85 P85 RfgFac.K3
x65 --- Rfg.Fac.A1
x66 --- Rfg.Fac.A2
x67 --- Rfg.Fac.A3
o20 o20 MinTransPres
o21 o21 MaxTransPres
o06 o06 SensorConfig
X20 --- SP1 Temp
X21 --- SP1 kohm
X22 --- SP1 ohm
X23 --- SP2 Temp
X24 --- SP2 kohm
X25 --- SP2 ohm
X26 --- SP3 Temp
X27 --- SP3 kohm
X28 --- SP3 ohm
d01 d01 Def. method
d10 d10 DefStopSens.
d02 d02 Def.StopTemp
r89 r89 Food type
q39 q39 Food sensor
o03 o03 Unit addr.
Code Short name
u00 u00 Ctrl. state
u17 u17 Ther. air
U72 U72 Food temp.
u12 u12 S3 air temp.
