Danfoss AK-CC55 Compact User Manual page 26

AK-CC55 Compact
Figure 29: Connections for application 1
40 41 42 43 44 45 46 47 48 49 50
S3 S4 S5
115 – 230 V AC Comp.
L N
1 2 3 7 8
Figure 30: Connections for application 2
40 41 42 43 44 45 46 47 48 49 50
S3 S4 S5
115 – 230 V AC
Comp.
L N
1 2 3 7 8
Figure 31: Connections for application 3
40 41 42 43 44 45 46 47 48 49 50
S3 S4 S5
115 – 230 V AC
Comp.
L N
1 2 3 7 8
© Danfoss | Climate Solutions | 2022.08
60 61 70 71
AI5 DI2 AO1
DI1
Alarm Fan
9 10 11 12 13 14 15 16 17
60 61 70 71
AI5 DI2 AO1
DI1
Light Fan
9 10 11 12 13 14 15 16 17
60 61 70 71
AI5 DI2 AO1
DI1
Railheat Fan
9 10 11 12 13 14 15 16 17
1
83 84 85
B - A +
MODBUS
Defrost
2
83 84 85
B - A +
MODBUS
Defrost
3
83 84 85
B - A +
MODBUS
Defrost
BC365212986197en-000201 | 26
