AK-CC55 Compact
Operation via AK-UI55 Bluetooth
Access to parameters via Bluetooth and app
1.
App can be downloaded from App Store and Google Play.
◦ Name = AK-CC55 Connect
◦ Start the app.
2.
Click on the display's Bluetooth button for 3 seconds.
◦ The Bluetooth light will then flash while display is showing the controller's address.
3.
Connect to the controller from the app.
Figure 48: AK-UI55 Bluetooth
Display info:
• Loc
• The operation is locked and cannot be operated via Bluetooth.
• Unlock from the system manager.
Figure 49: Connect to controller
The functions are described on
© Danfoss | Climate Solutions | 2022.08
Figure 50: Controller dashboard
Page 45
–
Page
57.
Figure 51: Set-up menu
BC365212986197en-000201 | 44
