AK-CC55 Compact
6. Open parameter r89 and set the number for the array of presettings. The few selected settings will now be
transferred to the menu
7. Set the desired cut-out temperature r00
8. Set the weighted thermostat air temperature between S4 and S3 sensor r15
9. Set the weighted thermostat air temperature between S4 and S3 during night operation r61
10. Set the weighted alarm air temperature between S4 and S3 A36
11. Set the weighted display readout between S4 and S3 o17
12. Select refrigerant via parameter o30 (only application 5-9)
13. Set the pressure transmitter min. and max. range via parameter o20 and o21 (only application 5-9)
14. Set the desired defrost method in d01
15. Set the interval time between defrost starts in d03
16. Set the desired defrost sensor in d10
17. Set the maximum defrost time in d04
18. Set the defrost stop temperature in d02
19. Open parameter r12 and start the regulation
20. Go through the parameter list and change the factory values where needed
21. Get the controller up and running on network:
◦ MODBUS: Activate scan function in system unit
Table 11: Food type settings
Setting of presettings (r89).
After setting 1-5, setting is returned to 0.
Food type
Temperature (r00)
Max. temp. setting (r02)
Min. temp. setting (r03)
Upper alarm limit (A13)
Lower alarm limit (A14)
Upper alarm limit for S6 (A22)
Lower alarm limit for S6 (A23)
© Danfoss | Climate Solutions | 2022.08
1 2
Vegetables Milk
8 °C 0 °C
10 °C 4 °C
4 °C -4 °C
14 °C 8 °C
0 °C -5 °C
14 °C 8 °C
0 °C -5 °C
3 4
Meat/fish Frozen food
-2 °C -20 °C
2 °C -16 °C
-6 °C -24 °C
8 °C -15 °C
-5 °C -30 °C
8 °C -15 °C
-5 °C -30 °C
BC365212986197en-000201 | 36
5
Ice cream
-24 °C
-20 °C
-28 °C
-15 °C
-30 °C
-15 °C
-30 °C
